Summary of Contents for Addictive audio BOOST Series
-
Page 2: Specifications
Specifications B250.4 (13.8V) STEREO BRIDGED Signal to Noise Ratio 101dB 65x4 watts RMS @ 4ohm 135x2 watts RMS @ 4ohm High Efficiency 77% THD: Do Not Operate at 2ohm or 0.1% Do Not Operate at 2ohm or Lowest Recommended Load: 1ohm Bridged 4ohm Stereo 1ohm Stereo... -
Page 3: Installation
We at Addictive Audio want you to get the most out of your equipment by playing it at a safe level, a level that lets the sound come through loud and clear without annoying blaring distortion;... -
Page 4: Power Supply Connections
Caution Before drilling or cutting any holes investigate the layout of your automobile thoroughly! Take care when working near the gas lines, hydraulic lines and electrical wiring. WARNING This power amplifier has a protection feature to prevent any damage from misuse or faulty conditions - excessive heat, short circuit speakers or overload. -
Page 5: Power Input Connections
Signal Input (High-Level) B450.1 Addictive Audio B450.1 Boost Series amplifier has High-Level inputs as an input signal option. When High-Level inputs are used the Auto-Start feature can also be... - Page 6 If you do not have a DMM, please visit an Authorized Retailer for assistance. All Addictive Audio subwoofers have the coil impedance on the back plate sticker found on the bottom of the subwoofer for easy identification.
- Page 8 Features and Controls B450.1 / B250.4 (Fig.4) 1. RCA Line Output Jacks Allows signal to pass through to another amplifier. 2. RCA Line Input Jacks Input signal from source unit through RCA cable. 3. Remote Gain Control This allows an external bass knob (included) to adjust the subwoofer from a more convenient location in the vehicle or in the event the stock head unit is being used.
- Page 9 5. Input Gain/Level Control *NOT A VOLUME KNOB* This allows for the adjustment of the gain of both channels to match the output level of the source unit. In addition, it allows adjustment from 0.2V to 6.0V. 6. Subsonic Filter Control the high pass crossover point for the speaker outputs to eliminate ultra low frequencies.
- Page 10 11. 0-180 Degree Phase Alignment Allows for the time correction of music signals to prevent phasing cancellation or music blurring. 12. Power / Protection LED POWER LED: Will illuminate GREEN when +12VDC is applied to both the remote turn on and +12V input from the battery and a solid ground has been made.
-
Page 11: Adjusting The Amplifier
Adjusting the Amplifier 1. Disconnect the negative battery post and secure it to something so accidental re-connection does not occur during the installation process. 2. Run all wires needed for the amplifier to work correctly. Do not attach the fuse in the fuse holder by the battery until all wires have been plugged into the amplifier. - Page 12 14. Turn the Bass EQ “ON” if desired. Now set the center point frequency and adjust the BOOST (refer to EASY CLICK chart on pg. 13 for exact tuning) accordingly. Keep an eye on the clipping LED! 15. If you have installed the Bass Knob, now you can use it effectively and safely.
- Page 14 Many vehicles have small and insufficient wire to connect the alternator’s positive connection to the battery and to ground the battery to the vehicle chassis. To prevent voltage drops, these wires should be upgraded to 4-0 AWG when installing one or more Addictive Audio amplifiers. ____________________________________________________ ____________________________________________________...
- Page 15 LIKE US ON FACEBOOK AND STAY UP TO DATE ON NEW PRODUCTS, PROTOTYPES, RELEASE DATES, BUILD PICTURES AND MORE. www.facebook.com/AddictiveAudioInc FOLLOW US ON INSTAGRAM AND GET IMMEDIATE UPDATE PICTURES AND VIDEOS. #addictiveaudio #kromeaudio #vitalpower www.instagram.com/AddictiveAudioInc WATCH THE LATEST AND GREATEST VIDEOS OF ADDICTIVE AUDIO, KROME AUDIO AND VITAL POWER PRODUCTS! www.youtube.com/AddictiveAudioInc...
