Page 3
CONGRATULATIONS! Selecting fine audio equipment, such as the Addictive Audio unit you have just purchased, is only the beginning of your musical enjoyment. Now is the time to consider how to maximize the fun and excitement your equipment has to offer.
at the marked locations and firmly fasten the amplifier in place with the mounting screws supplied in the accessory kit. Caution Before drilling or cutting any holes investigate the layout of your automobile thoroughly! Take care when working near the gas lines, hydraulic lines and electrical wiring.
Page 5
+12V Power (+12V) This wire is usually connected directly to the positive battery terminal. Be sure to use proper fuse as rated above within 16 inches of the main battery. (Refer to Fig. 1a and 1b) Ground (GND) Same gauge as +12V and no longer than 36” This connection must be completed using an “O”...
Signal Input (RCA) Addictive Audio amplifiers have RCA connection type input terminal for low level input. A standard pair of RCA type cables can be used for all models (Refer to . The amplifiers allow both stereo and mono input. The amplifier internally Fig.
Page 8
Strapping/Linking 2 Amplifiers to 1 Subwoofer (Fig. 6) Caution Input voltage under unloaded condition should be less than 16Volts. Impedance of two amplifiers STRAPPED is 4 ohm and 2 ohm (2ohm being the minimum).
Page 9
Features and Controls 50.1 / 100.1 / 200.1 (Fig.7) 1. RCA Line Output Jacks Allows signal to pass through to another amplifier. 2. RCA Line Input Jacks Input signal from source unit through RCA cable. Input Gain Level Control *NOT A VOLUME KNOB* This allows for the adjustment of the gain of both channels t o match the output level of the source unit.
Page 10
A majority of companies only offer a bass boost that only allows the ability to boost a certain amount of dB at 45Hz. To adjust the Addictive Audio amplifier according to this “industry average” set the Center Frequency to 45Hz (16 clicks).
Page 11
Addictive Audio uses the CLIPPING LED to lp “SE E” when clipping occurs, without this, our only other option would be to give eryone an oscilloscope.
Page 12
5. Make sure Bass EQ switch is set to OFF and the Strap Mode switch is set 6. If using the supplied Remote Ga in Control (Bass knob) turn the dial all the way up to the max. (full clockwise) 7.
Page 15
Many vehicles have small and insufficient wire to connect the alternator’s positive connection to the battery and to ground the battery to the vehicle chassis. To prevent voltage drops, these wires should be upgraded to 4-0 AWG when installing one or more Addictive Audio amplifiers. ___________________________________________________ ___________________________________________________...
Page 18
Specifications 25.1AB (13.8V) STEREO BRIDGED Signal to Noise Ratio >95dB 205x1 watts RMS @ 4ohm High Efficiency 81% THD: 0.1% 300x1 watts RMS @ 2ohm Do Lowest Recommended Load: 2ohm Mono Not Operate at 1ohm Mono 20.2AB (13.8V) STEREO BRIDGED Signal to Noise Ratio 101dB 230x2 watts RMS @ 4ohm 660x1 watts RMS @ 4ohm...
Page 19
After all, we want you listening for a lifetime. Introduction Your ADDICTIVE AUDIO amplifier has been designed to give you very high performance, and valuable features, at a very reasonable price. Take the time to...
Page 20
Caution Before drilling or cutting any holes investigate the layout of your automobile thoroughly! Take care when working near the gas lines, hydraulic lines and electrical wiring. WARNING This power amplifier has a protection feature to prevent any damage from misuse or faulty conditions - excessive heat, short circuit speakers or overload.
Page 21
Using a fuse of a different type or rating may result in a serious hazard. Signal Input (RCA) Addictive Audio amplifiers have RCA connection type input terminal for low level input. A standard pair of RCA type cables can be used for all models (Refer to .
Page 22
signal to the amplifier providing signal to secondary amplifier. If mono input to initial amplifier is made the output to stereo (secondary) amplifier will also be mono. Adjustment of input level is accomplished by the gain control. Adjusting this control allows the amplifier gain to be controlled to match the source un Signal Input Co nnections Speaker Output Connections...
Page 25
Features and Controls 25.1 / 20.2 / 5.4 / 10.4 (Fig.4) 1. 0-180 Degree Phase Alignment Allows for the time correction of music signals to prevent phasing cancellation or music blurring. 2. MODE HPF: Set the MODE SWITCH to the HPF position when the amplifier is used to drive a tweeter/midrange system.
3. High Pass Filter with EASY CLICK (Refer to Pg.13 for EASY CL ICK Adjusting) This controls the high pass crossover point for the speaker outputs. This crossover, when selected, will attenuate the frequencies below the crossover point with a slope of -12dB per octave The crossover point is adjustable from 50-500Hz.
