BFM Europe Eden HE MK2 Installation, Maintenance & User Instructions

High efficiency inset room heater
Hide thumbs Also See for Eden HE MK2:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation, Use and Maintenance Instructions
Eden HE MK2
HIGH EFFICIENCY INSET ROOM HEATER
Installation, Maintenance & User Instructions
Hand these instructions to the user
Model No's BHVG**RN2 is for use on Natural Gas (G20) at a supply pressure
of 20 mbar in G.B. / I.E.
Model No's BHVG**RP2 is for use on Propane Gas (G31) at a supply
pressure of 37 mbar in G.B. / I.E.
** Denotes trim & colour variant

Advertisement

Table of Contents
loading

Related Manuals for BFM Europe Eden HE MK2

Summary of Contents for BFM Europe Eden HE MK2

  • Page 1 Eden HE MK2 HIGH EFFICIENCY INSET ROOM HEATER Installation, Maintenance & User Instructions Hand these instructions to the user Model No’s BHVG**RN2 is for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E.

  • Page 2: Table Of Contents

    Removal & replacing the glass frame assembly 45-46 Removal & re-fitting the fuel-bed logset 47-51 Removal & re-fitting the pebble fuel-bed pebble set Model numbers BHVG**RN2 & BHVG**RP2 are manufactured by:- BFM Europe Ltd. Trentham Lakes, Stoke-on-Trent, Staffordshire, ST4 4TJ...

  • Page 3: Information And Requirements

    SECTION 1 INFORMATION AND REQUIREMENTS APPLIANCE INFORMATION Main injector : (1 off) Stereomatic Cat 82 – size 2.05 (NG) Stereomatic Cat 82 – size 1.31 (LPG) Pilot Type : NG - Seagas P5-29D LPG - Seagas P5-30LP Max. Gross Heat Input : 6.9 kW Min.

  • Page 4: Conditions Of Installation

    INSTALLATION REQUIREMENTS CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a GAS SAFE Registered Installer, in accordance with these installation instructions and the Gas Safety (Installation and Use) Regulations 1998 as amended. Failure to install appliances correctly could lead to prosecution.

  • Page 5: Shelf Position

    SHELF POSITION The fire may be fitted below a combustible shelf providing there is a minimum distance of 300mm above the top of the fire and the shelf does not project more than 150mm. If the shelf overhangs more than 150mm the distance between the fire and the shelf must be increased by 15mm for every 25mm of additional overhang over 150mm.

  • Page 6: Installation Of Fire

    SECTION 2 INSTALLATION OF FIRE UNPACKING THE COMBUSTION CHAMBER Carefully lift the combustion chamber out of the carton. Remove the loose item packaging carefully from the pack. Check the contents as listed :- DO NOT UNDER ANY CIRCUMSTANCES USE THIS APPLIANCE IF THE GLASS PANEL IS BROKEN OR NOT SECURELY FIXED TO THE FIREBOX.

  • Page 7: Preparing The Combustion Chamber Opening (In Studded Wall)

    PREPARATION OF THE COMBUSTION CHAMBER OPENING (INTO STUDDED WALL) USING A 125MM OR 175MM FLUE LINER. All combustible parts of the studwork must be set at the distances as shown below in figure 3 & 4. For installation into such applications a flue box with 125mm flue pipe adaptor is available to purchase as a cost option extra, please order part number 1130-127730, from your local BFM fires stockist.

  • Page 8: Preparing The Combustion Chamber Opening (In Chimney Breast)

    PREPARATION OF THE COMBUSTION CHAMBER OPENING (INTO EXISTING CHIMNEY BREAST) An opening should be constructed to the following dimensions in the existing chimney breast. See figure 5 below. Fig. 5 Lintle must project 150mm either side of the opening if Width = 835mm cutting into an existing chimney...
  • Page 9 Fig. 6 The Interactive Zone - Openings, beams or joists within this area need to be assessed. 400mm interactive area Load triangle - No beam or opening permissible within this area 600mm load triangle Lintel e.g. 750mm x 75mm Proposed Opening in Chimney Breast The opening needs to be sufficient to accomodate the combustion chamber.

  • Page 10: Securing The Fire To The Opening

    SECURING THE COMBUSTION CHAMBER TO THE OPENING 2.4.1 The combustion chamber must be secured to the opening via the four off screw and rawlplugs provided. Figure 7 below shows the hole centres in the mounting flanges of the combustion chamber. Fig.

  • Page 11: Installation Of The Gas Supply

    INSTALLATION OF THE GAS SUPPLY (INTO STUDDED WALL OR EXISTING CHIMNEY BREAST) Before installing the combustion chamber, decide from which side or if a rear connection to the gas supply is required. Plan the pipe run to enter from the rear or below the firebox from the left, right or rear and connect to the inlet elbow.

