BFM Europe Distinction Installation, Maintenance & User Instructions

Log effect balanced flue room heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Da Vinci &
Distinction
LOG EFFECT BALANCED FLUE ROOM HEATER
Installation, Maintenance & User Instructions
Hand these instructions to the user
Model No. BDVL**RN is for use on Natural Gas (G20) at a supply pressure of
20 mbar in G.B. / I.E.
** Denotes cosmetic variant

Advertisement

Table of Contents
loading

Related Manuals for BFM Europe Distinction

Summary of Contents for BFM Europe Distinction

  • Page 1 Da Vinci & Distinction LOG EFFECT BALANCED FLUE ROOM HEATER Installation, Maintenance & User Instructions Hand these instructions to the user Model No. BDVL**RN is for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E.

  • Page 2: Table Of Contents

    Securing the combustion chamber in the opening / fitting the closure plate 20 2.12 Setting hearth panel / surround legs / combustion chamber height 21-22 2.13 Installing the Da Vinci / Distinction surround design 2.14 Removal / Re-fitting the glass frame assembly 24-26 Section 3...

  • Page 3: Information And Requirements

    SECTION 1 INFORMATION AND REQUIREMENTS APPLIANCE INFORMATION Main injector : (1 off) Bray Injector Cat 82 – size 600 Pilot Type : S.I.T. 140 Series – size 27 Max. Gross Heat Input : 8.7kW Min. Gross Heat Input : 5.5 kW 0.799 m 3 /hr (High) Gas Rate : 0.511 m 3 /hr (Low)

  • Page 4: Conditions Of Installation

    Due consideration should be made to this when installing or decorating. It is recommended that the product is only installed with surround designs available from BFM Europe Ltd, but should you choose to fit an alternative surround, please give consideration to accessibility for servicing...

  • Page 5: Flue Terminal Position

    FLUE TERMINAL POSITION The minimum acceptable dimensions from the flue terminal to obstructions and ventilation openings are shown below and listed in the table It is important that the position of the flue allows the free passage of air across it at all times. The minimum acceptable space from the flue terminal to obstructions and ventilation openings are specified below (Fig.

  • Page 6: Installation Of Fire

    SECTION 2 INSTALLATION OF FIRE UNPACKING THE COMPONENTS Remove the loose item packaging carefully from the pack. Check the contents as listed :- DO NOT UNDER ANY CIRCUMSTANCES USE THIS APPLIANCE IF THE GLASS PANEL IS BROKEN OR NOT SECURELY FIXED TO THE FIREBOX. Packing Check List Pack 1 of 3 - Combustion Chamber Pack 1 off...
  • Page 7 Shelf 1 off R/H leg 1 off Top infill 1 off Controls access panel 1 off Shelf infill section Pack 3 of 3 - Distinction Surround 1 off Hearth 1 off L/H leg 1 off Shelf 1 off R/H leg...

  • Page 8: Preparing The Combustion Chamber Opening (In Studded Wall)

    PREPARATION OF THE COMBUSTION CHAMBER OPENING (INTO STUDDED WALL) All combustible parts of the studwork must be set at the distances as shown below in Fig. 4 & 5. Fig. 4 Minimum 50mm at rear Minimum 50mm at sides Combustion Chamber Refer to Fig.

  • Page 9: Preparing The Combustion Chamber Opening (In Chimney Breast)

    PREPARATION OF THE COMBUSTION CHAMBER OPENING (INTO EXISTING CHIMNEY BREAST) An opening should be constructed to the following dimensions in the existing chimney breast. Fig. 5 Lintle must project 150mm either side of the opening if cutting into an existing chimney breast Width = 870mm Height = 955mm...
  • Page 10 150mm (CONTINUED) The Interactive Zone - Fig. 9 Openings, beams or joists within this area need to be assessed. 400mm interactive area Load triangle - No beam or opening permissible within this area 600mm load triangle Minimum 200mm Lintel e.g. 750mm x 75mm Proposed Opening in Chimney Breast...

  • Page 11: Installation Of The Gas Supply

    INSTALLATION OF THE GAS SUPPLY (INTO STUDDED WALL OR EXISTING CHIMNEY BREAST) Before installing the combustion chamber, decide from which side or if a rear connection to the gas supply is required. Plan the pipe run to enter the below the firebox from the left, right or rear and connect to the inlet elbow.

