www.ultraflymodel.com
Challenge yourself !
FW-190
For Advanced Flyers
Length (
)
Wing Span (
)
Wing Area (
Flying weight(
Wing Loading(
Radio Requirement
-------INDEX
Parts index
Tools and radio required for assembly
1.Main Wing assembly
2.Tail & Landing gear assembly
3. Power system & cowling assembly
4.Servo assembly
5.CG & Control Adjustment
6.Decals
805 mm
31.7 In
930 mm
36.6 In
2
2
)
13 Dm
201.5 In
)
645 g
22.7 oz
2
2
)
49.6 g/dm
16.2oz/ft
3-4 (
)
3-4 Channel
PRECAUTION
1
Please read through the entire instruction manual before you start .
First time builders if not familiar with the processes in the manual,
2
please find an experienced builder to help with assembly.
3
Always keep children away from the assembly area due to small parts
and glue which are dangerous to children.
4
Please save this instruction manual for future repair or parts ordering
5
purposes.
6
8
9
Advertisement
Related Manuals for Ultrafly FW-190
Summary of Contents for Ultrafly FW-190
- Page 1 Challenge yourself ! FW-190 For Advanced Flyers Length ( 805 mm 31.7 In Wing Span ( 930 mm 36.6 In Wing Area ( 13 Dm 201.5 In Flying weight( 645 g 22.7 oz Wing Loading( 49.6 g/dm 16.2oz/ft 3-4 (...
-
Page 3: Included Parts
INCLUDED PARTS Wing Panels Cowling Fuselage 9x7 Prop Spinner M2.6x10 Washer M5.2x12 M2.6x8 M3x3 M5 Nut Prop adapter Push Rods 170mm X2 590mm X1 630mm X1 Aileron Servo Mount Velcro Main Wheels M3x25mm Wing Bolt Main Landing Gear Main Wing Joiner Washer Tail Wheel Assembly... -
Page 4: Tools Required
PARTS NOT INCLUDED IN KIT ITEMS REQUIRED FOR OPERATION (Not included in kit) Receiver Lipo battery Electronic speed controller 15mm 4~8 Channel transmitter Ext.wire x1 Battery charger Micro servos x3 TOOLS REQUIRED Cutting knife Pliers Drill Screw driver Pins Soldering lron (M3) Epoxy Glue C.A glue... -
Page 5: Wing Assembly
WING ASSEMBLY Procedure 1 2.Install the aileron and remove all pins. Apply CA to all 1.Using a pin hold the hinge at the center location. hinge areas. Be careful to keep CA away from Apply epoxy on the aileron pushrod tip and cove on aileron and wing joint. - Page 6 Procedure 4 1.Install the wing onto the fuselage and fasten it with (M3x30mm) screw. TAIL & LANDING GEAR ASSEMBLY Procedure 1 Marking Marking 1.At the center position of the elevator, use a thin 2.Install the elevator to the fuselage. Look through the marker pen and draw a vertical line with a ruler.
- Page 7 Procedure 4 2.Trial fit the rudder control surface with the tail. Mark the location of the tail wheel wire that would contact/penetrate the rudder controller surface. Use 1.Use a 1.5mm hand drill to drill a 5mm a 1.5mm hand drill to drill a 10mm hole and apply a deep hole for installing the tailwheel plate.
- Page 8 1.Assemble the spinner as shown in the graphics. position,you need to install the motor first and put on If you use our Ultrafly F/12/10 or F/18/09 motor the cowling then fasten up the spinner. You should on this model, you will need a 4/6mm propeller...
- Page 9 Important Note for 3S Lipo Application For best results, use only the Ultrafly Apollo series brushless Electric Speed Controller (ESC). You will need a strong Battery Elimination Circuit (BEC) in your ESC. This model requires three micro servos.The BEC circuit in a standard ESC can only support 2-3 micro servos in 3S Lipo Battery application.
- Page 10 Procedure 4 Always adjust the servo at its neutral position before you install it. Please use screws to fasten the servo on the servo mounting plywood in the fuselage. Do not use glue or double sided tape to install the servo. Use Z bend or easy connector to connect the push rod with the servo arm.
- Page 11 Decal Locations...