  • Page 12: Making The Electrical Connection

    MAKING THE ELECTRICAL CONNECTION. WARNING : THIS APPLIANCE MUST BE EARTHED AND SHOULD BE PREFERABLY CONNECTED VIA A 3 AMP SWITCHED FIXED FUSED SPUR WITH A MINIMUM CONTACT SEPARATION OF 3MM. IT MAY HOWEVER BE CONNECTED TO A 3 PIN PLUG TO BS 5733, THAT IS FITTED WITH A 3 AMP FUSE TO BS 1362.

  • Page 13: Removal & Re-Fitting Of The Glass Panel

    REMOVING / RE-FITTING THE GLASS PANEL 2.7.1 To remove the glass frame, the glass clamp as supplied in the loose items pack will be required. Secure the clamp to the glass panel as shown below in figure 12. Fig. 12 2.7.2 Remove the front grill by removing the 2 off retaining screws from the upturned tabs, 1 off at each end of the trim...
  • Page 14 2.7.3 Remove the 5 off securing screws and glass panel retaining bracket that are located on the top underside face of the combustion chamber. behind the canopy. See figure 14 below. Fig. 14 Glass Panel Retaining Bracket, secured by 5 off screws Combustion Chamber Glass panel...

  • Page 15: Removing The Burner Assembly

    REMOVING THE BURNER ASSEMBLY 2.8.1 Lift the burner tray cover vertically clear as shown below in figure 17 and store in a safe place. Fig. 17 2.8.2 This will allow access to the 8 off burner retaining screws, 4 off at the rear of the burner and 2 off at each side as shown below in figure 18.
  • Page 16 2.8.5 The burner can then be removed from the combustion chamber as shown below in figure 19. Fig. 19 Burner unit 2.8.6 Make the gas connection to the inlet elbow as prepared in section 2.5 Before making the final gas connection, thoroughly purge the gas supply pipework to remove all foreign matter, otherwise serious damage may be caused to the gas control valve on the fire.
  • Page 17 2.8.8 Remove the pressure test point screw from the inlet elbow and fit a manometer. 2.8.9 Turn on the main gas supply and carry out a gas tightness test. 2.8.10 Turn on the electrical supply to the appliance via the fixed fused spur or plug.

  • Page 18: Finishing The Product Aperture / Fitting The Plaster Frame

    FINISHING OF THE PRODUCT APERTURE / FITTING THE PLASTERING FRAME 2.9.1 The area below around the appliance will require a high temperature plaster finish around the appliance due to the high heat output level of the product, see figure 22. A plastering frame is supplied with the product to assist in obtaining this finished surface.

  • Page 19: Fitting The Fuel Bed Logset

    SECTION 3 INSTALLATION OF FIRE FITTING THE FUEL-BED LOGSET IF FITTING THE PRODUCT WITH THE PEBBLE FUELBED, PLEASE PROCEED TO SECTION 3.2 3.1.1 The vermiculite material should then be first layed around the burner tray as shown below in figure 23, resulting in an even layer. Fig.
  • Page 20 3.1.3 Place Log “2” at the right hand side centre of the burner tray fitting the hole in the bottom face of the log onto the single location peg as shown below in figure 25. Fig. 25 Log No. 2 3.1.4 Place Log “3”...
  • Page 21 3.1.5 Place Log “4” at the centre of the burner tray fitting the holes in the bottom face of the log onto the 2 off location pegs as shown below in figure 27. Fig. 27 Log No. 4 3.1.6 Place Log “5” at the right hand side of the burner tray locating in the groove of Log “3”...
  • Page 22 3.1.7 Place Log “6” at the left hand side of the burner tray locating in the groove of Log “1” as shown below in figure 29. Fig. 29 Log No. 6 Groove in Log “1” for locating Log “6” 3.1.8 Place Log “7”...
  • Page 23 3.1.9 If required, fit the glow fibre material over the flame ports. To do this, seperate into short strands and place randomly over the flame porting area as shown below in figure 31. This material is only supplied to improve flame aesthetics and is optional to install. Fig.

  • Page 24: Fitting The Fuel Bed Pebbles Set

    FITTING THE FUEL-BED PEBBLES 3.2.1 Remove the log retaining brackets (which are held in place by self tapping screws) from the fuel-bed support plate and retain them in a safe place. Fold the log retaining bracket mounted to the burner to the flat position.