  • Page 12: Specifying The Flue System & Components

    L/H side or R/H side by rotating the elbow section. If the terminal is fitted below 2m from ground level, a terminal guard must be fitted in England & Wales. BFM Europe supply a suitable guard in the Horizontal Flue Kit. See section 2.6 2.5.2...

  • Page 13: Balanced Flue In Horizontal Flue Configuration

    BALANCED FLUE IN HORIZONTAL CONFIGURATION 2.6.1 Horizontal balanced flue configuration and components identified as shown below in Fig. 11 Fig. 11 1554mm Max 1 metre length of metalotherm 324mm Min flue duct 469mm Max This is the standard flue duct supplied.
  • Page 14 BALANCED FLUE IN HORIZONTAL CONFIGURATION (CONTINUED) 2.6.2 Mark the position of the centre of the flue on the inner wall. (See Fig. 11 on previous page for position). 2.6.3 Cut hole for outer flue pipe. There are two possible methods to achieve this, either core drill or via hammer and chisel.

  • Page 15: Balanced Flue In Vertical Flue Configuration

    BALANCED FLUE IN VERTICAL CONFIGURATION 2.7.1 Vertical flue configuration and components identified as shown below in Fig. 12 Fig. 12 For details of weather proofing options at point of exit, please Vertical Terminal see overpage, sections 2.7.1 to 2.7.8 for a flat roof or 2.7.9 for a pitched roof Locking Bands Minimum Flue Height = 3 metres...

  • Page 16: Balanced Flue In Vertical Flue Configuration (Flat Roof)

    (USSR10). See Fig. 13 below 2.8.7 Install the terminal (contained within the terminal kit requested at point of order from BFM Europe Ltd.) with a locking band and fix with 3 nuts. 2.8.8 Finish the roof covering over the flashing and weatherproof. Refer to section 3.3 to fit the correct restrictor plate to the fire.

  • Page 17: Balanced Flue In Vertical Flue Configuration (Pitched Roof)

    (USSR10). 2.9.5 Install the terminal (contained within the terminal kit requested at point of order from BFM Europe Ltd.) with a locking band and fix with 3 nuts. 2.9.6 Finish the roof covering over the flashing and weatherproof. Refer to section 3.3 to fit the correct restrictor plate to the fire.

  • Page 18: Balanced Flue Utilising Existing Chimney

    2.10 BALANCED FLUE UTILISING EXISTING CHIMNEY Vertical flue configuration and components identified as shown below in Fig. 15 for installation into an existing chimney. Fig. 15 Outside Mounting Plate 4” / 100mm Flexible Flue Liner Sliding Adaptor Minimum Flue Internal Locking Band of Internal Height Mounting...
  • Page 19 Attach the internal mounting plate to the bottom part of the chimney and seal with suitable high temperature sealant. 2.10.8 Install the Da Vinci or Distinction product and fit with a minimum 1 metre rigid section of Metaloterm concentric flue (as supplied with the existing chimney flue kit by BFM Europe).

  • Page 20: Securing The Combustion Chamber In The Opening / Fitting The Closure Plate

    2.11 SECURING THE COMBUSTION CHAMBER IN THE OPENING / FITTING THE CLOSURE PLATE / CONVECTION CHANNEL 2.11.1 The product is supplied with a closure plate to assist in sealing off the top of the opening, and providing access to the flue connection on the top of the fire.

  • Page 21: Setting Hearth Panel / Surround Legs / Combustion Chamber Height

    2.12 SETTING THE COMBUSTION CHAMBER HEIGHT TO INSTALL THE SURROUND AND CENTRALISING THE SURROUND LEGS. 2.12.1 In order to ensure that the combustion chamber is at the right height to allow the controls access panel to open and close correctly, it is necessary to adjust the height of the combustion chamber as shown below in Fig.
  • Page 22 2.12 SETTING THE COMBUSTION CHAMBER HEIGHT TO INSTALL THE SURROUND AND CENTRALISING THE SURROUND LEGS. (CONTINUED) 2.12.3 In order to ensure that controls access cover does not bind on the surround legs, it also necessary to set the surround legs to assume a 4mm gap at each side of the controls access cover, centrally about the opening.

