Summary of Contents for TrekStor SurfTab wintron 10.1 3G

  • Page 1 wintron 10.1 3G SurfTab ® OPERATING INSTRUCTIONS...

  • Page 2: Table Of Contents

    Contents 1) About the SurfTab ……………………………………………………… 4 2) Safety information ……………………………………………………… 5 Operational safety ………………………………………………………… 5 Repair …………………………………………………………………… 6 Intended operating conditions …………………………………………… 7 Power supply ……………………………………………………………… 7 Care and maintenance …………………………………………………… 7 Notes on devices with a suction cup……………………………………… 7 Information on the memory capacities indicated …………………………...
  • Page 3 13) Downloading applications from the Windows Store ………………… 20 14) Transferring files between the SurfTab and other devices …………… 20 Transferring files via Bluetooth …………………………………………… 20 Transferring files between the SurfTab and a PC ………………………… 21 15) Connecting the SurfTab to a television ……………………………… 22 Connecting to a television via HDMI cable ………………………………...

  • Page 4: About The Surftab

    1) About the SurfTab The TrekStor SurfTab wintron 10.1 3G is a tablet PC with the Windows 8.1 with Bing operating system and a 10.1" IPS touch display for surfing the Internet, using apps and playing music, videos and games. Thanks to numerous additional programs available with Office 365 Personal, it is ideally suited for mobile word processing and for designing presentations and tables.

  • Page 5: Safety Information

    2) Safety information These instructions use the following warning symbols and key words: DANGER Indicates possible danger to life and/or danger of severe, irreversible injuries. CAUTION Follow instructions to avoid injuries and material damage. WARNING Follow instructions to avoid material damage. NOTE Further information about the use of the device.

  • Page 6: Repair

    DANGER Do not cover the device or charger during operation or while charging. This may cause the device/charger to overheat and potentially catch fire! CAUTION This device can generate high sound volumes. Never listen at high volumes for long periods. Doing so can result in immediate or gradual hearing damage.

  • Page 7: Intended Operating Conditions

    Intended operating conditions Protect the device from extremely high or low temperatures and fluctuations in temperature. Use it at an ambient temperature between 10º C and 40º C. Do not place the device near a heat source and protect it from direct sunlight. Never expose the device to humidity, condensation or moisture.

  • Page 8: Technical Specifications

    259 x 173 x 9 mm Weight 668 g Battery Lithium polymer Housing material Plastic Operating system Windows® 8.1 with Bing 4) Package contents • SurfTab wintron 10.1 3G • Power adapter (two-part) • Quick guide • Product safety and legal information...

  • Page 10: Controls And Ports

    5) Controls and ports A) Windows button B) Front camera C) Micro-USB socket D) Volume control E) On/off switch F) Speaker G) Keyboard dock H) Rear camera Memory card slot Micro-SIM card slot K) DC IN Micro-HDMI® socket M) USB-A socket N) Microphone O) Audio out socket 6) Starting up the SurfTab for the first time...

  • Page 11: Switching On The Surftab

    b) Now connect the assembled power adapter to the SurfTab and a plug socket, and fully charge the SurfTab. The maximum battery life is reached after approximately ten charging cycles. Switching on the SurfTab Press the on/off switch for approximately two to three seconds to switch on the SurfTab.

  • Page 12: Home Screen And Desktop View

    8) Home screen and desktop view Depending on needs and preferences, you can decide whether to use the home screen with live tiles (this screen is optimised for mobile devices) or the classical desktop view. The first time you switch on your SurfTab, the home screen with live tiles appears. If you would like to switch to the desktop view, tap the live tile with the name "D "...

  • Page 13: Desktop View

    Desktop view 9) Charm Bar The Charm Bar is a bar with quick links to some of the important functions of the SurfTab. You can show or hide the Charm Bar on the home screen or the desktop view. To open the Charm Bar, swipe your finger from the right edge of the screen towards the centre of the screen.

  • Page 14: Using And Setting Up The Home Screen

    10) Using and setting up the home screen To go to the home screen, tap the Windows button (A). Selecting an element Using your fingertip, briefly tap the desired live tile or an input area in order to open it. Using the touch screen in the desktop view: Whereas in the home screen, it is sufficient to tap the elements just once in order to open or activate them, in the desktop view, many of the elements must be...

  • Page 15: Arranging And Sorting The Live Tiles

    Arranging and sorting the live tiles The live tiles displayed on the home screen can be arranged to suit your preference. To access the edit mode for a particular live tile, place your finger on the live tile and hold the tile until a small tick appears in its top-right corner. You are now in edit mode for the selected tile.

