Serialio Scanfob CS3070 Configuration Manual

Hide thumbs
1
2
3

Advertisement

Table of Contents

To change the configuration settings for the Scanfob® CS3070, plug the scanner in with the supplied USB
cable and access the scanner like you would a flash drive. In the \Parameters folder, you will see a
"config.ini" file that contains the current configuration settings. Open this file in a text editor, such as
Notepad, to edit the configuration.
The table below shows the configuration parameters of the Scanfob® CS3070, with the default settings
and what each setting is used for.
Setting
BarcodeFile
BarcodeDB
BTPin
BTName
BTProfile
Mute
Prefix
Suffix
Separator
DateFormat
TimeFormat
Sleep
BTSleep
ButtonPlus
ButtonMinus
ButtonBT
LEDBlue
LEDRed
LEDGreen
LEDAmber
Scanfob® CS3070 Configuration
Purpose
Name of the batch* file containing scanned
barcodes when scanner is in batch mode.
Bar code database filename. If the database file
exists scanned bar codes are checked against its
content. If the bar code exists within the database,
the scanner issues a positive beep, if not a
negative beep. To engage this mode, create the
BarcodeDB.txt file on the CS30XX. Note that if
this mode is engaged, no bar code data is saved
to the scanner.
Default SPP PIN.
Bluetooth device name used during discovery.
Selected BT profile. Set to SPP or HID.
Mute the beeper.
Prefix character.
Suffix character.
Separator character.
Date format for batch data. Enter no value to
disable the date stamp.
Time format for batch data. Enter no value to
disable the time stamp.
Time in seconds before the scanner enters sleep
mode when no activity is detected.
Time in seconds before the scanner enters sleep
mode when paired to another Bluetooth device
when no activity is detected.
Enable/Disable the Plus button.
Enable/Disable the Minus button.
Enable/Disable the BT button.
Enable/Disable the blue LED for normal operation
and wake up.
Enable/Disable the red LED for normal operation
and wake up.
Enable/Disable the green LED for normal
operation and wake up.
Enable/Disable the amber LED for normal
Default
BARCODES.TXT
DBASE.TXT
0000
Scanfob-
CS3070:<serialnumber>
SPP
Off
<none>
0x0D (CR)
',' (comma)
MM/DD/YY (Enabled)
24h (Enabled)
120 (2 minutes)
600 (10 minutes)
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled
Enabled

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Scanfob CS3070 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Serialio Scanfob CS3070

Summary of Contents for Serialio Scanfob CS3070

  • Page 1 Scanfob® CS3070 Configuration To change the configuration settings for the Scanfob® CS3070, plug the scanner in with the supplied USB cable and access the scanner like you would a flash drive. In the \Parameters folder, you will see a “config.ini” file that contains the current configuration settings. Open this file in a text editor, such as Notepad, to edit the configuration.

  • Page 2: Led Indications

    operation and wake up. WakeUpLed Enable/Disable the wake up LEDs. Disabled Low Battery Indication Length red LED will display when battery is low. Disable Protect Toggle Enable/Disable the protect option. 0 (Disabled) Max Barcode Length Set the maximum number of characters for a barcode.

  • Page 3: Beeper Indications

    Enable Bluetooth radio Hold Bluetooth button Rapidly flashing blue Bluetooth is enabled for 5 seconds but has not paired with a host Bluetooth radio pairing Press Bluetooth button Slowly flashing blue Bluetooth radio paired Very slowly flashing with host and in range blue LED Bluetooth radio out of Blue LED is off...