  • Page 23: Installing The Da Vinci / Distinction Surround Design

    2.13 INSTALLING THE DA VINCI / DISTINCTION SURROUND 2.13.1 Unpack the surround from the wooden crate, check all parts are present as per Fig. 20 below and carefully store the components. 2.13.2 Set the hearth panel equally around the centre of the opening and ensure that it is level across it’s width.

  • Page 24: Removal / Re-Fitting The Glass Frame Assembly

    2.14 REMOVING THE GLASS FRAME ASSEMBLY 2.14.1 To remove the glass frame, the glass clamp as supplied in the loose items pack will be required. Secure the clamp to the glass panel as shown below in Fig. 21 Fig. 21 Glass Clamp 2.14.2 The glass frame is released by firstly unscrewing the retaining bolts of...
  • Page 25 2.14.3 Whilst holding the glass suction clamp, release the bottom glass clamps as indictated below in Fig. 23 by unlatching them down and forwards. Fig. 23 Bottom Glass Clamps 2.14.4 Ensure the glass assembly is supported at all times during the following operations using the glass clamp.
  • Page 26 Fig. 25 Move entire glass assembly to the left Fig. 26 Swing right hand edge of glass frame assembly forwards to clear R/H leg of surround. Glass frame assembly can then be removed.

  • Page 27: Fitting The Fuel Bed Logset

    FITTING THE FUEL-BED LOGSET 3.1.1 Log “A” must be fitted with the retaining lugs as shown below in Fig. 27 positioned on Log “A” into the locating holes in the fuel-bed base plate as shown below. Fig. 27 Locating lugs - position into holes as shown above 3.1.2 Log “A”...
  • Page 28 3.1.3 Place the bark chippings over the burner as shown below in Fig. 29, do not allow the bark chippings to cover the area around the pilot as indicated below. Fig. 29 Keep area around pilot clear of bark chippings 3.1.4 Position the retaining lug on Log “B”...
  • Page 29 3.1.5 Fit Log “B” into position, using the locating lug that fits into left hand end of Log “A” as shown below in Fig. 31. Fig. 31 Log “B” Fitted onto Log “A” 3.1.6 Fit Log “C” into position at right hand side of log “A” as shown below in Fig.
  • Page 30 3.1.7 Fit Log “D” into position at right hand side of centre of the fuel-bed base log “A”as shown below in Fig. 33, using the locating lug in Log “A” as a guide for placement. Fig. 33 Log “D” Fitted onto Log “A”...
  • Page 31 3.1.9 Fit Log “F” into position at the centre of the fuel-bed as shown below in Fig. 35, using the locating lug in Log “D” as a guide for placement. Fig. 35 Log “F” Fitted onto Log “D” 3.1.10 Fit Log “G” into position at the left hand centre of the fuel-bed as shown below in Fig.
  • Page 32 3.1.11 Fit Log “H” into position at the right hand centre of the fuel-bed as shown below in Fig. 37, using the retaining lug in Log “F” as a guide for placement. Finally, check pilot area to ensure no bark chippings have covered the pilot.

  • Page 33: Making The Gas Conection & Checking For Gas Tightness

    MAKING THE GAS CONNECTION & CHECKING FOR GAS TIGHTNESS 3.2.1 Before making the final gas connection, thoroughly purge the gas supply pipework to remove all foreign matter, otherwise serious damage may be caused to the gas control valve on the fire. Failure to purge the gas supply will invalidate the guarantee.

  • Page 34: Replacing The Glass Assembly

    REPLACING THE GLASS ASSEMBLY 3.4.1 When replacing the glass assembly manouever into position by reversing the instruction for removal as detailed in section 2.14 3.4.2 Centre the assembly (use the legs on the surround as a guide) but take care not to damage the surround. When fitted correctly all the glass frame should be hidden behind the surround legs.

