INDEX Models and dimensions Note for the installer page page Running the appliance on other types Data of appliances of gas Replacing the main burner nozzle Technical data Replacing the pilot burner nozzle Maintenance Operating instructions Replacing parts Construction, equipment installed Gas valve and safety devices Safety thermostat...
Page 3
Dimensions 13.5 13.5 52.5 52.5 52.5 52.5 CFG15 CFG15D 1/2” gas connector Safety thermostat Technical data Oil drain 041 - 03 - Gas fryers...
Page 4
Dimensions KFG15 KFG15D KFG20 KFG20D 3/4” gas connector Safety thermostat Technical data Oil drain 041 - 03 - Gas fryers...
Page 5
Dimensions OPFG15 OPFG15D OPFG20 OPFG20D 3/4” gas connector Safety thermostat Technical data Oil drain 041 - 03 - Gas fryers...
Model Description Dimensions Basins Nr. Gas connector (LxPxH+H1) - mm. Capacity (Lt.) CFG15 Gas deep fat fryer - 1 tank 400 x 700 x 875 (1085) 1/2" ISO R228 51BQ2905 CFG15D Gas deep fat fryer - 2 tanks 800 x 700 x 875 (1085) 15+15 1/2"...
Page 7
TABLE 1 CFG15 CFG15D KFG20 KFG20D Model KFG15 KFG15D OPFG20 OPFG20D OPFG15 OPFG15D II2H3+ Category Construction type Air necessary for combustion 18.0 12.0 24.0 Nominal thermal power Minimum thermal power Connection pressure Methane gas 2H 20 mbar Liquid gas 3+...
ASSEMBLY Gas connection Location The R 1/2” gas off-take for models CFG15 - CFG15D and R 3/4” for models KFG15 - KFG15D - KFG20 - KFG20D - The appliance should be installed in a well ventilated OPFG15 - OPFG15D - OPFG20 - OPFG20D on the ap- room, and if possible under a range hood.
screws; - Insert extension (B) onto the collector; - Place part (C) on part (A) and fix with self-tapping screws; - Fit back element (D) onto part (A) and fix. - connect the outlet (E) to the fume exhaust pipe. COMMISSIONING THE APPLIANCE Before commissioning the appliance If you wish to check the nominal capacity further, you...
Note for the installer - Explain and demonstrate to the user how the machine works according to the instructions and hand him this manual. - Remind the user that any structural alterations to the room housing the appliance may affect the combu- stion air supply.
REPLACING PARTS Burner (Fig. 1) Unscrew nozzle (28) and nut (29). Loosen the screws (26) fixing the burner to the chamber. Replace the burner. All parts must be replaced by authorised technicians Thermocouple (38 - Fig. 1) only! To replace the following parts, remove the control panel Unscrew the nipple fixing the thermocouple to the valve, (after unscrewing its fixing screws).
USING THE APPLIANCE Warning! Lighting the pilot burner - Beware of inexpert handling! Press the button (14) and as the same time the piezoelec- - Old and dirty oil or frying fat can represent a real fire tric lighter (12) to light the pilot flame, which can be seen hazard;...
Emptying the tank TAKING CARE OF THE APPLIANCE FREQUENCY OF MAINTENANCE When emptying, check that you have a container large enough to collect all the oil in the tank. Warning! The container should be placed correctly under the drain tap. Never clean the appliance with jets of water, whether It is advisable to filter frying oil and fat daily and to chan- direct or pressurised.
