Setting up display settings
Make sure to restart the computer before moving on to the next.
Log into Windows as a user with administrative privileges.
2
Confirm that the PowerDesk-HF icon is added in the taskbar.
Note:
•
It takes about 30 seconds for the icon to appear on the taskbar.
•
When another graphics card coexists, the icon may not appear. In that case, select
the display connected to this card on the Settings tab in the Display Properties
dialog box.
3
Set the resolution and color depth for each display connected to this card by following
the instructions below.
1) Select the Settings tab in the Display Properties dialog box.
Select a display icon, and the Display section shows display and card information.
If it shows "Plug and Play Monitor on Matrox/TOTOKU LV...," it indicates that the
display is connected to this card. If it shows
LV...," it means that there is no display connected.
2) Select a display that is connected to this card and set an appropriate screen
resolution.
Predetermined Resolution
Resolution Landscape
5MP
3MP
Note:
• Make sure "Extend my Windows desktop onto this monitor" is checked.
ENGLISH
Portrait
2048 x 2560 2560 x 2048
1536 x 2048 2048 x 1536
"Default Monitor
Display
ME511L, ME551i2
ME315L, CCL316,
ME351i, CCL350i,
ME355i2, CCL352i2
- 8 -
Windows 2000/XP
on Matrox/TOTOKU
Graphics Card
LV52P1
LV32P1