  • Page 35: Lighting The Appliance

    LIGHTING THE APPLIANCE IMPORTANT : IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU MUST ENSURE THAT YOU WAIT A FULL FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. The product is controlled by the remote handset supplied with the fire. Ensure the 9V battery as supplied in the loose items pack has been fitted to the fire before attempting to light it and the 4 off AA batteries have been fitted to the reciever unit, located next to the control valve at the L/H/S.
  • Page 36 With the product in “MANUAL” mode the fire can now be switched between HIGH rate heat input and LOW rate heat input by pressing the “DOWN” arrow on the handset. To reduce the flame height of the main burner incrementally, press the arrow momentarily. To reduce the heat input directly down to the minimum level, press and hold the “DOWN”...
  • Page 37 3.5.2 Operation of the Fire in “TEMPERATURE” mode In order to change the mode of operation from “MANUAL” to “TEMPERATURE”, press the “SET” button, the fire will then change to either “DAY TEMP” (Fig. 43) mode or “NIGHT TEMP” mode (Fig 44). To alternate between the 2, press the “SET”...
  • Page 38 3.5.3 Operation of the Fire in “TIMER” mode In order to change the mode of operation from “MANUAL” to “TIMER”, press the “SET” button, the fire will then alternate between the settings until the “TIMER” mode is displayed. NOTE : The “SET” button allows you to alternate between all modes of operation :- “...

  • Page 39: Fitting The Handset Wall Bracket

    3.5.4 Low Battery Signal When the battery in the handset needs replacing, “BATT” will be displayed on the handset. Remove the cover on the rear of the handset and replace the 9V battery as necessary. 3.5.5 To Set the Time on the Remote Handset Simultanelously press the “UP”...

  • Page 40: Maintenance

    Servicing Notes Servicing should be carried out annually by a competent person such as a GAS SAFE registered engineer. It is a condition of BFM Europe’s lifetime guarantee scheme that this is carried out by a competent person i.e a GAS SAFE registered Engineer in accordance with these servicing notes, and the pilot must also be changed as a requirement of the guarantee.

  • Page 41: Removal Of The Gas Control Valve / Controls Access Cover

    4.2.1 Remove the burner, as detailed in section 4.1 4.2.2 Loosen the pipe connected to the injector and remove the injector. 4.2.3 Replace in reverse order and carry out a gas tightness test. Removing the Gas Control Valve / Controls Access Cover 4.3.1 Open the controls access cover at the bottom of the fire.

  • Page 42: Removal Of The Ultrasonic Receiver

    Removing the Ultrasonic receiver. 4.4.1 Open the controls access cover at the bottom of the fire. 4.4.2 Lift the ultrasonic receiver out of it’s retaining bracket at the left hand side of the gas control valve 4.4.3 Disconnect the control wires. 4.4.4 Re-fit the new receiver and re-connect the control wires in reverse order, replace the receiver unit into it’s cradle at the left hand side of the...

  • Page 43: Parts Shortlist

    PARTS SHORTLIST Gas control valve B-92200 Thermostatic handset / reciever unit B-126400 Glass panel B-126350 Complete log set B-134060 Log “A” only B-134070 Log “B” only B-134080 Log “C” only B-134090 Log “D” only B-134100 Log “E” only B-134110 Log “F” only B-134120 Log “G”...

  • Page 44: Installation Information / About Your Fire

    If this appliance is fitted directly on to a wall without the use of a BFM Europe supplied fireplace or surround, soft wall coverings such as wallpaper, blown vinyl etc.
  • Page 45 ABOUT YOUR NEW DA VINCI / DISTINCTION GAS FIRE The BFM Europe Da Vinci / Distinction log effect gas fire incorporates a unique and highly developed fuel bed which gives the realism of a loose log layout combined with realistic flames and glow. The use of durable ceramic material in the construction of the fuelbed components ensures long and trouble free operation.

  • Page 46: Lighting The Appliance

    LIGHTING THE APPLIANCE IMPORTANT : IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU MUST ENSURE THAT YOU WAIT A FULL FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. The product is controlled by the remote handset supplied with the fire. Ensure the 9V battery as supplied in the loose items pack has been fitted to the fire before attempting to light it.
  • Page 47 With the product in “MANUAL” mode the fire can now be switched between HIGH rate heat input and LOW rate heat input by pressing the “DOWN” arrow on the handset. To reduce the flame height of the main burner incrementally, press the arrow momentarily. To reduce the heat input directly down to the minimum level, press and hold the “DOWN”...
  • Page 48 5.2.2 Operation of the Fire in “TEMPERATURE” mode In order to change the mode of operation from “MANUAL” to “TEMPERATURE”, press the “SET” button, the fire will then change to either “DAY TEMP” (Fig. 4) mode or “NIGHT TEMP” mode (Fig 5). To alternate between the 2, press the “SET”...
  • Page 49 5.2.3 Operation of the Fire in “TIMER” mode In order to change the mode of operation from “MANUAL” to “TIMER”, press the “SET” button, the fire will then alternate between the settings until the “TIMER” mode is displayed. NOTE : The “SET” button allows you to alternate between all modes of operation :- “...

