- Page 1 019_03 07/2007 Instructions for installation, use and maintenance ELECTRIC FRYER KFE1 · KFE2 KFE15 · KFE20 KFE15D · KFE20D OPFE1 · OPFE2 OPFE15 · OPFE20 OPFE15D · OPFE20D © COPYRIGHT 2004 GIGA GRANDI CUCINE SRL...
- Page 2 INDEX Models and dimensions page Technical data Installation instructions Installation Legal and technical requisites Installation Wiring Unipotential Using the appliance Ignition Emptying the bath Cleaning and taking care of the appliance What to do if not using the appliance for a long time What to do if something goes wrong Maintenance WEEE Directive...
- Page 3 Dimensions OPFE1 OPFE15 / OPFE20 400 x 900x 270 400 x 900x 270 / 530 weight approx.50 kg weight approx.59 kg / 62 kg OPFE2 OPFE15D / OPFE20D 600 x 900x 270 800 x 900x 270 / 530 weight approx.95 kg weight approx.109 kg / 120 kg Main switch Pilot lamp (voltage)
- Page 4 Dimensions KFE1 KFE15 / KFE20 400 x 900x 875 400 x 900x 875 weight approx.64,5 kg weight approx.70 kg / 73 kg KFE2 KFE15D / KFE20D 600 x 900x 875 800 x 900x 875 weight approx.104 kg weight approx.120 kg / 131 kg...
-
Page 5: Technical Data
THE APPLIANCE MUST BE INSTALLED BY QUALIFIED PERSONNEL. FRYER Model Dim.: LxWxH Voltage rating Power Lead wire / Section KFE1 400 x 900 x 875 400 V 3N or 230 V 3 7.5 kW 5 x 1.5 mm or 4 x 2.5 mm KFE2... -
Page 6: Installation Instructions
H07 RN-F Warning ! type and its section should be large enough for the ap- MODELS KFE1 KFE15 KFE20 pliance (see "Technical specifications and dimensions", if this model is going to be mounted on its own, it must page 5). -
Page 7: Using The Appliance
USING THE APPLIANCE Warning! CLEANING AND TAKING CARE OF THE MACHINE - Beware of inexpert handling! - Old and dirty oil or frying fat can represent a real fire Warning! hazard; make sure only new oil or frying fat are used each time you start frying. - Page 8 THE 2002/96/EC DIRECTIVE (WEEE): information to users This informational note is meant only for owners of equipment marked with the symbol shown in Fig. A on the adhesive label featuring the tech- nical specifications applied on the actual pro- duct (the label also giving the serial number). This symbol indicates that the product is classified, ac- cording to the regulations in force, as an item of electrical and electronic equipment and conforms to EU Directive...
-
Page 9: Wiring Diagrams
Wiring diagrams KFE1 - KFE15 - KFE20 OPFE1 - OPFE15 - OPFE20 11 12 13 400 V 3N L1 L 2 L 3 N L1 L 2 L 3 230 V 3 Line input terminal board Commutating terminal board Switch... - Page 10 Wiring diagrams KFE2 - KFE15D - KFE20D OPFE2 - OPFE15D - OPFE20D 400 V 3N L1 L 2 L 3 N L1 L 2 L 3 230 V 3 Line input terminal board Commutating terminal board Switch Microswitch Safety contactor Adjusting contactor Adjusting thermostat Safety thermostat...
- Page 11 BLE IF THE INSTRUCTIONS CONTAINED IN THIS MA- NUAL ARE NOT OBSERVED. GIGA GRANDI CUCINE S.r.l. - Via Pisana, 336 - Loc. Olmo - 50018 SCANDICCI (FI) - ITALY - Tel. +39 055 722 33 (11 linee r.a.) - Fax +39 055 7310 056 - www.gigagrandicucine.it - info@gigagrandidicucine.it...