  • Page 25: Lighting / Operation Of The Appliance

    YOU WAIT A FULL FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. The BFM Fires Eden HE MK2 is controlled by the remote handset supplied with the fire. Ensure the 9V battery as supplied in the loose items pack has been fitted to the handset before attempting to light it.
  • Page 26 3.3.1.2 The remote handset is now used to control all functions of the fire. To light the fire, press the “UP” arrow and and “OFF” button simultateously as shown on figure 35 below. You will hear a click and the fire begins a 30 second ignition process.
  • Page 27 3.3.1.4 To turn the fire off, press the “OFF” button, this will extinguish all flames including the pilot. 3.3.2 Operation of the Fire in “TEMPERATURE” mode 3.3.2.1 In order to change the mode of operation from “MANUAL” to “TEMPERATURE”, press the “SET” button, the fire will then change to either “DAY TEMP”...
  • Page 28 burner only) until the room has cooled to the temperature you have set on the handset display. 3.3.2.5 If you would like the “NIGHT TEMP” to turn the fire off then decrease the temperature until [----] is displayed. 3.3.3 Operation of the Fire in “TIMER” mode 3.3.3.1 In order to change the mode of operation from “MANUAL”...
  • Page 29 3.3.3.4 To set the P2 timed setting, press the “SET” button until the “TIMER” mode is displayed. Hold the “SET” button until the display flashes the current time for P1. Press the “SET” button again to scroll past the setting for P1 (sun) and P1 (moon). The time should now be flashing on the handset.
  • Page 30 3.3.4.2 Press and hold the “LARGE” flame button to turn on the fan and increase fan speed. 3.3.4.3 Press and hold the “SMALL” flame button to decrease the fan speed, see figure 41 / 42 for fan speed bar indicator (4 bars illuminated = maximum fan speed, 1 bar illuminated = minimum fan speed).

  • Page 31: Checking For Clearance Of Combustion Products

    CHECKING FOR CLEARANCE OF COMBUSTION PRODUCTS 3.4.1 Close all doors and windows in the room. 3.4.2 Light the fire and allow to run for approximately 5 minutes on high position. 3.4.3 After approximately 5 minutes hold a smoke match just inside and below the centre of the lower front canopy at the top of the fire (see figure 43 below).

  • Page 32: Removal / Re-Fitting Of The Efficiency Baffle

    REMOVAL / RE-FITTING OF THE EFFICIENCY BAFFLE 3.5.1 Remove the glass panel as shown in section 2.7 3.5.2 The efficiency baffle if fitted to the inner roof of the combustion chamber and is secured by 2 off screws. 3.5.3 Remove the screws and pull the efficiency baffle downwards to remove from the appliance.

  • Page 33: Maintenance

    SECTION 4 MAINTENANCE Servicing Notes Servicing should be carried out annually by a competent person such as a GAS SAFE registered engineer. This is a condition of the guarantee schemes. The service should include visually checking the chimney and fire opening for accumulations of debris and a smoke test to check for a positive up-draught in the chimney.

  • Page 34: Removal Of The Ultrasonic Receiver

    Removing the ultrasonic receiver. 4.3.1 Remove the burner from the combustion chamber as described in section 4.1. 4.3.2 Disconnect the control wires from the receiver. 4.3.3 Disconnect the ignition wire. 4.3.4 Re-fit the new receiver and re-fit the control wires to the control valve. 4.3.5 Re-assemble the burner unit to the combustion chamber and carry out a gas tightness test.

  • Page 35: Checking For Flue Debris

    Checking for Flue Debris 4.7.1 Remove the burner assembly as detailed in section 4.1 4.7.2 Locate the removeable backplate on the rear face of the firebox at the bottom. 4.7.3 Remove the 2 screws that hold the removeable backplate on the rear face of the firebox.

  • Page 36: Wiring Diagram

    Wiring Diagram Fig. 37 IMPORTANT : ALL ELECTRICAL WORK MUST BE CARRIED OUT BY A COMPETENT, QUALIFIED ELECTRICIAN.

  • Page 37: 5.1 Installation Information

    The Model number of this appliance is as stated on the rating plate affixed to the control panel of the fire and the appliance is manufactured by:- BFM Europe Ltd Trentham Lakes Stoke on Trent...

  • Page 38: About Your Eden He Mk2 Gas Fire

    ABOUT YOUR NEW EDEN HE MK2 GAS FIRE The BFM Fires “Eden HE MK2” log effect gas fires incorporate a unique and highly developed fuel bed which gives the realism of a loose log layout combined with realistic flames and glow. The use of durable ceramic material in the construction of the fuelbed components ensures long and trouble free operation.

