Ranger
For use with machines having Code Numbers:
Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However,
your overall safety can be
increased by proper installation
... and thoughtful operation on
your part. DO NOT INSTALL,
OPERATE OR REPAIR THIS
EQUIPMENT WITHOUT READ-
ING THIS MANUAL AND THE
SAFETY PRECAUTIONS CON-
TAINED THROUGHOUT. And,
most importantly, think before
you act and be careful.
• Sales and Service through Subsidiaries and Distributors Worldwide •
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
RETURN TO MAIN MENU
®
305D (CE)
11458, 11459, 11587
EN 60974-1
OPERATORʼS MANUAL
• World's Leader in Welding and Cutting Products •
Copyright © Lincoln Global Inc.
IM971-A
June, 2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RANGER 11458 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lincoln Electric RANGER 11458

Summary of Contents for Lincoln Electric RANGER 11458

  • Page 1 Ranger For use with machines having Code Numbers: Safety Depends on You Lincoln arc welding and cutting equipment is designed and built with safety in mind. However, your overall safety can be increased by proper installation ... and thoughtful operation on your part.

  • Page 2: California Proposition 65 Warnings

    351040, Miami, Florida 33135 or CSA Standard W117.2-1974. A Free copy of “Arc Welding Safety” booklet E205 is available from the Lincoln Electric Company, 22801 St. Clair Avenue, Cleveland, Ohio 44117-1199. BE SURE THAT ALL INSTALLATION, OPERATION, MAINTENANCE AND REPAIR PROCEDURES ARE PERFORMED ONLY BY QUALIFIED INDIVIDUALS.

  • Page 3: Electric Shock Can Kill

    ELECTRIC SHOCK can kill. 3.a. The electrode and work (or ground) circuits are electrically “hot” when the welder is on. Do not touch these “hot” parts with your bare skin or wet clothing. Wear dry, hole-free gloves to insulate hands.
  • Page 4 WELDING and CUTTING SPARKS can cause fire or explosion. 6.a. Remove fire hazards from the welding area. If this is not possible, cover them to prevent the welding sparks from starting a fire. Remember that welding materials from welding can easily go through small cracks and openings to adjacent areas.
  • Page 5 PRÉCAUTIONS DE SÛRETÉ Pour votre propre protection lire et observer toutes les instruc- tions et les précautions de sûreté specifiques qui parraissent dans ce manuel aussi bien que les précautions de sûreté générales suivantes: Sûreté Pour Soudage A LʼArc 1. Protegez-vous contre la secousse électrique: a.
  • Page 6 SAFETY            - Drive engine Moteur / Motoren Make : Net installed power : Rated speed : r.p.m...

  • Page 7: The Lincoln Electric Company

    THE LINCOLN ELECTRIC COMPANY EC DECLARATION OF CONFORMITY Manufacturer and technical documentation holder: Address: EC Company: Address: Hereby declare that machine: Sales code: Is in conformity with Council Directives and amendments: Standards: Notified body (for 2000/14/EC Conformity): Address: Guaranteed sound power level:...
  • Page 8 2004/108/EC. It was manufactured in conformity with a national standard that implements a harmonized standard: EN 60974-10 Electromagnetic Compatibility (EMC) Product Standard for Arc Welding Equipment. It is for use with other Lincoln Electric equipment. It is designed for industrial and professional use. Introduction All electrical equipment generates small amounts of electromagnetic emission.
  • Page 9 viii viii SAFETY Electromagnetic Compatibility (EMC) The size of the surrounding area to be considered will depend on the structure of the building and other activities that are taking place. The surrounding area may extend beyond the boundaries of the premises. Methods of Reducing Emissions Mains Supply Welding equipment should be connected to the mains supply according to the manufacturer’s recommenda-...
  • Page 10 Electric for advice or information about their use of our products. We respond to our customers based on the best information in our posses- sion at that time. Lincoln Electric is not in a position to warrant or guarantee such advice, and assumes no liability, with respect to such infor- mation or advice.

  • Page 11: Table Of Contents

    Electrical Connections ...A-4 Machine Grounding ...A-4 Welding Terminals ...A-5 Welding Output Cables ...A-5 Cable Installation...A-5 Auxiliary Power ...A-5 Standby Power Connections ...A-5 Connection of Lincoln Electric Wire Feeders...A-6,A-7 ________________________________________________________________________________ Operation...Section B Safety Precautions ...B-1 General Description...B-1 For Auxiliary Power ...B-1 Engine Operation...B-1 Break in Period ...B-1...
  • Page 12 Fuel ...D-4 Bleeding the Fuel System ...D-4 Fuel Filter ...D-5 Engine Adjustment ...D-5 Battery Maintenance ...D-5 Servicing Optional Spark Arrestor ...D-5 Welder / Generator Maintenance ...D-6 Storage ...D-6 Cleaning...D-6 Brush Removal and Replacement ...D-6 ________________________________________________________________________ Troubleshooting ...Section E How to Use Troubleshooting Guide...E-1 Troubleshooting Guide...E-2 thru E-6...

