Summary of Contents for Pintek PA-655
-
Page 1: Instruction Manual
50 Amp AC/DC Current Probe 安培 交流/直流 電流探測鉗 PA-655 DC‐500KHz. 5mA‐50A INSTRUCTION MANUAL www.tmatlantic.com... -
Page 2: Table Of Contents
TABLE OF CONTENTS General Safety Instructions------------------------------------------------- 4 Safety Terms and Symbols-------------------------------------------------- 5 Getting Started------------------------------------------------------------------6 Basic Operation-----------------------------------------------------------------8 Maintenance--------------------------------------------------------------------10 Specifications------------------------------------------------------------------13 ... - Page 3 PA-655 50 Amp AC/DC Current Probe www.tmatlantic.com...
-
Page 4: General Safety Instructions
General Safety Instructions: Read the following safety instructions to avoid injury and prevent damage to this product or any products connected to it. Use this product only as specified. Only qualified personnel should perform service procedures. To Avoid Fire or Personal Injury Connect and Disconnect Properly. Connect the probe output to the measurement instrument before connecting the probe to the circuit under test. -
Page 5: Safety Terms And Symbols
Safety Terms and Symbols: Terms in This Manual. These terms may appear in this manual: Warning statements identify conditions or practices WARNING. that could result in injury or loss of life. Caution statements identify conditions or practices CAUTION. that could result in damage to this product or other property. Terms on the Product. -
Page 6: Getting Started
The PA-655 current probe enables a general purpose oscilloscope to display AC and DC current signals up to 100 amps Peak (35A RMS). The PA-655 current probe can also make AC and DC measurements with a multimeter by using the recommended accessory MT-246N (BNC-to-banana) plug adapter. - Page 7 Table 1: PA-655 controls and indicators Control/Indicator Description Current flow symbol. The arrow shows the probe’s polarity convention for measuring current flowing from positive to negative. Zero adjustment. Rotate to adjust the probe output to zero when there is no current present. It may also be used to offset a DC signal component.
-
Page 8: Basic Operation
2. Move the OFF/ Range switch to the 20 mV/A or 200 mV/A position to turn on the probe. (※The PA-655 current probe has a green LED power/battery indicator. If the LED does not light, replace the battery or use specified power adaptor.) - Page 9 See Figure 4. The sensitivity of the PA-655 current probe is multiplied times the number of loops in the jaws. For example: 200 mV/A X 4 turns = 800 mV/A.
-
Page 10: Maintenance
PA-655 AC/DC Current Probe. 1. Notes on Battery and Power Converter: The PA-655 current probe uses a single square 9 V battery. This machine is a high power product. Please use the specified alkaline battery. As the battery in the PA-655 current probe is drained, significant gain errors may occur. - Page 11 PA-655 has in its design a priority external power circuit therefore it is safe to simultaneously install the battery and the external power supply. During usage, removing the external power supply will not produce waveform anomaly or any damage. However when external power is used for an extended time (more than 1 week), removal of battery is recommended.
- Page 12 Do not clean with solvents or abrasives. Do not immerse the probe. 4. Preparation for Shipment Our company has designed a special box to be used for PA-655, convenient for storage and shipment. Please do not discard it. If the original packaging is unfit for use or not available, use the following...
-
Page 13: Specifications
Specifications: These characteristics apply to an adjusted PA-655 AC/DC Current Probe installed on an oscilloscope of any brand. The oscilloscope must be warmed up for at least 20 minutes and be in an environment with the temperature at 10℃~30℃ and the humidity at 0~80. - Page 14 Table 3: Voltage and current ratings Maximum working Maximum Maximum current (A) Working floating voltage (V) voltage (V) Range Range Rating 20 mV/A 200 mV/A DC + peak AC 50 AC peak AC peak-peak 100 1200 RMS CAT III 35.4 3.54 RMS CAT II...
- Page 15 Table 5: Environmental Characteristics Temperature 0°C to +50°C Working (+32°F to +122°F) -20°C to +80°C Storage (-4°F to +176°F) 0°C to 40°C, 95% humidity Humidity 40°C to 50°C, 45% humidity Pollution Degree Figure 6: Gain versus frequency at 1 A peak, typical ...
- Page 16 Figure 7: Maximum current versus frequency Figure 8: DC signal linearity in the 20 mV/A range, typical www.tmatlantic.com...
- Page 17 Figure 9: Phase versus frequency at 1 A peak, typical Table 6: Certifications and compliances Compliance was demonstrated to the following EC Declaration specification as listed in the Official Journal of the European Union: Conformity – Low Voltage Low Voltage Directive 73/23/EEC, as amended by 93/68/EEC EN 61010-1/A2:1995...
- Page 18 Table 6: Certifications and compliances (cont.) Terminals on this product may have different Installation installation (overvoltage) category designations. (Overvoltage) The installation categories are: Category CAT III Distribution-level mains (usually permanently connected). Equipment at this level is typically in a fixed industrial location.
-
Page 19: Replaceable Parts
Product number MT-246N. Designed with color fool proof design to avoid polarity mistake when connecting to digital meter. The PA-655 does not have any user repairable assemblies. If you should have trouble with your probe, contact your local Service Center or representative for help. - Page 20 Accessories BP-250 ADP-110 or 220 ... PA-655 MT-246N The diagram showing how PA-655 connect to Oscilloscope or DMM. www.tmatlantic.com...
