Overview
Mellanox BX4000 series is a 1U, top-of-rack gateway that provides I/O consolidation on both InfiniBand
and Ethernet. The product supports 10/20/40Gb/S InfiniBand to 1/10Gigabit Ethernet and 2/4/8G Fibre
Channel.
The BX4000 series, a top of the rack gateway, provides LAN and SAN connection to the InfiniBand and 10
Gigabit Ethernet based networks.
The uplink and downlink ports are separated into gateway port groups. Specific uplink ports are assigned
corresponding downlink ports. Each gateway port group is assigned a color to easily associate the uplink
ports to the corresponding downlink ports of the gateway port group.
A10
A12
B13
B11
FC
A1
EN
A11
A13
B12
B10
FC
B1
EN
The Port Numbering Table shows the uplink and downlink ports by color, alpha-numeric id identifying the
IB uplink ports.
Table 1 - MTB 4010B Port Numbering
Gateway
BridgeX
Port Group
Controller
by Color
Number
White
Orange
A20 and B20 are InfiniBand ports.
Mellanox Technologies Inc.
350 Oakmead Parkway, Sunnyvale, CA 94085
Document Number
3054
BX4000 Series Quick Start Guide
Figure 1: MTB 4010 Gateway Port Groups Distinguished by Color
B20
A20
I2C
IOIO
I2C RS232
1 GigE
Gateway Port Group A – BridgeX controller 1 – White
Gateway Port Group B – BridgeX controller 1 – Orange
Uplink
Corresponding Downlink
Ports
1
A20
A10 A11 A12 A13
1
B20
B10 B11 B12

Quick Start Guide

Sys
Fan
PSU 1
PSU 2
Corresponding Downlink
FC Ports
Ethernet Ports
A10 A11 A12
B13
B10 B11 B12
Tel: 408-970-3400
Fax: 408-970-3403
Mellanox
®
BX4010
www.mellanox.com
Rev 1.5

Advertisement

loading

  Related Manuals for Mellanox Technologies BX4000 Series

  Summary of Contents for Mellanox Technologies BX4000 Series

  • Page 1: Quick Start Guide

    Ethernet. The product supports 10/20/40Gb/S InfiniBand to 1/10Gigabit Ethernet and 2/4/8G Fibre Channel. The BX4000 series, a top of the rack gateway, provides LAN and SAN connection to the InfiniBand and 10 Gigabit Ethernet based networks. The uplink and downlink ports are separated into gateway port groups. Specific uplink ports are assigned corresponding downlink ports.
  • Page 2: Gateway Port Groups

    Hybrid CX4 to QSFP cables are supported on both the uplink side and the downlink side. SR and LR mod- ules can be used on the downlink side. CX4 connectors are supported on the uplink side. Rev 1.5 Mellanox Technologies...
  • Page 3: Installation Safety Warnings

    Do not operate the product if the blank cover is not securely fastened or if it is removed. During Lightning - Electrical Hazard During periods of lightning activity, do not work on the equipment or connect or disconnect cables. Rev 1.5 Mellanox Technologies...
  • Page 4: Equipment Installation

    For convenience we will use the terms power side of the gateway to Rev 1.5 Mellanox Technologies...
  • Page 5: Package Contents

    Mellanox ® BX4010 PSU 1 PSU 2 I2C RS232 1 GigE Package Contents The package should include all of the following parts: • BridgeX Gateway • Installation kit for 19” Rack mounting • 2 Power cables Rev 1.5 Mellanox Technologies...
  • Page 6: Installation

    Note: There may be more screws in the kit than are required for installing the gateway. • 4 pan head screws • 2 metal washers • 4 sets of caged nuts and bolts for the mounting plates Rev 1.5 Mellanox Technologies...
  • Page 7 You can choose from two options for mounting the rail slide; one option puts the end of the rail slide even with the end of the gateway and the second Rev 1 Mellanox Technologies...
  • Page 8 Do not tighten the screws just yet. Figure 7: Connecting the Rails Place the bolts for the caged nuts in a convenient location, so as to be easily accessible when you install the gateway into the rails. Rev 1 Mellanox Technologies...
  • Page 9: Cable Installation

    Cables in the bottom row should be inserted up side down in relation to the how the cables are inserted in the top row. Cables, especially long copper cables, can weigh a substantial amount. Make sure that the weight of the cable is supported on its own and not hanging from the gateway. Rev 1 Mellanox Technologies...
  • Page 10: Access And Configuration

    Connect the host PC to the RS-232 port of the MTB4000 series gateway using the supplied cable. Make sure to connect to the RS-232 RJ-45 port of the switch and not to the ETH port. Note: No remote IP connection is available at this stage. Rev 1 Mellanox Technologies...
  • Page 11 Connect the CPU Ethernet port to your local 1Gigabit Ethernet network. Connect any Linux station to the Ethernet. At the prompt enter: telnet 172.22.2.2 The login appears Enter the user name “admin”. Enter the password. Password: admin Rev 1 Mellanox Technologies...
  • Page 12: Change Your Password

    Selection 1 under the config_net brings you to this flow. It will show the current configuration and ask if you want to change it. Configure Host Networking - The current HOST configuration is: NETWORKING=yes NETWORKING_IPV6=no GATEWAY=<IP_ADDRESS> HOSTNAME=<hostname.domainname> Do you want to change this configuration? [y/N]: (Default “No”) Y – will open the following flow: Rev 1 Mellanox Technologies...
  • Page 13: Configure Ip Address

    Do you want to change this configuration? [y/N]: (Default “No”) N - will redirect you to the main menu Y – will show the configuration for DHCP and ask you if you want to save it The used configuration is: DEVICE=eth0 ONBOOT=yes HWADDR=<MAC_ADDRESS> Rev 1 Mellanox Technologies...
  • Page 14 This selection will open section <1> and section <2> one by one with the flows described above. Selection 4 under the configure IP Address brings you to this flow. It will show the current configuration and ask if you want to change it. Exit Exit – will exit from the program Rev 1 Mellanox Technologies...
  • Page 15 FabricIT license to enable all of the available commands and functions. See the FabricIT BXM User Manual for instructions and commands available to manage the switches, and fabric. To access this document, please contact your local Mellanox rep- resentative. Rev 1 Mellanox Technologies...
