Removing Unit From Carton
Assemble The Unit
1 1
2
Remove all contents from
Insert the upper blower
carton.
tube into the blower outlet
and turn it clockwise until
it locks into place.
Assemble The Unit
Starting The Unit
Primer
Bulb
10 X
5
1 6
Place the unit on a level
Press the primer bulb 10
surface. Fill the fuel tank.
times, or until fuel is visible.
Starting The Unit
1 8
9
Crouch in the starting
Squeeze and hold the
position.
throttle for all further steps.
Starting The Unit
3-5 X
12
1 13
Continue to squeeze the
Continue to squeeze the
trigger. Pull the rope 3-5
trigger, or press down the
times to start the engine.
cruise control, and allow the
unit to warm up for 30-60
seconds.
IMPORTANT: READ OPERATOR'S MANUAL THOROUGHLY AND FOLLOW THE SAFE OPERATION PRACTICES WHILE OPERATING THE UNIT.
NEED HELP?
769-07543 P00
All manuals and user guides at all-guides.com
Operator's Manual
50:1
1 Gallon
2.6 oz
3
4
Install the lower blower tube
Mix thoroughly in a separate
onto the upper blower tube
fuel can:
and turn it clockwise until it
– 2.6 fl. oz. of 2-cycle
locks into place.
engine oil
– 1 gallon of unleaded
gasoline
NOTE: Do not mix directly in
the fuel tank.
Choke Lever
7
Move the choke lever to
Position 1.
5 X
11
10
Move the choke lever to
Pull the rope 5 times.
Position 2.
Call 1-877-282-8684
DIDN'T START?
Repeat the starting instructions.
IF engine fails to start after 2 attempts,
14
move choke lever to position 3 and pull
the starter rope until engine starts
Continue to squeeze the
trigger. Move the choke
IF unit still fails to start, refer to the
lever to Position 3. Warm
operator's manual for additional starting
the unit for an additional 60
and troubleshooting information
seconds. The unit may be
used during this time.
CALL 1-877-282-8684 IN U.S. OR 1–800–668–1238 IN CANADA
Tools Required:
• Flathead Screwdriver
Handle
On/Off Stop Control
Cruise Control
Spark Plug
Upper Blower Tube
Lower Blower Tube
Primer Bulb
Lower Vacuum Tube
Need Help?
BV228 EC
2-Cycle
Electric Start Capable
Handheld Blower / Vacuum
Trigger
Air Filter
Cover
Starter Rope
Choke Lever
Muffler
Cover
Fuel Cap
Upper Vacuum Tube
Vacuum Elbow
Vacuum Bag Strap
Cinch Strap
Vacuum Bag
Zipper
01/12