  • Page 16: Calling Up The Applications Menu

    Calling up the Applications menu The Applications menu is located "beneath" the home screen. To call up the Applications menu, place your fingertip on a free area of the home screen and "drag" the home screen up. 11) Connecting the SurfTab to the Internet Connecting to the Internet via WiFi Tap the Windows button to switch to the home screen.
  • Page 17 Enter the network key in the input field and tap "n " to confirm. The network key can generally be found on the back of your router. If a WPS authentication method (for example, a PIN) was set up for your router, the SurfTab shows a different input field.

  • Page 18: Connecting To The Internet Via 3G

    WARNING You will be asked whether the SurfTab should search for additional devices in the selected network and whether it should automatically connect to these devices (for example, printers or television sets). This is recommended in private home networks that you can trust. If you connect to a public wireless network, we recommend that you decline this option by tapping "N ".

  • Page 19: Activating Office 365 Personal

    12) Activating Office 365 Personal A one-year subscription to Office 365 Personal is preinstalled on your SurfTab. To exploit the numerous benefits of the productivity software, you must activate Office within six months of activating Windows. You can then use the Office applications Word, Excel, PowerPoint, Outlook, OneNote, Access and Publisher on your SurfTab free of charge for one year.

  • Page 20: Downloading Applications From The Windows Store

    13) Downloading applications from the Windows Store The Windows Store is available as a live tile on the first or second page of the home screen. You can identify the Windows Store by its icon, a shopping bag featuring the Windows logo. The following two requirements must be met in order to access the Windows Store: 1.

  • Page 21: Transferring Files Between The Surftab And A Pc

    h) Select the device you would like to connect from the list of devices available by tapping the name of the device. Now tap "p ". The SurfTab sends a verification code to the device to be connected. Check that the code displayed on the device to be connected matches the code displayed on the SurfTab and confirm with "y "...

  • Page 22: Connecting The Surftab To A Television

    g) Tap and hold the desired files until a drop-down window appears. Tap "C " in the drop-down window. h) Now tap "t pC" again on the left in the file browser. Open the desired destination folder by tapping twice. Tap a free area in the folder and hold there until a drop-down window appears.

  • Page 23: Using The Camera

    Open the Charm Bar by swiping your finger inwards from the right-hand edge of the screen. d) Tap "D " in the Charm Bar. eviCes e) Now tap "p ". rojeCt Tap "a ". The SurfTab now searches for available Miracast DD a Wireless Display devices nearby.

  • Page 24: Automatic Windows Update Function

    Recording a video Tap the video camera symbol on the right side of the screen to start video recording. To stop video recording, tap the "Stop" symbol (appears instead of the video camera symbol during recording). Calling up options and front camera To call up further options of the camera application or to switch to the front camera, swipe your finger from the bottom edge of the display towards the centre.

  • Page 25: Performing A System Backup

    Tap "s " in the Charm Bar. ettings d) Now tap "C " in the bottom-right area. hange settings e) Tap "u " in the bottom-left area and then "C pDate aMD reCovery hoose hoW upDates " (centre of the screen). get installeD Under "i ", select how the SurfTab should proceed with...

  • Page 26: Reset And Recovery

    19) Reset and recovery Reset If your SurfTab "freezes" and no longer responds, you can restart it. Press and hold down the on/off switch until the device switches off. Wait for about 20 seconds and then turn the device on normally. Recovery If you would like to re-set up your SurfTab, proceed as follows: Tap the Windows button to switch to the home screen.

  • Page 27: Notes On Copyright And Trademarks

    The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by TrekStor GmbH is under license. Other trademarks and trade names are those of their respective owners.

  • Page 28: Notes On Liability And Warranty

    23) Notes on liability and warranty The manufacturer shall reserve the right to constantly further develop the product. These changes may be made without any direct reference to them in the operating instructions. As a result, the information contained in the operating instructions does not need to reflect the current technical design.
  • Page 29 Product: SurfTab wintron 10.1 (ST10432-3) | SurfTab wintron 10.1 3G (ST10432-3a) I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I I...
  • Page 30 Supportinformationen Sollten Sie Fragen zu Ihrem TrekStor Produkt haben, gehen Sie bitte wie folgt vor: • Überprüfen Sie anhand der Produkteigenschaften und der Funktionen Ihres Gerätes (auf der Verpackung ersichtlich), ob Sie die richtigen Einstellungen vorgenommen haben. • Lesen Sie aufmerksam die gesamte Bedienungsanleitung.