  • Page 39: Lighting & Operating The Appliance

    LIGHTING THE APPLIANCE IMPORTANT : IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU MUST ENSURE THAT YOU WAIT A FULL FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. The BFM Fires Eden HE is controlled by the remote handset supplied with the fire. Ensure the 9V battery as supplied in the loose items pack has been fitted to the handset before attempting to light it.
  • Page 40 Fig. 2 Manual Graphic on Handset Display 5.3.1.3 With the product in “MANUAL” mode the fire can now be switched between HIGH rate heat input and LOW rate heat input by pressing the “DOWN” arrow on the handset. To reduce the flame height of the main burner incrementally, press the arrow momentarily.
  • Page 41 5.3.2 Operation of the Fire in “TEMPERATURE” mode 5.3.2.1 In order to change the mode of operation from “MANUAL” to “TEMPERATURE”, press the “SET” button, the fire will then change to either “DAY TEMP” (figure 4) mode or “NIGHT TEMP” mode (figure 5). To alternate between the 2, press the “SET”...
  • Page 42 5.3.3 Operation of the Fire in “TIMER” mode 5.3.3.1 In order to change the mode of operation from “MANUAL” to “TIMER”, press the “SET” button, the fire will then alternate between the settings until the “TIMER” mode is displayed. NOTE : The “SET” button allows you to alternate between all modes of operation :- “...
  • Page 43 5.3.4 Operation of the Fire in “CIRCULATING FAN” mode 5.3.4.1 In order to change the mode of operation from “MANUAL” to “CIRCULATING FAN”, briefly press the “SET” button to scroll through to the circulating fan mode as shown below in figure 8, both fan and level icons will flash.

  • Page 44: Cleaning Instructions

    Any damaged parts must be replaced by contacting your dealer or telephoning BFM Europe on the number stated on the rear cover of this book. Logs or pebbles must only be replaced with a complete and genuine replacement set and the fire must never be run with the wrong number or damaged logs or pebbles.

  • Page 45: Removal & Replacing The Glass Frame Assembly

    REMOVING AND REPLACING THE GLASS FRAME & PANEL 5.5.1 To remove the glass frame, the glass clamp as supplied in the loose items pack will be required. Secure the clamp to the glass panel as shown below in figure 11. Fig.
  • Page 46 5.5.3 Remove the 5 off securing screws and glass panel retaining bracket that are located on the top underside face of the combustion chamber. behind the canopy. See figure 12 below. Fig. 12 Glass Panel Retaining Bracket, secured by 5 off screws Combustion Chamber Glass panel...

  • Page 47: Removal & Re-Fitting The Fuel-Bed Logset

    REMOVAL AND REPLACING THE FUEL-BED LOGSET IF THE PRODUCT HAS A PEBBLE FUELBED, PLEASE PROCEED TO SECTION 5.7 Remove the glass panel as shown on pages 45-46 before attempting to remove or replace the logs. 5.6.1 The vermiculite material should then be first layed around the burner tray as shown below in figure 15, resulting in an even layer.
  • Page 48 5.6.3 Place Log “2” at the right hand side centre of the burner tray fitting the hole in the bottom face of the log onto the single location peg as shown below in figure 17. Fig. 17 Log No. 2 5.6.4 Place Log “3”...
  • Page 49 5.6.5 Place Log “4” at the centre of the burner tray fitting the holes in the bottom face of the log onto the 2 off location pegs as shown below in figure 19. Fig. 19 Log No. 4 5.6.6 Place Log “5” at the right hand side of the burner tray locating in the groove of Log “3”...
  • Page 50 5.6.7 Place Log “6” at the left hand side of the burner tray locating in the groove of Log “1” as shown below in figure 21. Fig. 21 Log No. 6 Groove in Log “1” for locating Log “6” 5.6.8 Place Log “7”...
  • Page 51 5.6.9 If required, fit the embaglow material over the flame ports. To do this, seperate into short strands and place randomly over the flame porting area as shown below in figure 23. This material is only supplied to improve flame aesthetics and is optional to install. Fig.

  • Page 52: Removal & Re-Fitting The Pebble Fuel-Bed Pebble Set

    REMOVAL & RE-FITTING THE FUEL-BED PEBBLES Remove the glass panel as shown on pages 45-46 before attempting to remove or replace the logs. 5.7.1 Fit the pebbles to the burner tray as shown below in figure 24, do not fill the flame ports in the burner with pebbles.
  • Page 53 Vermiculite Due to our policy of continual improvement and development the exact accuracy of illustrations and descriptions contained in this book cannot be guaranteed Part No. B-167740 Issue 2 BFM Europe Ltd. Trentham Lakes Stoke-on-Trent Staffordshire ST4 4TJ www.bfm-europe.com Telephone - General Enquiries :...
