- Page 1 23 Inch LCD WVA VGA LCD - ID #963 Operation Manual...
- Page 2 Introduction This monitor is an open frame LCD Panel monitor. It features the VESA plug & play system which allows the monitor to automatically adjust itself to match the frequency of the user's device. Features • High brightness. • Fast response time. •...
- Page 3 Setting up your LCD monitor • Choose a position where the reflection of the light is minimal and away from a window for maximizing the quality of the screen image. • It is important to keep 30cm between the LCD monitor to minimize eye strain.
- Page 4 OSD Control Thanks to the user-friendly design of OSD (On Screen Display), you can adjust your monitor by the keypads in the front of the monitor. Power Switch Power On/Off. Power Indicator Green = normal = power saving = power off. Menu Automatically optimize positions, phase and clock when OSD is not shown.
- Page 5 Signal Connector Signal Signal Signal TMDS Data 2- TMDS Data1- TMDS Data0- TMDS Data2+ TMDS Data1+ TMDS Data0+ TMDS Data1/3 TMDS Data2/4 TMDS Data0/5 Shield Shield Shield TMDS Data4- TMDS Data3- TMDS Data5- TMDS Data4+ TMDS Data3+ TMDS Data5+ TMDS Clock DDC Clock +5V Power Shield...
- Page 6 Notes The OSD disappears several seconds after you stop pressing the buttons while performing an adjustment. Any changes are automatically saved in the memory when the OSD disappears. Turning off the power should be avoided while using the menu. Adjustments for clock, phase and positions are saved for each signal timing.
-
Page 7: Screen Adjustment
Screen Adjustment Primary Directory Secondary Directory Description Colour Contrast Adjust the contrast of the image. Brightness Adjust the brightness of the screen. Colour Adjust Adjust the color of the image. Colour Temp Select the colour Temp. you want. Back R e t u r n t o m a i n m e n u . Image Setting Clock ust the clock pulse of the image. - Page 8 Front View A. 513mm E. 91.5mm B. 291mm F. 297mm C. 563mm D. 337mm...
- Page 9 PC Support Timing Item Resolution H Freq.(kHz) V Freq.(Hz) 604x436@57 26.445 57.386 754x353@61 24.822 59.812 750x365@57 24.408 57.566 680x350@60 23.196 59.477 620x256@50 15.613 50.365 650x215@61 16.013 61.118 650x215@62 16.304 62.229 640x215@63 16.606 63.382 630x215@64 16.800 64.122 640x215@53 15.750 53.030 680x215@57 15.104 57.649 640x400@70...
- Page 10 Specifications Specifications for this Model Model Selection Guide VGA + DVI Screen Size 23" Pixel Pitch(mm) 0.372 x 0.372 Blacklight CCFL x 6 Cell Type APVA Response 16ms Input Mode WXGA Video Frequency Horizontal 30 ~ 60KHZ Video Frequency Vertical 48 ~ 75Hz Colours 16.7M Colors...
