505_03
15210851
11/2006
Validity from serial number
Installation, operating and
maintenance instructions
ELECTRIC FRYER
IF1E4
IF4E
·
IF2E6
IF6E
·
© COPYRIGHT 2004 GIGA GRANDI CUCINE SRL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IF1E4 and is the answer not in the manual?

Questions and answers

Summary of Contents for GIGA IF1E4

  • Page 1 505_03 15210851 11/2006 Validity from serial number Installation, operating and maintenance instructions ELECTRIC FRYER IF1E4 IF4E · IF2E6 IF6E · © COPYRIGHT 2004 GIGA GRANDI CUCINE SRL...
  • Page 2 CHARACTERISTICS Supplied by: Date: Customer Service: e-mail 505_03 - ELECTRIC FRYER 11/2006 2 · 16...
  • Page 3: Table Of Contents

    INDEX Diagram Features of the appliances Technical data 4 Installation instructions 4.1 Safety rules 4.2 Structure, framework and safety devices of the appliances 4.3 Assembly 4.3.1 Installation premises 4.3.2 Statutory regulations and technical requirements 4.3.3 Installation 4.3.4 Wiring 4.3.5 Equipotential 4.4 Preparing for installation Operation preparation 5.1 Preparation and Start-up...
  • Page 4: Diagram

    1 - DIAGRAM Fig. 1 IF1E4 IF1E4 IF2E6 IF2E6 IF4E IF4E IF6E IF6E 11.5 11.5 11.5 11.5 11.5 .5 11.5 11.5 IF1E4 IF1E4 IF2E6 IF2E6 IF4E IF4E IF6E IF6E Terminal board Green indicator light (tension) Yellow indicator light (resistance) Cable input...
  • Page 5: Technical Data

    Model Dimensions in mm. Voltage rating Power Lead wire / Section (LxPxH) IF1E4 - IF4E 400 x 610 x 220 400 V 3N or 230 V 3 7.5 kW 5 x 1.5 mm or 4 x 2.5 mm IF2E6 - IF6E...
  • Page 6: Installation Instructions

    4 - INSTALLATION INSTRUCTIONS 4.1 Safety rules 4.3.2 Statutory regulations and technical requirements During installation of the appliance, the following regulations must • Only a local gas utility technician is authorized to carry out gas be adhered to: installations and connections. The statutory regulations (applied •...
  • Page 7: Preparation And Start-Up

    4 - INSTALLATION INSTRUCTIONS appliance, it is necessary to waterproof the leaks with sanitary silico- In order to collect the oil, place a bowl under the drainpipe. ne, anti-mould and heat resistant to at least 100°C (i.e. Pactan 6076). The knob position is fixed; therefore, in the design of the parts Panels and/or inflammable parts must be at a distance of at least where the appliance will be fit into, the relevant panel will have to 300 mm from the hot walls of the machine.
  • Page 8 CHARACTERISTICS Fig. 2 505_03 - ELECTRIC FRYER 11/2006 8 · 16...
  • Page 9 CHARACTERISTICS Fig. 3 505_03 - ELECTRIC FRYER 11/2006 9 · 16...
  • Page 10 CHARACTERISTICS Fig. 4 604 outside outside 604 outside outside 505_03 - ELECTRIC FRYER 11/2006 10 · 16...
  • Page 11: Ignition

    5 - SET-UP FOR OPERATION 5.3 Ignition 5.4 Cleaning and taking care of the machine Check if the oil discharge is closed. Never clean the appliance with jets of water, whether direct or pressurised! Fill the vessel with oil up to the level marked Never clean the appliance before it has cooled down.
  • Page 12: Instructions For Use

    6 - INSTRUCTIONS FOR USE 6.1 Safety, cleaning and repair rules 6.3 Appliance care and frequency of maintenance • This appliance is used for the preparation of meals at industri- Attention! When cleaning, carefully avoid washing the al level. Usage and cleaning can be carried only by expert per- appliance with direct water jets or high-pressure sonnel.
  • Page 13: Warnings And Advice For Maintenance Of Stainless Steel Appliances

    6 - INSTRUCTIONS FOR USE • contact with non-ferrous metals (element build up) 6.4.3 The 2002/96/EC (WEEE) Directive: • lack of oxygen (i.e. no air inlet, water lacking oxygen). information to users This informational note is meant only for Fig. A owners of equipment marked with the 6.4.2 Warnings and advice for maintenance of stainless symbol shown in fig.
  • Page 14: Appendix: Electrical Diagrams

    7 - APPENDIX: ELECTRICAL DIAGRAMS IF1E4 - IF4E IF2E6 - IF6E Line input terminal board Switch Microswitch Contactor Safety contactor Working thermostat Safety thermostat Green pilot lamp Orange pilot lamp Resistance 505_03 - ELECTRIC FRYER 11/2006 14 · 16...
  • Page 15: Appendix: Electrical Diagrams

    7 - APPENDIX: ELECTRICAL DIAGRAMS IF1E4 - IF4E IF2E6 - IF6E Line input terminal board Switch Microswitch Contactor Safety contactor Working thermostat Safety thermostat Green pilot lamp Orange pilot lamp Resistance 505_03 - ELECTRIC FRYER 11/2006 15 · 16...
  • Page 16 IF THE INSTRUCTIONS CONTAINED IN THIS MANUAL ARE NOT OBSERVED. GIGA GRANDI CUCINE S.r.l. - Via Pisana, 336 - Loc. Olmo - 50018 SCANDICCI (FI) - ITALY - Tel. +39 055 722 33 (11 linee r.a.) - Fax +39 055 7310 056 - www.gigagrandicucine.it -...
