For use with machines having Code Numbers:
Safety Depends on You
Lincoln arc welding and cutting
equipment is designed and built
with safety in mind. However, your
overall safety can be increased by
proper installation ... and thought-
ful operation on your part. DO
NOT INSTALL, OPERATE OR
REPAIR THIS EQUIPMENT
WITHOUT
READING
THIS
MANUAL AND THE SAFETY
PRECAUTIONS CONTAINED
THROUGHOUT. And, most
importantly, think before you act
and be careful.
• Sales and Service through Subsidiaries and Distributors Worldwide •
Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com
RETURN TO MAIN MENU
PRO-CUT
10571, 10572, 10475, 10476, 10586 and 10587
11011, 11012, 11013, 11014, 11015 and 11016
OPERATOR'S MANUAL
• World's Leader in Welding and Cutting Products •
55
TM
Copyright © 2005 Lincoln Global Inc.
IM637-A
March, 2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO-CUT IM637-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lincoln Electric PRO-CUT IM637-A

Summary of Contents for Lincoln Electric PRO-CUT IM637-A

  • Page 1 PRO-CUT For use with machines having Code Numbers: Safety Depends on You Lincoln arc welding and cutting equipment is designed and built with safety in mind. However, your overall safety can be increased by proper installation ... and thought- ful operation on your part. DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT WITHOUT...

  • Page 2: Electric Shock Can Kill

    WARNING PROTECT YOURSELF AND OTHERS FROM POSSIBLE SERIOUS INJURY OR DEATH. KEEP CHILDREN AWAY. PACEMAKER WEARERS SHOULD CONSULT WITH THEIR DOCTOR BEFORE OPERATING. Read and understand the following safety highlights. For additional safety information it is strongly recommended that you pur- chase a copy of “Safety in Welding &...
  • Page 3 4.g. Sparks and spatter are thrown from the plasma arc. Wear safety glasses, ear protection and oil free protective garments such as leather gloves, heavy shirt, cuffless trousers, high shoes and a cap over your hair. Wear ear plugs when cutting or gouging out of position or in confined places.
  • Page 4 NOTES...
  • Page 5 PRÉCAUTIONS DE SÛRETÉ Pour votre propre protection lire et observer toutes les instructions et les précautions de sûreté specifiques qui parraissent dans ce manuel aussi bien que les précautions de sûreté générales suiv- antes: Sûreté Pour Soudage A L’Arc 1. Protegez-vous contre la secousse électrique: a.
  • Page 6 The code number is especially important when identifying the correct replacement parts. - Register your machine with Lincoln Electric either via fax or over the Internet. • For faxing: Complete the form on the back of the warranty statement included in the literature packet accompanying this machine and fax the form per the instructions printed on it.

  • Page 7: Table Of Contents

    Installation ...Section A Technical Specifications ...A-1 Safety Precautions...A-2 Select Proper Location ...A-2 Stacking ...A-2 Lifting and Moving...A-2 Tilting ...A-2 High Frequency Interference Protection ...A-2 Input Electrical Connections ...A-3 Power Input Connection for 208/230/460 Volt Machines...A-3 Power Input Connection for 200/380-415 Volt Machines ...A-3 Input Power Cord Connector Installation ...A-3 Cord Removal ...A-3 Cord Installation ...A-3...
  • Page 8 Maintenance ...Section D Safety Precautions ...D-1 Input Filter Capacitor Discharge Procedure ...D-1 Routine Maintenance...D-2 Periodic Maintenance ...D-2 Troubleshooting ...Section E Safety Precautions...E-1 How to Use Troubleshooting Guide...E-1 Troubleshooting Guide ...E-2 Wiring Diagrams ...Section F Wiring Diagram ...F-1 thru F-4 Dimension Print...F-5 Parts List ...P309 Series &...

  • Page 9: Installation

    TECHNICAL SPECIFICATIONS - PRO-CUT 55 THREE PHASE Standard Input Current Voltage at Rated Output 208/230/460 31/28/17 200/380-415 30/17/16 460/575 17/14 Duty Cycle 50% Duty Cycle 100% Duty Cycle Current Range 25-60 Amps REQUIRED GAS FLOW RATE 70 PSI @ 360 SCFH ( 4.8 Bar.

