INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE: DO NOT discard this manual!
Model(s):

WOODBURNING FIREPLACE

Installation and service of this fireplace should be
performed by qualified personnel. Hearth & Home
Technologies recommends NFI certified profes-
sionals, or technicians supervised by an
NFI certified professional.
Owner's Manual
Operation and Care
Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other flam-
mable vapors and liquids in the vicinity of this
or any other appliance.
• DO NOT overfire. Overfiring will void your
warranty.
• Comply with all minimum clearances to com-
bustibles as specified. Failure to comply may
cause house fire.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fireplace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other flammable
materials.
• Keep clothing, furniture, draperies and other flammable
materials away.
WARNING
Fire Risk.
For use with solid wood fuel only.
Other fuels may overfire and generate poisonous
gases (i.e. carbon monoxide).
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EM-415 and is the answer not in the manual?

Questions and answers

Summary of Contents for Heat & Glo EM-415

  • Page 1: Woodburning Fireplace

    For use with solid wood fuel only. NFI certified professional. Other fuels may overfire and generate poisonous gases (i.e. carbon monoxide). Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 2: Table Of Contents

    2. Moisture content 3. Seasoning 4. Storing Wood 5. Burning Process 6. Creosote Formation 7. Processed Solid Fuel Firelogs D. First Fire E. Lighting Instructions Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 3: Welcome

    DECORATIVE GAS APPLIANCE IN THE FIREPLACE, CONTACT: HEARTH & HOME TECHNOLOGIES, ADJUST DAMPER TO THE FULLY OPEN POSITION. 7571 215th Street West, Lakeville, MN 55044 Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 4: Limited Lifetime Warranty

    Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645F 02-18-13 Page 1 of 2 Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 5 THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645F 02-18-13 Page 2 of 2 Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 6: Product Specific And General Information

    Heat & Glo is a registered trademark of Hearth & Home Technologies. Warning! Risk of Fire! For use with solid wood fuel only. Other fuels may overfire and generate poisonous gases (i.e. carbon monoxide). Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 7: Important Safety And Operating Information

    48 in. (1219 mm) Clear Space Front of Fireplace 12 in. (305 mm) Clear Space Sides of Fireplace (from the FP opening) Figure 3.1 Clear Space Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 8: Grate

    If doors are left partly open, gas and flame may be drawn out of the fireplace opening. Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 9: General Operating Parts

    WARNING! DO NOT operate fireplace before reading and understanding operating instructions. Failure to operate fire- place according to operating instructions could cause fire or injury. Flue Damper Control Section 2.F. Close Open Open Close Outside Air Kit Control Section 2.I. Figure 3.2 General Operating Parts Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 10: Flue Damper

    CAUTION! Outside air control handle may be warm. Adjust before lighting fire. Figure 3.3 Operating Positions of Bi-fold Doors 4. Fan Kit • Fan kit is optional. • Refer to instructions included with fan kit. Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 11: Fuel

    Hard woods • Douglas Fir • Oak • Pine • Maple • Spruce • Apple • Cedar • Birch • Poplar • Aspen • Alder Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 12: Seasoning

    Doing so • refractory is in place may trap moisture from the ground and impede air • all labels have been removed. circulation. Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 13: Lighting Instructions

    WARNING! Risk of Fire! Keep combustible materials, gasoline and other flammable vapors and liquids clear of the fireplace. DO NOT: • store flammable materials close to the fireplace • use gasoline, lantern fuel, kerosene, charcoal lighter fluid or similar liquids to start or “freshen up” a fire in this fireplace. Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 14: Maintenance And Service

    In the event of a chimney fire, Hearth & Home Tech- nologies recommends replacement of the chimney and inspection of the adjacent structure to the provisions of NFPA Level III inspection criteria. Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 15: Grate

    Frequency: After each ash removal By: Homeowner • Inspect condition of refractory. Replace if crumbly or otherwise deteriorated, or if cracks exceed 1/4 in. (6 mm). Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 16: Troubleshooting

    Add glass doors to slow down air flow. Overdrafting Check for correct vent height; too much vertical height creates overdrafting. Check location of vent termination (refer to chimney assembly section). Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 17: Faqs

    Be sure you have air available for combustion and that your firewood is dry and well seasoned. Build your fires properly and according to the instructions given in op- Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 18 Air register from furnace near fireplace? Doors opening and closing? Outside air Window closed Combustion closed? for start-up? air control Figure 5.1 Factory-built Fireplaces: Troubleshooting Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 19: Reference Materials

    Hearth Filler 30331 Lower Grille Assembly 31679 Grate GR23 Junction Box 21878 Installation Manual 4017-268 Owner’s Manual 4017-267 Additional service parts on following page 1/15 Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 20: Service Parts

    Junction Box Kit Nailing Flange 31190 Qty 4 req Drywall Flange 29238 Refractory Retainer 11847 Qty 3 req Smoke Diverter 30559 Strip Protector 18320 Qty 2 req Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 21 Hearth Filler 30332 Lower Grille Assembly 31680 Grate GR24 Junction Box 21878 Installation Manual 4017-268 Owner’s manual 4017-267 Additional service parts on following page 1/15 Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 22 Qty. 4 req 31190 Drywall Flange 28388 Refractory Retainer Qty. 3 req 11847 Smoke Shield Extension Kit 35397 Strip Protector Qty. 2 req 18320 Touch-up Paint 71479 Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 23: Accessories

    Gasketed Cabinet Style Doors GGD36BK, GGD42BK TK6S, TK7S Louver Trim Kit-Stainless Steel 31683-BS Brushed Stainless Hood (EM-485T only) Gas Inserts Gas Log Sets Gas Log Lighters Wood-burning Inserts Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
  • Page 24: Contact Information

    7216645, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending. Printed in U.S.A. - Copyright 2012 Heat & Glo • EM-415, EM-485T Owners Manual • 4017-267 • Rev D • 01/27/15...
