- Page 1 LED Multi-Screen SDI Video Wall - ID# 927 Operation Manual...
- Page 2 Introduction The LED Multi-Screen SDI Video Wall allows SDI sources to be shown on multiple 1366x768 LED panels. Controlled using RS-232 and an IR remote this video wall has a thin bezel that is just 6mm wide, which allows you to clearly see your desired video.
-
Page 3: Remote Control
Remote Control ① POWER: Turn on the power of the monitor. ② POWER OFF: Turn off the power of the monitor. ③ SINGLE: Press this button to switch the output image to single display per monitor. ④ 2x2/3x3/4x4/5x5:Press these buttons to switch the output image to 2x2/3x3/4x/3x2/4x3 or 5x5 displays per image. - Page 4 Using Your LED Display Refer to the owner's manual of any external equipment to be connected. When connecting any external equipment, do not connect any AC power cord to wall outlets until all other connections are completed. 1. Connect all AC power sources. 2.
- Page 5 Using the OSD menu Press [MENU]. Press [▲ / ▼] to highlight an option. Press [◄ / ►] to adjust. Press [OK] to confirm the selection. Picture Menu Press [▲ / ▼] to highlight an option. Press [◄ / ►] to adjust. Press [OK] to confirm the selection.
- Page 6 Setup Menu Press [▲ / ▼] to highlight an option. Press [◄ / ►] to adjust. Press [OK] to confirm the selection. Press [EXIT] to exit menu. Option Description Language Select the OSD display language (English, Traditional Chinese and Simplify Chinese). Standard Set it to ON will allow system to set the setup menu into the default value as indicated in the in the above diagram.
- Page 7 RS-232 Protocol Pin Definition RS-232 IN RS-232 OUT Pin 1 Pin 1 Pin 2 Pin 2 Pin 3 Pin 3 Pin 4 Pin 4 Pin 5 Pin 5 Pin 6 Pin 6 Pin 7 Connect to Pin 8 Pin 7 Connect to Pin 8 Pin 8 Connect to Pin 7...
- Page 8 Connection and Installation...
- Page 9 Prepare the TV / Panel Keep all the parts properly for future installation purpose. 1.Separate the fixed rack from both side To avoid scratch or damage of the panel, it is suggested to place the panel on a • flat table that is covered with soft cotton pad. As show in the diagram 1, remove the screws (x4) from the fixed rack (x2) of both •...
- Page 10 Specifications Screen Size (inches) 47SDI Aspect Ratio 16:9 Contrast Ratio 1400:1 Viewing angle range 178° Panel Resolution 1366*768 Response Time (ms) VIDEO HDMI Compatibility 480p/720p/1080i/1080p HDTV Compatibility Up to 1080P PC Resolution Up to 1920x1080@60 Progressive Scan Video Noise Reduction 3D-Y/C Digital Comb Filter Color Purity Optimizer (3D Color Management)