  • Page 10: Safety Precautions

    SAFETY PRECAUTIONS Read entire Installation Section before installing the PRO-CUT 55. WARNING ELECTRIC SHOCK CAN KILL. • Only qualified personnel should install this machine. • Turn the input power OFF at the disconnect switch or fuse box and discharge input capacitors before working inside the equip- ment.

  • Page 11: Input Electrical Connections

    INPUT ELECTRICAL CONNECTIONS Before installing the machine, check that input supply voltage, phase, and frequency are the same as the machine's voltage, phase, and frequency as specified on the machine's rating plate. The Pro-Cut 55 should be connected only by a quali- fied electrician.

  • Page 12: Frame Grounding

    2. If the ground screw assembly is loose, tighten the assembly to the base before installing the new ground lead. Install the green lead on the ground screw assembly, replace the plain washer and lock washer, then tighten nut. Install in accordance with all local and national electrical codes.

  • Page 13: Gas Input Connections

    GAS INPUT CONNECTIONS Supply the PRO-CUT 55 with clean compressed air or nitrogen. • Supply pressure must be between 80 psi and 150 psi. • Pressure guage, located on the front of the machine, should be set to approximately 70 PSI for a 25 ft. torch and 75 PSI for a 50 ft.

  • Page 14: Operation

    SAFETY PRECAUTIONS Read and understand this entire section before oper- ating the machine. WARNING ELECTRIC SHOCK can kill. • Do not touch electrically live parts or electrode with skin or wet clothing. • Insulate yourself from work and ground. • Always wear dry insulating gloves.

  • Page 15: User Responsibility

    USER RESPONSIBILITY Because design, fabrication, erection and cutting vari- ables affect the results obtained in applying this type of information, the serviceability of a product or struc- ture is the responsibility of the user. Variation such as plate chemistry, plate surface condition (oil, scale), plate thickness, preheat, quench, gas type, gas flow rate and equipment may produce results different than those expected.

  • Page 16: Cutting Capability

    CUTTING CAPABILITY The PRO-CUT 55 is rated at 55 amps, at 50% duty cycle on a 10 minute basis (runs 55 amps for 5 minutes, then idling for 5 minutes) or 40 amps, at 100% duty cycle (continuous use). If the duty cycle is exceeded, a thermal protector will shut off the output of the machine until it cools to the normal operating temperature.

  • Page 17: Limitations

    LIMITATIONS Do not exceed output current and duty cycle rating of machine. Do not use the PRO-CUT 55 for pipe thaw- ing. CONTROLS AND SETTINGS Status Reset Purge Board Button Button Indicators XXXX XXXX XXXX XXXX XXXX XXXX XXXX XXXX Output Control Knob...

  • Page 18: Safety Led

    • Hold the nozzle standoff 1/8” (3.2mm) to 3/16” (4.7mm) above the workpiece during cutting. Do not let the torch nozzle touch the work or carry a long arc. • Keep moving while cutting. Cut at a steady speed without pausing. Maintain the cutting speed so that the arc leg is 10°...

  • Page 19: Pilot Arc Discussion

    PILOT ARC DISCUSSION The PRO-CUT has a smooth, continuous pilot arc. The pilot arc is only a means of transferring the arc to the workpiece for cutting. Repeated pilot arc starts, in rapid succession, is not recommended as these starts will generally reduce consumable life.

  • Page 20: Suggestions For Extra Utility From The Pro-Cut System

    Suggestions for Extra Utility from the PRO-CUT System: WARNING ELECTRIC SHOCK CAN KILL. • Turn off machine at the disconnect switch on the front of the machine before tightening, cleaning or replacing consumables. ---------------------------------------------------------------------------- 1. Occasionally an oxide layer may form over the tip of the electrode, creating an insulating barrier between the electrode and nozzle.

  • Page 21: Accessories

    ALWAYS USE GENUINE LINCOLN ELECTRIC ELECTRODES AND VORTECH™ NOZZLES • Only Genuine Lincoln Electric consumables yield the best cutting performance for the PRO-CUT 55. • The patented VORTECH™ nozzle provides an extra “kick” of swirl as the arc exits the nozzle which improves cutting performance.