  • Page 50: Cleaning Instructions

    None of these parts must be washed or exposed to any cleaning agents or water. Any damaged parts must be replaced by contacting your dealer or telephoning BFM Europe on the number stated on the rear cover of this book. Logs or bark chippings must only be...
  • Page 51 pads as this may scratch the surface finish of the glass panel. PLEASE NOTE :- The glass will require cleaning periodically. Condensation produced by the products of combustion will create marks on the inside face of the glass panel. 5.3.4 Removing the Glass Assembly - Ensure the fire is cool before attempting to remove the glass panel 5.3.4.1...
  • Page 52 5.3.4.3 Whilst holding the glass suction clamp, release the bottom glass clamps as indictated below in Fig. 10 by unlatching them down and forwards. Fig. 10 Bottom Glass Clamps 5.3.4.4 Ensure the glass assembly is supported at all times during the following operations using the glass clamp.
  • Page 53 Fig. 12 Move entire glass assembly to the left Fig. 13 Swing right hand edge of glass frame assembly forwards to clear R/H leg of surround. Glass frame assembly can then be removed.

  • Page 54: Removing & Replacing The Logset

    REMOVAL AND REPLACING THE FUEL-BED LOGSET Remove the glass panel as shown in section 5.3.4 before attempting to remove or replace the logs. 5.4.1 Log “A” must be fitted with the retaining lugs as shown below in Fig. 14 positioned on Log “A” into the locating holes in the fuel-bed base plate as shown below.
  • Page 55 5.4.3 Place the bark chippings over the burner as shown below in Fig. 16, do not allow the bark chippings to cover the area around the pilot as indicated below. Fig. 16 Keep area around pilot clear of bark chippings 5.4.4 Position the retaining lug on Log “B”...
  • Page 56 5.4.5 Fit Log “B” into position, using the locating lug that fits into left hand end of Log “A” as shown below in Fig. 18. Fig. 18 Log “B” Fitted onto Log “A” 5.4.6 Fit Log “C” into position at right hand side of log “A” as shown below in Fig.
  • Page 57 5.4.7 Fit Log “D” into position at right hand side of centre of the fuel-bed base log “A”as shown below in Fig. 20, using the locating lug in Log “A” as a guide for placement. Fig. 20 Log “D” Fitted onto Log “A”...
  • Page 58 5.4.9 Fit Log “F” into position at the centre of the fuel-bed as shown below in Fig. 22, using the locating lug in Log “D” as a guide for placement. Fig. 22 Log “F” Fitted onto Log “D” 5.4.10 Fit Log “G” into position at the left hand centre of the fuel-bed as shown below in Fig.
  • Page 59 5.4.11 Fit Log “H” into position at the right hand centre of the fuel-bed as shown below in Fig. 24, using a retaining peg in Log “F” as a guide for placement. Finally, check pilot area to ensure no bark chippings have covered the pilot.

  • Page 60: Replacing The Glass Assembly

    REPLACING THE GLASS ASSEMBLY 5.5.1 When replacing the glass assembly manouever into position by reversing the instruction for removal as detailed in section 2.14 5.5.2 Centre the assembly (use the legs on the surround as a guide) but take care not to damage the surround. When fitted correctly all the glass frame should be hidden behind the surround legs.

  • Page 61: User Replaceable Parts

    B-126710 Due to our policy of continual improvement and development the exact accuracy of illustrations and descriptions contained in this book cannot be guaranteed Part No. B-129130 Issue 3 BFM Europe Ltd. Trentham Lakes Stoke-on-Trent Staffordshire ST4 4TJ www.bfm-europe.com Telephone - General Enquiries :...
