Heatilator EcoChoice ECO-ADV-PS35 Owner's Manual

Pellet burning stoves
Hide thumbs Also See for EcoChoice ECO-ADV-PS35:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual , Owner's Manual Installation and Operation
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions on installation, operation, or service.
NOTICE: DO NOT DISCARD THIS MANUAL
PELLET BURNING STOVES
Model(s):
ECO-ADV-PS35
ECO-ADV-PS50
ECO-CAB50
CAUTION
Tested and approved for wood pellets. Burning of any
other type of fuel voids your warranty.
CAUTION
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and na-
tional codes and regulations.
• Consult local building, fi re offi cials or authorities having juris-
diction about restrictions, installation inspection, and permits.
1
Owner's Manual
Operation & Care
7058-206C
WARNING
If the information in these instruc-
tions is not followed exactly, a
fi re could result causing property
damage, personal injury, or death.
• Do not store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of
this or any other appliance.
• Do not overfi re - If heater or chimney con-
nector glows, you are overfi ring. Overfi ring
will void your warranty.
• Comply with all minimum clearances to
combustibles as specifi ed. Failure to
comply may cause house fi re.
WARNING
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
Hot glass will cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room as
fi replace.
•
Alert children and adults to hazards of high temperatures
•
High temperatures may ignite clothing or other
fl ammable materials.
•
Keep clothing, furniture, draperies and other fl ammable
materials away.
NOTE
To obtain a French translation of this manual, please contact
your dealer or visit www.heatilator.com
Pour obtenir une traduction française de ce manuel, s'il vous
plaît contacter votre revendeur ou visitez www.heatilator.com
05/06/2015

Advertisement

Table of Contents
loading

Related Manuals for Heatilator EcoChoice ECO-ADV-PS35

Summary of Contents for Heatilator EcoChoice ECO-ADV-PS35

  • Page 1 • Consult local building, fi re offi cials or authorities having juris- diction about restrictions, installation inspection, and permits. Pour obtenir une traduction française de ce manuel, s’il vous plaît contacter votre revendeur ou visitez www.heatilator.com 7058-206C 05/06/2015...

  • Page 2: Congratulations

    Hearth & Home Technologies welcomes you to our tradition old-fashioned when it comes to craftsmanship. Each unit of excellence! In choosing a Heatilator appliance, you have is meticulously fabricated and gold and nickel surfaces are our assurance of commitment to quality, durability, and per- hand-fi...

  • Page 3: Table Of Contents

    M. Quick Start Guide ..............11 N. Frequently Asked Questions..........12 Heatilator is a registered trademark of Hearth & Home Technologies. NOTE: Hearth & Home Technologies, manufacturer of this appliance, reserves the right to alter its products, their specifi cations and/or price without notice.

  • Page 4: Warranty Policy

    HEATILATOR ECO-CHOICE WARRANTY Hearth & Home Technologies Inc., on behalf of its hearth brands (“HHT”), extends the following warranty for ECO- CHOICE by heatilator wood and pellet hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: HHT warrantes to the original owner of the HHT appliance at the site of installation, and to any transferree taking own- ership of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance will be free from defects in materials and workmanship at the time of manufacture.
  • Page 5 HEATILATOR ECO CHOICE WARRANTY COVERAGE: HHT authorized dealers is available on th HHT branded websites. the nearest HHT authorized dealer or supplier. Additional service fees may apply if you are seeking warranty service from a dealer other than the dealer from whom you originally purchased the product.

  • Page 6: Listing And Code Approvals

    • Unit must be secured to mobile home structure. C-1482. Note: The appliance is also approved for installation The Heatilator ECO Choice Pellet Heater meets the U.S. Environ- mental Protection Agency’s emission limits for pellet heaters sold into a shop after May 15, 2015.

  • Page 7: Operating Instructions

    HEATILATOR ECO CHOICE User Guide Operating Instructions Fuel Material WARNING • Made from sawdust or wood by-products • Depending on the source material it may have a high or Fire Risk. low ash content. • Do not operate appliance before reading and Higher Ash Content Material understanding operating instructions.

  • Page 8: General Operating Information

    HEATILATOR ECO CHOICE E. General Operating Information Changing to Different Fuel Type 1. Thermostat Calls For Heat • Empty the hopper of the previous fuel The appliance is like most modern furnaces; when the • Thoroughly vacuum hopper before fi lling with the new fuel thermostat calls for heat, your appliance will automatically •...