  • Page 22: Maintenance

    INPUT FILTER CAPACITOR DISCHARGE PROCEDURE 1. Turn off input power or disconnect input power lines. 2. Remove the 5/16" hex head screws from the side and top of the machine and remove wrap-around machine cover. 3. Be careful not to make contact with the capacitor terminals that are located on the top and bottom of the Power Board on the right side of the machine.

  • Page 23: Routine Maintenance

    ROUTINE MAINTENANCE 1. Keep the cutting or gouging area and the area around the machine clean and free of combustible materials. No debris should be allowed to collect which could obstruct air flow to the machine. 2. Every 6 months or so, the machine should be cleaned with a low pressure airstream.

  • Page 24: Troubleshooting

    HOW TO USE TROUBLESHOOTING GUIDE Service and Repair should only be performed by Lincoln Electric Factory Trained Personnel. Unauthorized repairs performed on this equipment may result in danger to the technician and machine operator and will invalidate your factory warranty. For your safety and to avoid Electrical Shock, please observe all safety notes and precautions detailed throughout this manual.
  • Page 25 Observe all Safety Guidelines detailed throughout this manual PROBLEMS (SYMPTOMS) No Status indicators light and the fan does not operate 5 seconds after the power switch is turned on. No Status indicators light 5 seconds after the power switch is turned on, but the fan operates.

  • Page 26: Wiring Diagrams

    Observe all Safety Guidelines detailed throughout this manual PROBLEMS (SYMPTOMS) The Pro-Cut powers up properly but there is no response when the trig- ger is pulled and only the POWER LED is lit. If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
  • Page 27 Observe all Safety Guidelines detailed throughout this manual PROBLEMS (SYMPTOMS) When the trigger is pulled air begins to flow, but there is no pilot arc after at least 3 seconds. The air begins to flow and there is a very brief arc that snaps out consis- tently with repeated trigger pulls.
  • Page 28 Observe all Safety Guidelines detailed throughout this manual PROBLEMS (SYMPTOMS) Pilot arc starts but will not transfer when brought near work. If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your Local Lincoln Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
  • Page 29 Observe all Safety Guidelines detailed throughout this manual SYMPTOM Machine is unresponsive immediately after power-up. The Air Low LED is lit The Safety LED is flashing The Safety LED is lit and steady The Thermal LED is lit The “Ready”, “Air Low” and “Thermal” LED’s are flashing TROUBLESHOOTING STATUS BOARD INDICATORS...

  • Page 30: Troubleshooting E

    • After verifying that the torch and consumables are properly set in place. NOTE: Make sure that consumables are Lincoln Electric brand consumable parts. These parts are patented and using any other replacement consumables may cause damage to the torch or reduce cut quality. Also be sure to check that the nozzle is the correct part number (as identified on the top and side of the nozzle) or the Pro-Cut being used.
  • Page 31 DIAGRAMS MACHINE FRONT xxxxxxx ELEC MACHINE REAR PRO-CUT 55...
  • Page 32 DIAGRAMS PRO-CUT 55...
  • Page 33 DIAGRAMS MACHINE FRONT xxxxxxx ELEC MACHINE REAR PRO-CUT 55...
  • Page 34 DIAGRAMS MACHINE FRONT xxxxxxx ELEC MACHINE REAR PRO-CUT 55...
  • Page 35 DIAGRAMS PRO-CUT 55...
  • Page 36 NOTES PRO-CUT 55...
  • Page 37 NOTES PRO-CUT 55...
  • Page 38 ● WARNING ● Spanish ● AVISO DE PRECAUCION ● French ● ATTENTION ● ● German WARNUNG ● Portuguese ● ATENÇÃO ● Japanese Chinese Korean Arabic ● ● ● ● ● ● ● ● ● ●...
  • Page 39 ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● ● Spanish ● PRECAUCION French ● ATTENTION ● German WARNUNG Portuguese ● ● Japanese Chinese Korean Arabic WARNING AVISO DE ATENÇÃO...
  • Page 40 • World's Leader in Welding and Cutting Products • • Sales and Service through Subsidiaries and Distributors Worldwide • Cleveland, Ohio 44117-1199 U.S.A. TEL: 216.481.8100 FAX: 216.486.1751 WEB SITE: www.lincolnelectric.com...
