Page 1: User Manual
REACH HD Decoder DEC1000 User Manual V1.5 2012-01 Copyright© Shenzhen Reach IT Co., Ltd. - Page 2 Copyright© Shenzhen Reach IT Co., Ltd. 2011. All rights reserved. Any part of this document, including the text, image and graph, is the property of Shenzhen Reach IT Co., Ltd. No part of this document shall be copied in any means without the prior written consent of Shenzhen Reach IT Co., Ltd.
- Page 3 , Reach, REACH, , Reach Software, Beyonsys™ and Powolive™ are the trademarks of Shenzhen Reach IT Co., Ltd. Windows, Windows 95, Windows 98, Windows NT, Windows 2000, Windows 2003, Windows XP and Windows 7 are the trademarks of Microsoft. Other trademarks are the properties of their respective owners.
-
Page 4: Table Of Contents
Button function introduction of the remote controller ........7 2.2.2 Network parameter setting ................8 2.2.3 VOD ......................14 2.2.4 System Setting ....................17 2.2.5 Introduction of the Web interface ..............18 TROUBLE SHOOTING .................... 24 Copyright© Shenzhen Reach IT Co., Ltd. 4 / 24... -
Page 5: Overview
1 stream VGA signal, as well as the remote controller operation. It is more flexible and convenient, compared with the PC receiving way. The launch of REACH decoder adds the a new way of media receiving for the multimedia recording & streaming system, further improving Reach's total recording &... -
Page 6: Electrical Specifications
REACH DEC1000 User Manual Humidity: 5% to 95% Working temperature: 0 to 50℃ 1.2.3 Electrical specifications Operating voltage: DC12V/3A Power consumption: 10W 1.2.4 Network interface LAN: Local area network interface. Copyright© Shenzhen Reach IT Co., Ltd. 6 / 24... -
Page 7: Installation And Configuration
2.2.1 Button function introduction of the remote controller The decoder can do all the operations of receiving live streaming, play on demand and parameter setting, with remote controller, as shown in the following figure. Copyright© Shenzhen Reach IT Co., Ltd. 7 / 24... -
Page 8: Network Parameter Setting
To change the network address parameter of the decoder, enter the decoder menu interface, and select the “System setting” function menu by the remote controller's [Left] and [Right] navigation buttons, then press [OK], as shown in the following figure. Copyright© Shenzhen Reach IT Co., Ltd. 8 / 24... - Page 9 After saving the changed network address parameter, IP address will be effective, and no need to restart the decoder. You can check whether the address parameter is changed successfully in the front LCD panel of decoder. Copyright© Shenzhen Reach IT Co., Ltd. 9 / 24...
- Page 10 2.2.2.3 Live Streaming It is mainly used to receive the real time live streaming of the multimedia recording & streaming server. The live streaming interface is as shown in the following figure: Copyright© Shenzhen Reach IT Co., Ltd. 10 / 24...
- Page 11 IP and port/channel, as shown in the following figure: Name： To display name of the server for receiving unicast and multicast. IP Address：To display IP address of server for receiving unicast and Copyright© Shenzhen Reach IT Co., Ltd. 11 / 24...
- Page 12 -: Delete server.OK: Enter the media receiver interface after selecting server. The unicast receiving configuration is as shown in the following figure: The multicast receiving configuration is as shown in the following figure: Copyright© Shenzhen Reach IT Co., Ltd. 12 / 24...
- Page 13 By pressing [INFO] button on the remote controller, you can view the current media frame rate, bite rate, audio sample rate, audio bandwidth and video resolution while receiving media. The corresponding figure is as below: Copyright© Shenzhen Reach IT Co., Ltd. 13 / 24...
-
Page 14: Vod
2.2.3 VOD It is used to play on demand the files that have been recorded by the multimedia recording & streaming server, the VOD interface is as shown in the following figure: Copyright© Shenzhen Reach IT Co., Ltd. 14 / 24... - Page 15 REACH DEC1000 User Manual Name: To display name of the VOD server IP Address: To display IP address of the VOD Server +: Add new VOD server Copyright© Shenzhen Reach IT Co., Ltd. 15 / 24...
- Page 16 If you need to exit playing on demand file, press [EXIT] button, then you will be back to the VOD file list. The video on demand previewing mode is as below: Copyright© Shenzhen Reach IT Co., Ltd. 16 / 24...
-
Page 17: System Setting
In the system setting, we can view the current system’s version information, and set the network parameter, Output mode, language, date and time, etc. The system setting is shown in the following figure: Copyright© Shenzhen Reach IT Co., Ltd. 17 / 24... -
Page 18: Introduction Of The Web Interface
The decoder is embedded with WEB server. All the operations are completed through the browser (Internet Explorer), which is very easy and convenient. The functions in the Web interface mainly include the operations of system information, system configuration, servers list, Copyright© Shenzhen Reach IT Co., Ltd. 18 / 24... - Page 19 2.2.5.1 Web logon After 192.168.1.100 is entered in the browser address field, the logon page in the following figure will appear. User: admin (factory default, for administrator, can not be Copyright© Shenzhen Reach IT Co., Ltd. 19 / 24...
-
Page 20: System Information
IP address, as shown in the following figure: 2.2.5.3 Configurate System configuration mainly includes language, password modification, network setting, mode setting and system upgrade, etc., as shown in the following figure: Copyright© Shenzhen Reach IT Co., Ltd. 20 / 24... - Page 21 Enter the modified IP address, subnet mask and default gateway, then press “Save”. Note: After changing the network address, it will take effect after the decoder restarts. Mode Setting: To set the decoder's output modes, which include the Copyright© Shenzhen Reach IT Co., Ltd. 21 / 24...
- Page 22 VOD, as shown in the following figure: Copyright© Shenzhen Reach IT Co., Ltd. 22 / 24...
- Page 23 Save: Save the entered server information and finish the addition. 2.2.5.5 Restart System It is mainly used to remotely restart the decoder through network, as shown in the following figure: 3.2.6.6 Exit To exit the logged on Web management interface. Copyright© Shenzhen Reach IT Co., Ltd. 23 / 24...
-
Page 24: Trouble Shooting
Use the network tool and software, e.g. ping command, to test the network connection between the computer and this product. If you still could not log on the web interface, please contact the network administrator. Copyright© Shenzhen Reach IT Co., Ltd. 24 / 24...