  • Page 9: Hopper Lid Latch And Hopper Switch

    HEATILATOR ECO CHOICE G. Hopper Lid Latch and Hopper Switch Turn it to the “high” setting by pushing the top of the control switch in and then adjust the thermostat to its 1. Lift up the hopper lid and lock into open position. Now highest setting.

  • Page 10: Fire Characteristics

    HEATILATOR ECO CHOICE I. Fire Characteristics K. Ignition Cycles A properly adjusted fi re with the heat output control switch 1. At the beginning of each ignition cycle, it is normal to see set on “high” has a short active fl ame pattern that extends out some smoke in the fi...

  • Page 11: Quick Start Guide

    HEATILATOR ECO CHOICE M. Quick Start Guide ECO CHOICE QUICK START GUIDE *Before you plug in this appliance, follow these instructions* Remove hang tags from the door glass. Clean the glass. Remove the hardware pack and dessicant bag from the fi rebox area before your fi rst fi re.

  • Page 12: Frequently Asked Questions

    The selector switch on control box may be on the wrong regarding operation and troubleshooting. setting. Refer to the Reference Materials section of our Visit www.heatilator.com to fi nd a dealer. owner’s manual for details. What causes my glass to become dirty?

  • Page 13: Maintenance And Service

    HEATILATOR ECO CHOICE Maintenance and Service A. Proper Shutdown Procedure C. General Maintenance CAUTION 1. Types of Fuel Depending on the type of fuel you are burning will dictate how Shock and Smoke Hazard often you have to clean your fi repot.
  • Page 14 HEATILATOR ECO CHOICE 2. Cleaning Firepot with Cleaning Rod & Firepot 3. Ash Removal from Firebox Clean-Out Tool; • Frequency: Weekly or more frequently depending on • Frequency: Daily or more often as needed ash build-up. • By: Homeowner •...
  • Page 15 HEATILATOR ECO CHOICE 5. Disposal of Ashes 7. Cleaning the Hopper • Frequency: As needed • Frequency: Monthly or after burning 50 bags of fuel • By: Homeowner • By: Homeowner After burning approximately 50 bags of fuel you will need to Ashes should be placed in a metal container with a clean the hopper to prevent sawdust build-up.
  • Page 16 HEATILATOR ECO CHOICE 10. Cleaning the Glass 12. Cleaning Convection Blower - Requires No Lubrication • Frequency: When clear view of the fi repot becomes • Frequency: Yearly or more frequently depending on obscure Dust/Dirt build-up • By: Homeowner •...

  • Page 17: High Ash Fuel Content Maintenance

    HEATILATOR ECO CHOICE D. High Ash Fuel Content Maintenance • Frequency: As needed • By: Homeowner Poor quality pellet fuel, or lack of maintenance, can create conditions that make the fi repot fi ll quickly with ashes and Pellets Back-up in Feed Tube clinkers.

  • Page 18: Troubleshooting Guide

    HEATILATOR ECO CHOICE Troubleshooting Guide With proper installation, operation, and maintenance your appliance will provide years of trouble-free service. If you do experience a prob- lem, this troubleshooting guide will assist a qualifi ed service person in the diagnosis of a problem and the corrective action to be taken.
  • Page 19 HEATILATOR ECO CHOICE Symptom Possible Cause Corrective Action Slow or smoky start-up Dirty exhaust and/or venting system. Check for ash build up in unit, includ- (Cont’d) ing behind rear panels, fi rebox, exhaust blower and venting. Wet fuel / poor quality fuel...
  • Page 20 HEATILATOR ECO CHOICE Symptoms Possible Cause Corrective Action Convection blower fails to #1 snap disc defective. Replace snap disc. start. Blower not plugged in. Check that blower is plugged into wire harness. Blower is defective or object jammed in Replace blower.

  • Page 21: Service Parts Replacement

    HEATILATOR ECO CHOICE Service Parts Replacement A. Convection Blower Replacement 1. Turn down the thermostat, let appliance completely cool and then unplug appliance before servicing. Upper Left 2. The convection blower is located on the fl oor at the rear...

  • Page 22: Exhaust Blower Replacement

    HEATILATOR ECO CHOICE B. Exhaust Blower Replacement Snap Disc #2 - Fuel Delivery Interrupt 1. Turn down the thermostat, let appliance completely cool 1. Turn down thermostat, let appliance cool completely if and then unplug appliance before servicing. running. Then unplug appliance before servicing.

  • Page 23: Igniter Replacement

    HEATILATOR ECO CHOICE Remove Screw E. Baffl e Removal & Replace Shut down the appliance by turning down the thermostat and let the appliance completely cool down. 2. Remove the center baffl e fi rst by using the handle at the top of the baffl...

