Assembly & Set-Up
Contents of Crate
• One Jet Sweep Blower
• One Jet Sweep Operator's Manual
Blower Set-Up
Attaching the Upper Handle
1. Remove the carriage screws and star knobs from the upper
holes in the lower handle. See Fig. 3-1.
2. Place the upper over the lower handle, aligning the upper
holes/metal tabs in the upper handle with the upper holes/
lower holes in the lower handle. See Fig. 3-2.
3. Secure with the carriage screws and star knobs removed
earlier. See Fig. 3-2.
6
• One Upper Handle
• One Honda Engine Operator's
Manual
• One Chute Attachment
• One Bottle of Engine Oill
Figure 3-1
Figure 3-2
3
