Zte MF70 Getting Started

LEGAL INFORMATION

Copyright © 2013 ZTE CORPORATION.
ZTE MF70
All rights reserved.
No part of this publication may be excerpted,
Let's go
reproduced, translated or utilized in any form or
by any means, electronic or mechanical, includ-
Getting started with your device.
ing photocopying and microfilm, without the prior
written permission of ZTE Corporation.
The manual is published by ZTE Corporation.
We reserve the right to make modifications on
print errors or update specifications without prior
notice.
Version No. : R1.0
ZTE CORPORATION
NO. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057

Getting to Know Your Device

Indicator

Appearance

Indicator Status Description
The following figure is only for your reference. Turned on and not
Red solid
The actual product may be different. registered.
Green solid Registered to 2G.
Connected to 2G
Green blinking and data is being
3G
transferred.
Blue solid Registered to 3G.
Connected to 3G
1. microSD Card Slot Blue blinking and data is being
2. RESET Button transferred.
3. SIM/USIM Card Slot
Blue blinking Wi-Fi is Active.
4. USB Connector
Wi-Fi Blue solid WPS is Active.
5. External Antenna Connector
LED off Wi-Fi is off.
6. Front Cover
7. Indicator

Connection Scenario

8. Device Cap
Your device supports multi-clients for surfing on
NOTES:
the Internet at the same time. The following fig-
microSD logo is a trademark of

ure is only for your reference.
SD-3C, LLC.
TIP:
Please use the original external antenna if

With other accessories, such as mobile power
necessary.
and car power adapter, you will be able to supply
power to your device and use it anywhere and
anytime.
3. Close the front cover.

Connecting to Your Device

Installing Your Device

Via USB Connector

1. Open the front cover.
1. Plug the USB connector into the USB port
and make sure it is tightly inserted.
NOTE:
Do not open the front cover rudely so as to avoid
2. The OS detects and recognizes new hard-
the damage of the front cover.
ware and finishes the installation automati-
2. Insert the SIM/USIM card and microSD card.
cally.
NOTE:
If the system does not launch installation auto-
matically, you can run the installation program in
path of My Computer > ZTEMODEM.
3. The WebGUI configuration page will open
automatically, and then the client, your PC,
will connect to your device successfully.

Via Wi-Fi

3. Select the SSID of your device, and then
click Connect.
1. Supply power to your device by connecting
to your PC or using other accessories.
2. Use your normal Wi-Fi application on the cli-
ent to search the available wireless network.
4. Input the password, and then click Connect.
NOTE:
Please set the client to obtain an IP address
automatically referring to the chapter "Configuring
your PC", and then the client will get an IP ad-
dress like "192.168.0.100".
NOTE:
Password may be requested for Wi-Fi connec-
tion. Please check the body of your device to find
the default information after opening the front
cover.
5. Wait a moment, and then the client will con-
nect to your device successfully.

Accessing the Internet

After successfully connecting to your device,
you can access the Internet in the Automatic or
Manual mode. The default mode is Automatic.
Mode Operations
Your device will connect to the
Internet automatically, and your
Automatic
clients can surf on the Internet
directly.
Login the webGUI configura-
tion page, and select Settings >
3G Settings > Network Select
Manual
> WAN Connection Mode >
Manual, click Connect or Discon-
nect.
