FCC Information FCC (U.S. Federal Com mu ni ca tions Com mis sion) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide rea son able protection against harmful in ter fer ence in a res i den tial in stal la tion.
1. Introduction This manual explains how to use this graphics card along with TOTOKU LCD displays. Package contents Confi rm that the package contains the following items. Graphics card LVU2E1 ...1 Driver CD ...1 User’s Manual ...1 Hardware requirements • DOS/V PC or a workstation with an Intel Pentium4- or Athlon64-equivalent processor or higher •...
By default, it is set to portrait. See the display user manual for instructions. Please note that, in setting up LVU2E1 in Display Properties, only choices available for the currently used display orientation will be listed. For instance, when ME551i2 is in portrait orientation, landscape resolutions do not appear in the drop-down menu.
Page 8
Portrait (default) The LED blinks twice. Landscape Connect one end of the DVI cable supplied with the display to LVU2E1 and the other end to the display and tighten the screws on the connectors. Caution Careful not to break the connector pins by trying to insert the DVI connector at an angle.
To use two displays, connect the other display as well. Connecting the power cables Connect all power cables to the wall outlets, including the computer, the display, and other peripheral devices. ENGLISH - 7 -...
3. Software Installation and Setup Follow the instructions below to install the software (display driver) and set it up using the setup program included in the accompanying CD-ROM. See Q&A if any problem occurs. Installing the display driver software Turn on the display and start up the computer. Confi...
Page 11
2) Insert the driver CD in the CD-ROM drive. If the following screen appears, click "Cancel." 3) Double-click Setup.exe in DriverCD/XP2K directory included in the CD-ROM. 4) If the Hardware Installation screen appears, click "Continue Anyway." 5) When the InstallShield Wizard starts up, click "Next." ENGLISH - 9 -...
6) At the end of installation, the InstallShield Wizard Complete screen appears. For those using two displays on Windows 2000, select "No, I will restart my computer later" and click "Finish;" for those using a single display on Windows 2000 and all Windows XP users, select "Yes, I want to restart my computer now"...
Select a display icon, and if the Display section says "Plug and Play monitor on Elza TOTOKU LVU2E1," the corresponding display is connected to LVU2E1. In a multi-display setup, select the icon for the fi rst display on this card and verify "Extend my Windows desktop onto this monitor"...
Page 14
Set a resolution using the Screen resolution slider. Select 32 bit color from the Color quality drop-down menu. Note: "True Color (32bit)" on Windows 2000, "High (32bit)" on Windows XP Click "Advanced," select the Monitor tab, and check the refresh rate (see the table on the previous page).
Portrait orientation on ME201L/ME251i/CCL202/CCL212/CCL250i: To use ME201L, ME251i, CCL202, CCL212, and CCL250i in portrait orientation, follow the instructions below. Note: In a multi-display setup, horizontal span mode is not available (see Chapater 4 for detailed information on multi-display modes). 1) Select Display Properties>Settings(tab). 2) Select a display icon and click "Advanced."...
4. Software Uninstallation Follow the instructions below to uninstall the display driver for LVU2E1. Log into Windwos as a user with administrative privileges. Select Control Panel>Add/Remove Programs from the Start menu. Delete "NVIDIA drivers" from the Currently installed programs list.
Select a desired multi-display mode from the nView Display Mode drop-down menu and click "OK." Note: The nView Display Mode drop-down menu offers only "Single display" when there is only one display connected to LVU2E1. Follow the on-screen prompts and instructions to complete the setup. - 15 -...
6. Q&A Prior to installation What are the supported operating systems? Windows 2000/XP How many displays can this card take? 2 displays per card. What are the supporting TOTOKU displays? See the table below: Pixels ME201L, ME213L, ME251i, CCL202, CCL212, CCL250i ME315L, ME351i, CCL316, CCL350i ME511L, ME551i2, ME551i2 s Note: Displays below 2MP can also be connected.
Page 19
It can happen when a non-NVIDIA card coexists. Remove it once, insert LVU2E1, install and set up the display driver for it. Now remove it, insert the other card in another slot, install and set up a display driver for it. Put LVU2E1 back into the slot where it was inserted.
Page 20
Found New Hardware Wizard. Would it be a problem to use another driver for a coexisting NVIDIA-based card? Yes, use the same driver for it as for LVU2E1. If the other card does not work, contact your dealer. ENGLISH...
Another driver fi le of different version exists. It can happen when the driver is installed by overwriting the old one. Uninstall the old driver completely before installing the new one. Any other measures for multi-display-related problems? Try the followings as preventive measures: •...
Page 22
When another NVIDIA-based card is used, the icon for the second display in Dualview mode on LVU2E1 isn't displayed in Display Properties>Settings. Select "Dualview" from the nView Display Modes drop-down menu in Display Properties>Settings>Advanced>Quadro FX 1500 and restart the computer.
Miscellaneous Gray shades are not displayed properly (discontinuity, non-smoothness). Check the display color setting. Set it to 32 bit color for full 256 shades of gray. Lightning-like noise occurs during switching to portrait orientation using NVRotate. It occurs due to the high-speed drawing by NVRotate. It is not a failure. Can I use any commercially available DVI cable? No, use the DVI cable supplied with the TOTOKU display.
7. Technical Specifi cation Graphics card LVU2E1 Video memory Card type Operating system Max. # of cards # of output connectors Dimensions Max. power consumption 65W Resolutions Color modes Multi-display modes ENGLISH NVIDIA Quadro FX 1500 256MB 256-bit DDR3 SDRAM...
Page 25
TOTOKU Graphics Card LVU2E1 User's Manual August 2006 Edition Notes for this user's manual • No part of this manual, whether partly or wholly, may be reproduced or copied without authorization. • The content of this manual is subject to change without notice.
Page 26
TOTOKU ELECTRIC CO., LTD. 1-3-21 OKUBO, SHINJUKU-KU, TOKYO 169-8543 JAPAN TEL: +81-3-5273-2005 FAX: +81-3-5273-2091 URL: http://www.totoku.com/display/ ENGLISH - 24 -...
Page 37
インストールの完了表示が出たら、 次のようにします。 ・ OS が Windows XP の場合は[Yes, I want to restart my computer now.]を選択し、[Finish] ボタンをクリックして再起動します。 ・ OS が Windows 2000 でディスプレイが 1 台の場合は [Yes, I want to restart my computer now.] を選択し、 [Finish] ボタンをクリックして再起動します。 ・ OS が Windows 2000 でディスプレイが 2 台の場合は [No, I will restart my computer later.]...