  • Page 13: Installation

    (12 KW) Kubota Net intermittent D722 3000 RPM naturally aspirated water cooled Diesel engine RATED OUTPUT @ 40° C (104° F) - WELDER Welding Process Current/Voltage/Duty Cycle DC Constant Current DC Pipe Current ® Touch-Start DC Constant Voltage RATED OUTPUT @ 40° C (104° F) - GENERATOR...

  • Page 14: Safety Precautions

    HIGH TEMPERATURE OPERATION At temperatures above 40°C,welder output derating is neces- sary. For maximum output ratings, derate the welder output 2 volts for every 10°C above 40°C. Cold weather starting: With a fully charged battery and the proper oil, the engine should start satisfactorily down to about -15°C...

  • Page 15: Towing

    45 ltr.ʼs (12 Gal.ʼs). NOTE: A fuel shut off valve is located on the pre- filter/sediment filter. Which should be in the closed position when the welder is not operated for extended periods of time. ------------------------------------------------------------------------ RANGER®...

  • Page 16: Battery Connections

    To prevent dangerous electric shock, other equipment to which this engine driven welder supplies power must: • Be grounded to the frame of the welder using a grounded type plug. • Be double insulated. • Do not ground the machine to a pipe that carries explosive or combustible material.

  • Page 17: Welding Terminals

    When this welder is mounted on a truck or trailer, its frame must be electrically bonded to the metal frame of the vehicle. Use a #8 or larger copper wire connected between the machine grounding stud and the frame of the vehicle.

  • Page 18: Connection Of Lincoln Electric Wire Feeders

    • Shut the welder off. • For electrode Positive, connect the electrode cable to the "+" terminal of the welder and work cable to the "-" terminal of the welder. For electrode Negative, connect the electrode cable "-" terminal of the welder and work cable to the "+"...
  • Page 19 INSTALLATION Connection of LN-742 and Cobramatic to RANGER® 305D (CE). • Shut the welder off. • Connect per instructions on the appropriate connec- tion diagram in Section F. RANGER® 305D (CE)

  • Page 20: Operation

    • Insulate yourself from work and ground. • Always wear dry insulating gloves. • Always operate the welder with the hinged door closed and the side panels in place. • Read carefully the Safety Precautions page before operating this machine. Always follow...
  • Page 21 OUTPUT CONTROL of the REMOTE. Example: When the OUTPUT CONTROL on the welder is set to 200 amps the current range on the REMOTE CONTROL will be 40-200 amps rather than the full 40-300 amps. Any current range that is less than the full range provides finer current resolution for more fine tuning of the output.

  • Page 22: Engine Controls

    4. ARC CONTROL : The ARC CONTROL dial is active in the CV-WIRE, CC-STICK and DOWNHILL PIPE modes, and has different functions in these modes. This control is not active in the TIG mode. CC-STICK mode: In this mode, the ARC CONTROL dial sets the short circuit current (arc-force) during stick welding to adjust for a soft or crisp arc.
  • Page 23 15. ELECTRIC FUEL GAUGE- rate, reliable indication of how much fuel is in the tank. 16. ENGINE HOUR METER time that the engine has been running. This meter is useful for scheduling prescribed maintenance. 17. ENGINE PROTECTION LIGHT- indicator light for Low Oil Pressure and/or Coolant Over Temperature.

  • Page 24: Welder Operation

    WELDER OPERATION DUTY CYCLE Duty Cycle is the percentage of time the load is being applied in a 10 minute period. For example a 60% duty cycle, represents 6 minutes of load and 4 minutes of no load in a 10 minute period.

  • Page 25: Wire Welding-Cv

    When in the TOUCH START TIG mode and when a Amptrol is connected to the 6-pin Connector the OUT- PUT dial is used to set the maximum current range of the CURRENT CONTROL of the Amptrol. The ARC CONTROL is not active in the TIG mode. The RANGER®...

  • Page 26: Accessories

    400 amps, 100% duty cycle. K857 (7.6m) 25 ft. or K857-1 (30.4m) 100 ft. REMOTE CONTROL - Portable control provides same dial range as the output control on the welder. Has a convenient 6 pin plug for easy connection to the welder.

  • Page 27: Maintenance

    SAFETY PRECAUTIONS WARNING • Have qualified personnel do all maintenance and troubleshooting work. • Turn the engine off before working inside the machine or servicing the engine. • Remove guards only when necessary to perform maintenance and replace them when the maintenance requiring their removal is complete.

