Warning!
Safety Precautions
LINDY LCD Terminal
In order to avoid the risk of fire or electric shock DO NOT expose the
device to liquid or a high humidity environment.
Operate the LCD only at temperatures between +5°C and +45°C.
User Manual
There are no user serviceable parts. Qualified specialists must carry
out repairs only.
The notes and instructions regarding this device must be observed.
This device should always to be placed upon a solid horizontal
surface.
Only clean with neutral cleaning agents and a damp cloth. Do not use
liquid cleaning agents or agents containing abrasives.
To guarantee problem-free operation please ensure that there is
sufficient ventilation to prevent any damage caused by overheating.
Never obstruct or block the ventilation slots or other openings with
objects, and do not position the device in any location where there is
insufficient ventilation.
Features
14.1" 1024 x 768 TFT LCD
VGA, SVGA, and XGA video support.
PS/2 touch pad.
105 keys mechanical switch keyboard
LINDY Art.No. 21510 - 21515
Dimensions: Width 448mm x Height 44mm x Depth 590mm
www.LINDY.com
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (AUG 2002)
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (AUG 2002)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lindy 21510
Summary of Contents for Lindy 21510
- Page 1 105 keys mechanical switch keyboard LINDY Art.No. 21510 - 21515 Dimensions: Width 448mm x Height 44mm x Depth 590mm www.LINDY.com © LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (AUG 2002) © LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (AUG 2002)
-
Page 2: Table Of Contents
User Manual KVM Terminal LCD CONTENTS: CHAPTER 1 KVM Terminal LCD INSTALLATION INSTALLING THE TERMINAL INTO A 19” CABINET...…………… 4 OPENING THE LCD DISPLAY DRAWER……………….…………. CLOSING THE LCD DISPLAY DRAWER….………………….…….. 5 CABLE CONNECTIONS..……………………………………………… 5 CHAPTER 2 LCD DISPLAY VIDEO INPUT PIN ASSIGNMENT……...…..….… THE DISPLAY TIMING…………………………………………………... -
Page 3: Closing The Lcd Display Drawer
User Manual KVM Terminal LCD 3. Carefully lift the LCD display into a suitable viewing position. Now gently slide the drawer back to a comfortable position. CLOSING THE LCD DISPLAY DRAWER 1. To close the drawer – pull the drawer forward, and gently fold down the display. 2. -
Page 4: Display Controls
User Manual KVM Terminal LCD 2-3 The Display Controls Display Controls SWITCH NO. FUNCTION RESET AUTO CONFIG MENU ADJUST (+) ADJUST (-) 1 Reset: Hardware Reset 2 Auto: Auto adjusts the image. 3 Menu: Enter the OSD adjust menu and select the menu. 4 Adjust (+): To scroll up in menu or to increase value of selected item. -
Page 5: Horizontal Position
User Manual KVM Terminal LCD LINE WRITE Test display SCALE UP Don't care EDGE FLITER Adjust the image sharpness MISC FUNC Adjust the image colour OSD ADJUST Set up OSD position and size CONTRAST Sets the contrast of the display BRIGHTNESS Sets the brightness of the display EXIT... -
Page 6: Expand
User Manual KVM Terminal LCD 2-11 Expand The main menu "Expand" is used to adjust display size, select the sub-menu, zoom "In/Out" to adjust the display size from -15 to 15. EXPAND 1 : 1 FULL SCREEN ASPECT RATIO ZOOM IN/OUT RETURN 2-12 Input Select... -
Page 7: Edge Filter
User Manual KVM Terminal LCD 2-17 Edge Filter The main item "Edge Filter" is used to adjust the sharpness of the display. The range of the adjustment is -63 to 63. EDGE FILTER 2-18 MISC FUNC MISC FUNC ADC R GAIN ADC G GAIN ADC B GAIN ADC R OFFSET... -
Page 8: Brightness
(d) Consult the supplier or an experienced radio / TV technician for help. © LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (AUG 2002) FCC Compliance Statement (United States) This equipment has been tested and found to comply with part 15 of FCC rules.
