Lindy Dual Rail Modular KVM Console Switch User Manual

Dual rail modular kvm console with 15 / 17 / 19 lcd panel
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Dual Rail Modular KVM Console
with 15 / 17 / 19"LCD Panel
User Manual
English
For Installation into a 19" rack it is essential to precisely
follow the installation procedure as described in section
3.1. Install the Console into a Cabinet
of this manual.
Tested to comply with FCC Standards
For Commercial Use Only!
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH
SECOND EDITION (JULY 2008)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dual Rail Modular KVM Console Switch and is the answer not in the manual?

Questions and answers

Related Manuals for Lindy Dual Rail Modular KVM Console Switch

Summary of Contents for Lindy Dual Rail Modular KVM Console Switch

  • Page 1 For Installation into a 19” rack it is essential to precisely follow the installation procedure as described in section 3.1. Install the Console into a Cabinet of this manual. Tested to comply with FCC Standards For Commercial Use Only! © LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH SECOND EDITION (JULY 2008)

  • Page 2: Packing List

    Packing List The complete 15 / 17 / 19” dual rail console for modular KVM switch package consists of: 1U 19” rack mount console • Rail with front and rear bracket x 2 • Blockers x 2 • 1.8 m KVM cable. (HDDB-15 / VGA + PS/2 x 2) •...

  • Page 3: Safety Instructions

    Safety Instructions Please read these safety instructions carefully. Please keep this User’s Manual for later reference. Please disconnect this equipment from the AC outlet before cleaning. Do not use liquid or sprayed detergent for cleaning. Use a moist sheet or cloth for cleaning. It is recommended that for your convenience the equipment is installed near an easily accessible power socket.

  • Page 4: Table Of Contents

    1.2 Benefits ... 4 1.3 Product Specification ... 5 1.3.1 15" Dual Rail Console with Modular KVM Switch Specification ...5 1.4.2 17" Dual Rail Console with Modular KVM Switch Specification ...6 1.4.3 19" Dual Rail Console with Modular KVM Switch Specification ...7 2.

  • Page 5: General Information

    1. General Information The LINDY Dual Rail consoles offer an industrial level input solution to optimize your space utilization by controlling your systems in just 1U. With the unique modular design, you can easily integrate with more than 17 models of KVM switch, with different functions, and expand up to 8 levels of KVM switch.

  • Page 6: Product Specification

    1.3. Product Specification 1.3.1. 15" Dual Rail Console with Modular KVM Switch Specification Model name Number of ports Dimension Package Dimension Net Weight Gross Weight Display Size Panel Type Resolution Capabilities Pixel Pitch Viewing Angle (CR>10) Contrast Ratio Brightness Back Light...

  • Page 7: 17" Dual Rail Console With Modular Kvm Switch Specification

    1.3.2. 17" Dual Rail Console with Modular KVM Switch Specification Model name 17” dual rail console with modular KVM switch Number of ports Dimension 459.6 x 448.3 x 44 mm / 18.1 x 17.6 x 1.7 inches Package Dimension 606 x 551.5 x 230 mm / 23.9 x 21.7 x 9.0 inches Net Weight 13 Kg / 28.7 lbs...

  • Page 8: 19" Dual Rail Console With Modular Kvm Switch Specification

    1.3.3. 19" Dual Rail Console with Modular KVM Switch Specification Model name 19” dual rail console with modular KVM switch Number of ports Dimension 539.6 x 448.3 x 44 mm / 21.2 x 17.6 x 1.7 inches Package Dimension 606 x 551.5 x 230 mm / 23.9 x 21.7 x 9.0 inches Net Weight 13 Kg / 28.7 lbs...

  • Page 9: Panel Controls & Osd Function

    2. Panel Controls & OSD Function Panel Controls Soft power on/off button. Adjacent LED is lit when on Auto Auto-synchronize and scale down display to any valid factory preset timings Press to scroll the function you want to adjust Down Press to scroll the function you want to adjust To access the main menu.

  • Page 10: Brightness

    2.3. Brightness 1. Press Menu 2. Use the Up and Down buttons to scroll to Brightness 3. Press Menu to enter 4. Use the Up and Down buttons to adjust the Brightness of the display 5. Press Menu to enter 2.4.

  • Page 11: Position

    2.6. Position 1. Press Menu 2. Use the Up and Down buttons to scroll to Positioning 3. Press Menu to enter. You will see: Icon Image Pos OSD Pos Return 4. Use the Up and Down buttons to choose which Position you want to change 5.

  • Page 12: Rail With Front And Rear Bracket X

    3. Installation 3.1. Install the Console into a Cabinet 3.1.1. Notes It is essential that each step of this installation guide is completed in the stated order to ensure a successful installation. It is highly recommended that two persons carry out the installation.

  • Page 13: Installing The Console

    Dual Rail Console For Modular KVM Switch User Guide 3.1.3. Installing the Console 1. Adjust the rail with the rear bracket to fit your cabinet 2. Attach the front and rear brackets to your cabinet 3. Repeat steps 1 and 2 for the other side of your cabinet 4.

  • Page 14: Install Modular Kvm Switch

    Hardware Kits Contents 1. Bracket A with thumb screw x 2 2. Screw (length 6 mm) x 4 3.2.2. Install Modular KVM Switch Step 1. Install two screws (length 6mm) to attach Bracket A to the KVM Switch at each side...
  • Page 15 2. From the rear of the cabinet slide the KVM Switch along the rails, until it reaches the console and the thumb screws are aligned to the rear of the cabinet Plastic Rail on KVM Switch 3. Tighten the Thumb Screws of Bracket A, at each side, to fix the position of the KVM...

  • Page 16: Installing The Video Card And Video Driver

    3.3. Installing the Video Card and Video Driver Before connecting the LCD console, make sure your computer has a video card already installed for the monitor. After you connect the console, install the video driver. The video driver is supplied by the video card manufacturer and may be found on the CD-ROM that came with your computer.

  • Page 17: Connecting The Console

    Using two hands, grasp the rear of the console, lift the tab and pull the panel up and forward. This will disengage the momentary on / off switch and the unit should power on. The LED on the left or under of the monitor panel should turn from orange to green, verifying that the unit is operational.

  • Page 18: Kvm Switch

    4. KVM Switch With a unique modular design, you can easily integrate different KVM switch models, with different functions, and expand them up to 8 levels of KVM switch with a total number of up to 128 servers to manage.
  • Page 19 Recht umgesetzt. Dieses Gesetz verbietet vom 24.März 2006 an das Entsorgen von Elektro- und Elektronikgeräten über die Hausmülltonne! B2B Geräte wie dies LINDY LCD Terminal und LINDY 19“ KVM Switches nimmt LINDY kostenlos zurück und führt sie einem geordneten Recycling entsprechend den gesetzlichen Vorgaben zu.
  • Page 20 Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Tested to comply with FCC Standards For Commercial Use Only! 2nd Edition, July 2008 www.lindy.com...
