LINDY 15" & 17" LCD Terminals
User Manual
21540(DE), 21541(IT), 21542(FR), 21543(UK), 21544(CH), 21545(US)
21524(UK), 21526(DE), 21527(IT), 21528(FR), 21529(US), 21519(CH)
Tested to Comply with
FCC Standards
For Commercial Use
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH -
LINDY 17" LCD Terminal No's:
LINDY 15" LCD Terminal No's:
www.LINDY.com
SECOND
EDITION
(APRIL
English
2005)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lindy 21519(CH)
Summary of Contents for Lindy 21519(CH)
- Page 1 21540(DE), 21541(IT), 21542(FR), 21543(UK), 21544(CH), 21545(US) 21524(UK), 21526(DE), 21527(IT), 21528(FR), 21529(US), 21519(CH) Tested to Comply with FCC Standards For Commercial Use © LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - LINDY 17” LCD Terminal No’s: LINDY 15” LCD Terminal No’s: www.LINDY.com SECOND...
-
Page 2: Safety Information
User manual Supplied Items The LCD Terminal package consists of: • 1 x 1U, 19” rack mount console with 17” or 15” LCD screen (according to part number) and 2 locking keys • 1 x 19” mounting kit with screws and multiple rear mounting brackets for mounting to a depth of between 53cm and 100cm •... - Page 3 User manual Features • The LINDY LCD Terminal is designed for use in standard 60cm to 120cm depth, 19” cabinets. It requires a mounting depth of at least 50cm and a distance between front and rear 19” rails of at least 43cm.
- Page 4 Between 68cm and 83.5cm, use long rear L-brackets plus support brackets Note: if you require extended rear L- rackets for longer distances between the front and rear 19” rails (not cabinet depth!), please contact LINDY support. Installing the short rear brackets Please install the brackets and distance washers as per the picture to the right.
-
Page 5: User Manual
User manual Installing the long rear brackets Please select the appropriate brackets according to the distance between your 19” rails ( see Important note on page 3 ) and install them as per the pictures. You will need the front support brackets (A), outer slider brackets (B), inner slider bracket (C)... - Page 6 User manual Mounting the drawer into the cabinet Fix the front 19” brackets of the drawer onto the front side of your 19” cabinet. Fix the screws only to the slider bracket - not to both brackets! Fix the screws on the back of the drawer onto the rear side of your 19” Cabinet. Please note: You can hide the handle of the keyboard drawer inside the drawer.
-
Page 7: Lcd Display
User manual Cable connections 1. Ensure the computer or KVM switch you are connecting to is switched OFF! 2. Use the included ‘3-in-1 2 x PS/2 + 1 x VGA’ cable to connect to the console ports of your computer or KVM switch 3. - Page 8 Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment under FCC Rules. © LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - Canadian Department of Communications RFI statement This equipment does not exceed the class B limits...
