www.ultraflymodel.com
EDGE 540
EDGE 540
For Advance Flyers．適合進階玩家
Length (全長)
1190 mm
Wing Span (翼展)
1100 mm
Wing Area (翼面積)
27.7 Dm
All up Weight(全備重)
1200 g
Wing Loading (翼荷重)
46.21 g/dm
Radio Requirement
4 Channel
-------INDEX
Parts index．零件表__________________________________________ 01
●
Tools and radio required to assembly．組裝前注意事項__________ 02
●
2.Main Wing assembly．主翼的組裝____________________________ 03
●
3. Tail & Landing gear assembly ．尾翼組與輪架組裝_____________ 05
●
4. Power system & cowling assembly ．動力組與整流罩組裝 ______ 11
●
5.Servo assembly．伺服器的組裝_______________________________ 13
●
6.CG & Control Adjustment．重心及設定的組裝________________ 18
●
43.3 In
47.2 In
2
429.4 sq.In
42.34 oz
2
15.1 oz/sq.ft
4 (動作)
PRECAUTION
．Please read through the entire instruction manual before you start .
．First time builders if not familiar with the processes in the manual,
please find an experienced builder to help with assembly.
．Always keep children away from the assembly area due to small parts
and glue which are dangerous to children.
．Please save this instruction manual for future repair or parts ordering
purposes.
請注意
．組裝前請先閱讀使用說明書
．初學無任何組裝經驗者請與經驗較豐富的高階玩家一同組裝
．請在孩童拿不到零件的環境下組裝以確保安全
．請保留本說明書方便您日後的快速查閱
Advertisement
Related Manuals for Ultrafly Edge 540
Summary of Contents for Ultrafly Edge 540
- Page 1 EDGE 540 EDGE 540 For Advance Flyers．適合進階玩家 Length (全長) 1190 mm 43.3 In Wing Span (翼展) 1100 mm 47.2 In Wing Area (翼面積) 27.7 Dm 429.4 sq.In All up Weight(全備重) 1200 g 42.34 oz Wing Loading (翼荷重) 46.21 g/dm 15.1 oz/sq.ft...
- Page 2 A very thick airfoil would offer good lift but a bit tuff in Hi-alpha approach. Ultrafly has find a good balance between the two and create this model that can cover the two requirement properly. We hope you can...
-
Page 3: Included Parts
INCLUDED PARTS Wing 主翼 Cowling 整流罩 Fuselage 機身 Elevator Plastic Screw Velcro 水平尾翼 塑膠螺絲 魔鬼氈 Rudder Main Wing Joiner 10x12x408mm M3x30 M2.6x8 垂直尾翼 主翼連接管 螺絲 螺絲 110mm x2 Horn 600mm x1 Propeller 11x5.5 螺旋槳 660mm x1 Push Rod Screw M2x5 Prop adapter 推拉桿組... - Page 4 PARTS NOT INCLUDED IN KIT ITEMS REQUIRED FOR OPERATION( Not included in kit)另購裝備 2500~3200mAh Receiver Lipo battery Electronic speed controller 接收機 電池 電子變速器 15mm 4~8 Channel transmitter Ext.wire x1 Battery charger Standard servos x3 4動作以上發射機 延長線 x1 充電器 伺候器 x3 TOOLS REQUIRED 組裝必須工具...
-
Page 5: Wing Assembly
WING ASSEMBLY Procedure 1 Procedure 2 Try to move the Aileron up and down. Leave about 0.5-1.0 mm gap between the wing and the aileron. This gap is also named as "hinge line" which will be used in the following procedure. You must allow the aileron control surface to move freely. - Page 6 Procedure 4 Install the Carbon enhancement tube into the fuselage as shown in the picture then install the main wing. Procedure 5 Procedure 6 15mm 15mm plastic screw Install the wing onto the fuselage. Use a plastic screw to secure the wing as picture shows above on both side.
- Page 7 TAIL & LANDING GEAR ASSEMBLY Procedure 1 Procedure 2 38mm 19mm 19mm 7.5mm 7.5mm 15mm Take out the elevator from fuselage. Use hobby knife to remove the film in the center section between the markings for future assembly as picture shows. Procedure 3...
- Page 8 Procedure 4 Use CA to glue it into position as the picture shown. Insert CA hinges into the elevator and its control surface. Procedure 5 Install the main wing on the fuselage then install the rudder fin on the fuselage for reference. Put the model on your working table and look from the tail side as graphic shows.
- Page 9 Procedure 7 Carefully align them together and use CA glue to combine the two parts together. Procedure 8 Trial fit the rudder fin onto the fuselage. Use pen to make a mark at the connecting line between the rudder and fuselage on both sides.
- Page 10 Procedure 10 Put the vertical find back to its original position. Use CA to glue/fix it into position. Procedure 11 Screw M2.6x10 Install the tail wheel holding brass/FRP palate with two screws as picture shown. Wheel Stop Procedure 12 20mm 30mm Wheel Stop Wheel Stop...
- Page 11 Procedure 13 Procedure 14 Install the tail wheel landing wire onto the control surface with CA or Epoxy glue. Procedure 15 Use CA on the hinge to secure the control surface to the rudder...
- Page 12 Procedure 16 43mm M3 Nut M3x30 Screw 1.Measure and mark 43mm from the front and 9mm from Washer Washer the bottom of the wheel pants. Wheel pants are a pair. On you left side wheel pant, you drill a 3mm hole at its right side which will connect to the landing strut.
- Page 13 Procedure 19 M3x3 Screw Wheel Stop POWER SYSTEM & COWLING ASSEMBLY Procedure 1 1.Use pencel to mark the center line on the motor 2.Mark the screw location with a pen.. mount. Procedure 2 2 mm Screw M 2.6x8 Use 1.2 mm hand drill to pre-drill the screw holes. Install the motor with the screw provided by the motor maker as picture.
- Page 14 Procedure 3 The shaft should be in the center of the cowling hole. Procedure 4 Using tape to temporarily hold the cowling in place, install the spinner/prop assembly onto the motor output shaft by tightening the two hex screws on each side of the prop adaptor.
- Page 15 Procedure 6 Aluminum spinner assembly RADIO & SERVO ASSEMBLY Micro servos *4 Please reference your radio hand book to connect the wire to receiver Procedure 1 Look under the main wing and find the servo hole for aileron servo. Cut out the film that covers the hole carefully.
- Page 16 Procedure 2 Before installing the aileron servo, put the extended wire through the hole to the root of the wing. The extension wire should go through the wing root. The wire will go through the fuselage and connect to the receiver in the following procedure. Inster Procedure 3 Exit...
- Page 17 Procedure 5 Procedure 6 Hole line Hinge Procedure 7 Set the servo to neutral position then fasten the screw on the connector.
- Page 18 Procedure 8 Screw M2x10 Use CA to hold the horn in position then fastens it up with the screws. Use the same method on all horn installation 1.5mm Procedure 9 Screw M2x10 1.5mm Procedure 10 Screw M2x10 1.5mm...
- Page 19 Procedure 11 Procedure 12 Velcro Velcro Procedure 13 Attach the canopy as picture shown.
- Page 20 CG:Control Surface set-up & Test Flying Elevator Aileron Rudder 升降舵 副翼 方向舵 Min: 20mm Min: 30mm Min: 60mm Max:40mm Max: 50mm Max: 80mm Exp:20+ Exp:20+ Exp:10+ Use the battery to adjust the CG location. If the battery is not heavy enough add more weight in the nose or tail location.
