- Page 1 10.4 inch SVGA ID#702 LCD Monitor Operation Manual...
- Page 2 Introduction This is a 10 inch LCD SVGA input monitor for the majority of arcade machines and CNC machinery retrofits. It features the VESA plug & play system which allows the monitor to automatically adjust itself to the match the frequency of the user's device. Features High brightness.
- Page 3 Setting up your LCD monitor Screen Adjustment To enter adjust mode, please refer to the OSD control. Turn the computer and LCD monitor on. Press “Auto” button to start auto adjust. This will start the auto adjust process. This will take approximately 10 seconds.
- Page 4 Panel Controls Green : Power On + Signal Source Detected : Standby or Signal Source Not Detected Off : Power off Power Power On/Off. Up/+ This button is used for positive adjustment when OSD is Displayed Down/- This button is used for negative adjustment when OSD is Displayed Menu This button is used to display the ON...
- Page 5 Adjusting the Image Press the menu button to start the OSD feature. Click the “Up” or “Down” button to select the function to be adjusted. Click the “Menu” button to access into the function to be adjusted. Click the “Up” or “Down” button to change the current setting of the function selected.
- Page 6 OSD Menu Options Menu Auto Setup Automatically optimize positions, phase and clock Brightness Brightness Adjust Screen Brightness Recall Restore to Default Return Exit menu Contrast Adjust the Screen Contrast Display Adjust H Position Adjust the Horizontal Positioning V Position Adjust the Vertical Positioning V Size Adjust the Vertical Screen Size Clock...
- Page 7 OSD Display OSD H-Pos Position the OSD menu horizontally on screen OSD V-Pos Position the OSD menu vertically on screen OSD Timer Set the OSD menu on screen display time Set the OSD menu Transparency Transparency OSD Direction Set the direction of the OSD menu : Normal, Mirror, Left, Right, Up or Down Display Logo...
- Page 8 Support CGA/EGA/VGA Timings Type H. Frequency. V. Frequency Resolution (kHz) (Hz) 15.4 58.8 640x198 15.1 57.6 640x215 15.7 640x215 16.0 640x215 16.3 640x215 16.6 63.4 640x215 16.800 640x215 15.6 50.3 640x265 18.4 640x350 31.469 70.087 640x400 31.469 59.940 640x480 35.000 66.667 640x480 37.861...
- Page 9 Connecting into Option 1 - Using VGA Input Monitor By using a standard VGA 15 pin computer cable plug and play or, alternatively you may cut the end of your cable and wire directly to the output connector of the source equipment. Pin 1 Analog input.
- Page 10 P1 – RGBHV P3 – RGBH+V separate/or combined sync combined sync Pin 1 – Red Pin 1 – Red Pin 2 – Green Pin 2 – Green Pin 3 – Blue Pin 3 – Blue Pin 4 – Signal Earth Pin 4 –...
- Page 11 Filter Jumpers Set Jumpers as required to reduce effect of black line artifacts when low resolution mismatch becomes evident on LCD screen. By setting to “ON” position, each colour can be filtered as required. C1 = Red Colour 1 C2 = Green Colour | To adjust for C3 = Not used | Impedance...
- Page 12 Specifications Specifications for this Model Screen Size 10.4" TFT Pixel Pitch(mm) 0.264 x 0.264 Blacklight 2xCCFL Cell Type Input Mode SVGA Scan Frequency Horizontal 15 ~ 80KHZ Scan Frequency Vertical 48 ~ 75Hz Colours 16.7M Colors Aspect Ratio Horizontal Viewing Angle Full range Optimal Screen Resolution 800 x 600...
- Page 13 Troubleshooting Error Solution No Power Led Check Mains Power supply input Voltage (100v or 240vAC) and connection Check 12V DC at power supply output Check control board for damage No image Check cables connected correctly from source and into monitor inputs Check correct orientation of signal wires;...