  • Page 24: Glass Replacement

    HEATILATOR ECO CHOICE F. Glass Replacement 1. Open the door from the appliance by lifting door off of hinge pins and lay on a fl at surface face down. 2. Using a Phillips Head screw driver, remove the 4 brackets and set aside.

  • Page 25: Reference Materials

    HEATILATOR ECO CHOICE Reference Materials  When describing the location of a component, A. Component Functions it is always AS YOU FACE THE FRONT OF THE APPLIANCE. 1. Control Box a. The control box is located on the lower left side of the 2.
  • Page 26 HEATILATOR ECO CHOICE 12. Red Call Light 17. Snap Disc #2 (Fuel Delivery Interrupt) 175°F The red call light is on the side of the junction box, below the Snap disc #2 is located on the center of the convection plenum fuse.

  • Page 27: Component Locations

    HEATILATOR ECO CHOICE B. Component Locations Back of Appliance Heat Output Switch Terminal Block Center 2 Screws for Thermostat Wires Power Outlet Reset Button Figure 27.1 LOCATED BEHIND RIGHT SIDE PANELS Feed Motor LOCATED BEHIND LEFT SIDE PANELS Control Box...

  • Page 28: Exploded Drawings & Service Parts - Ps35

    HEATILATOR ECO CHOICE C. Exploded Drawings & Service Parts - PS35 ECO-ADV-PS35 Service Parts Beginning Manufacturing Date: Apr 2010 Free Standing Pellet Stove Ending Manufacturing Date: Active Part number list on following page. 04/15 7058-206C 05/06/2015...
  • Page 29 HEATILATOR ECO CHOICE ECO-ADV-PS35 Service Parts Beginning Manufacturing Date: Apr 2010 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 30 HEATILATOR ECO CHOICE ECO-ADV-PS35 Service Parts Beginning Manufacturing Date: Apr 2010 Ending Manufacturing Date: Active Snap Disc’s 24.1 24.2 F110F-20 L175F Manual Reset L250F Manual Reset IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers.
  • Page 31 HEATILATOR ECO CHOICE ECO-ADV-PS35 Service Parts Beginning Manufacturing Date: Apr 2010 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.

  • Page 32: Exploded Drawings & Service Parts - Ps50

    HEATILATOR ECO CHOICE D. Exploded Drawings & Service Parts - PS50 ECO-ADV-PS50 Service Parts Beginning Manufacturing Date: Apr 2010 Free Standing Pellet Stove Ending Manufacturing Date: Active Part number list on following page. 04/15 7058-206C 05/06/2015...
  • Page 33 HEATILATOR ECO CHOICE ECO-ADV-PS50 Service Parts Beginning Manufacturing Date: Apr 2010 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 34 HEATILATOR ECO CHOICE ECO-ADV-PS50 Service Parts Beginning Manufacturing Date: Apr 2010 Ending Manufacturing Date: Active Snap Disc’s 24.2 24.1 L250F Manual Reset F110F-20 L175F Manual Reset IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers.
  • Page 35 ECO-ADV-PS50 Service Parts Beginning Manufacturing Date: Apr 2010 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.

  • Page 36: Exploded Drawings & Service Parts - Cab50

    E. Exploded Drawings & Service Parts - CAB50 ECO-CAB50 Service Parts Beginning Manufacturing Date: May 2011 Pellet Cabinet Style Stove Ending Manufacturing Date: Active Part number list on following page. 04/15 7058-206C 05/06/2015...
  • Page 37 ECO-CAB50 Service Parts Beginning Manufacturing Date: May 2011 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 38 Hitch Pin Clip 3/32 Pkg of 10 7000-374/10 Rail, Auto-Clean SRV7034-152 Pull Rod SRV7074-141 Ash Pan Assembly SRV7074-013 Heatilator Logo Pkg of 10 4021-049/10 Latch Backing Plate SRV7058-155 Exhasut Combustion Blower, 70 CFM SRV7000-602 Gasket, Exhaust Combustion Blower 240-0812 Casting, Exhaust Transition...
  • Page 39 ECO-CAB50 Service Parts Beginning Manufacturing Date: May 2011 Ending Manufacturing Date: Active IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor. Hearth and Stocked Home Technologies does not sell directly to consumers. Provide model number and serial number when requesting service parts from your dealer or distributor.
  • Page 40 Hearth & Home Technologies 1445 North Highway Colville, WA 99114 Division of HNI INDUSTRIES Please contact your Heatilator dealer with any questions or concerns. For the number of your nearest Heatilator dealer log onto www.heatilator.com CAUTION DO NOT DISCARD THIS MANUAL...
