Lindy 21617 Quick Hardware Installation Manual

Modular lcd console

Advertisement

It is essential that each step of this installation guide
is completed in the stated order to ensure a
It is highly recommended that two persons carry out the installation.
1. Please check the contents of this box against the list below, before installation.
2. Before installation, make sure all peripherals and computer have been turned off.
3. The cabinet depth range must be in 570 ~ 870 mm for the 15" and 17" console or 650 ~
950 mm for the 19" console.
4. Reliable earthing of rack-mounted equipment must always be maintained. Particular
attention should be given to supply connections other than direct connections to the
branch circuit.

Hardware Installation Kits Contents:

1. Rail with front and rear brackets x 2
2. Blocker x 2
Tested to comply with FCC Standards
For Commercial Use Only!
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH
Modular LCD Console
Quick Hardware Installation Guide
successful installation.
3. Screw x 2
4. Screw (length 6mm) x 6
5. Key x 2
-
3rd EDITION (JULY 2012)
