Disassembly

Removing and Replacing the Battery

22
W220
All batteries can cause property damage and/or bodily injury such as burns if a conductive
material such as jewelry, keys, or beaded chains touch exposed terminals. The conductive
material may complete an electrical circuit (short circuit) and become quite hot. Exercise care
in handling any charged battery, particularly when placing it inside a pocket, purse, or other
container with metal objects.
1. Remove the battery door as described in the procedures.
2. Raise and remove the battery at the direction illustrated in the Figure 6.
Figure 6. Removing the Battery
There is a danger of explosion if the Lithium Ion battery is replaced incorrectly. Replace only
with the same type of battery or equivalent as recommended by the battery manufacturer.
Dispose of used batteries according to the manufacturer's instructions.