  • Page 28: Engine Oil Change

    • Locate oil drain hose and valve in bottom of base and pull through the hole in the battery access panel on the welder. • Remove the cap from the drain valve. Push valve in and twist counterclockwise. Pull to open and drain the oil into a suitable container for disposal.
  • Page 29 MAINTENANCE RANGER® 305D (CE)

  • Page 30: Cooling System

    It is recommended that the fuel shutoff valve be closed during periods of non-use. The Kubota D722 engine supplied with this welder is equipped with an automatic bleeding mechanism that helps purge the air from the mechanical fuel pump system.

  • Page 31: Fuel Filter

    CONNECTING A BATTERY CHARGER — remove battery from welder by disconnecting negative cable first, then positive cable and bat- tery clamp. When reinstalling, connect negative cable last. Keep well ventilated.

  • Page 32: Welder / Generator Maintenance

    WARNING • Service and Repair should only be performed by Lincoln Electric Factory Trained Personnel. Unauthorized repairs performed on this equip- ment may result in danger to the technician and machine operator and will invalidate your factory warranty.

  • Page 33: Troubleshooting

    HOW TO USE TROUBLESHOOTING GUIDE Service and Repair should only be performed by Lincoln Electric Factory Trained Personnel. Unauthorized repairs performed on this equipment may result in danger to the technician and machine operator and will invalidate your factory warranty. For your safety and to avoid Electrical Shock, please observe all safety notes and precautions detailed throughout this manual.

  • Page 34: Troubleshooting

    Observe all Safety Guidelines detailed throughout this manual PROBLEMS (SYMPTOMS) Major Physical or Electrical Damage is Evident. Engine will not "crank". Engine will "crank" but not start. Engine shuts down shortly after starting. If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
  • Page 35 3. Faulty engine alternator or charg- er module. Consult authorized Engine Service Shop. 1. Idler switch in High idle position. Set switch to Auto. 2. External load on welder or auxil- iary power. Remove all external loads. 3. Faulty PC board or idler sole- noid.
  • Page 36 Observe all Safety Guidelines detailed throughout this manual PROBLEMS (SYMPTOMS) Engine will not go to high idle when using auxiliary power. Engine will not go to high idle under weld or auxiliary loading. Engine does not develop full power. Engine runs rough. Engine will not go to high idle when attempting to weld or using auxil- iary power.
  • Page 37 2. Faulty connections to auxiliary receptacles. Check connections. 3. RCD tripped. Clear any ground fault and reset RCD circuit by pressing "Reset" button. 4. Faulty PC board or welder alterna- tor. CAUTION RANGER® 305D (CE) RECOMMENDED COURSE OF ACTION...
  • Page 38 Observe all Safety Guidelines detailed throughout this manual PROBLEMS (SYMPTOMS) The welding arc is “cold.” The weld- ing arc is not stable or is not satis- factory. the engine runs normally. The auxiliary power is normal. If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
  • Page 39 DIAGRAMS RANGER® 305D (CE)
  • Page 40 DIAGRAMS RANGER® 305D (CE)
  • Page 41 DIAGRAMS RANGER® 305D (CE)
  • Page 42 DIAGRAMS RANGER® 305D (CE)
  • Page 43 DIAGRAMS RANGER® 305D (CE)
  • Page 44 DIAGRAMS RANGER® 305D (CE)
  • Page 45 DIAGRAMS RANGER® 305D (CE)

  • Page 46: Dimension Print

    DIMENSION PRINT RANGER® 305D (CE)
  • Page 47 NOTES RANGER® 305D (CE)
  • Page 48 NOTES RANGER® 305D (CE)
  • Page 49 NOTES RANGER® 305D (CE)
  • Page 50 • WARNING • Spanish • AVISO DE PRECAUCION • French • ATTENTION • German • WARNUNG • Portuguese • ATENÇÃO • Japanese Chinese Korean Arabic READ AND UNDERSTAND THE MANUFACTURER’S INSTRUCTION FOR THIS EQUIPMENT AND THE CONSUMABLES TO BE USED AND FOLLOW YOUR EMPLOYER’S SAFETY PRACTICES. SE RECOMIENDA LEER Y ENTENDER LAS INSTRUCCIONES DEL FABRICANTE PARA EL USO DE ESTE EQUIPO Y LOS CONSUMIBLES QUE VA A UTILIZAR, SIGA LAS MEDIDAS DE SEGURIDAD DE SU SUPERVISOR.
  • Page 51 Keep your head out of fumes. Turn power off before servicing. • • Use ventilation or exhaust to • remove fumes from breathing zone. Los humos fuera de la zona de res- • Desconectar el cable de ali- • piración. mentación de poder de la máquina Mantenga la cabeza fuera de los •...
  • Page 52 • World's Leader in Welding and Cutting Products • • Sales and Service through Subsidiaries and Distributors Worldwide • Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com...
