BFM Europe Avelli Installation, Maintenance & User Instructions

Conventional flue log effect gas fire
Hide thumbs Also See for Avelli:
Table of Contents

Advertisement

Quick Links

Download this manual
Avelli
CONVENTIONAL FLUE LOG EFFECT GAS FIRE
Installation, Maintenance & User Instructions
Hand these instructions to the user
Model No's BHEL**RN2 is only for use on Natural Gas (G20) at a
supply pressure of 20 mbar in G.B. / I.E.
** denotes cosmetic variant

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Avelli and is the answer not in the manual?

Questions and answers

Related Manuals for BFM Europe Avelli

Summary of Contents for BFM Europe Avelli

  • Page 1 Avelli CONVENTIONAL FLUE LOG EFFECT GAS FIRE Installation, Maintenance & User Instructions Hand these instructions to the user Model No’s BHEL**RN2 is only for use on Natural Gas (G20) at a supply pressure of 20 mbar in G.B. / I.E.

  • Page 2: Table Of Contents

    Installation of Fire Unpacking the fire Installing the fire box 9-18 Fitting the batteries to the receiver unit & handset Installing the Avelli surround 19-20 Centralising the surround legs Gas tightness and inlet pressure Section 3 Assembling Fuel Bed and Commissioning...

  • Page 3: Information And Requirements

    SECTION 1 INFORMATION AND REQUIREMENTS APPLIANCE INFORMATION Model BHEL**RN2 ** denotes cosmetic variance Gas Type Main injector (1 off) Size 380 Pilot Type Seagas P4-29D Max. Gross Heat Input : 6.2 kW Min. Gross Heat Input : 3.5 kW Cold Pressure : 20.0 +/-1.0 mbar Ignition : 6V Battery Ignition...

  • Page 4: Conditions Of Installation

    INSTALLATION REQUIREMENTS CONDITIONS OF INSTALLATION It is the law that all gas appliances are installed only by a GAS SAFE Registered Installer, in accordance with these installation instructions and the Gas Safety (Installation and Use) Regulations 1998 as amended. Failure to install appliances correctly could lead to prosecution.

  • Page 5: Fireplace / Surround Suitability

    FIREPLACE / SURROUND SUITABILITY The fire must only be installed with the hearth supplied it must not be installed directly onto carpet or other combustible floor materials. If a heating appliance is fitted directly against a wall combustible material must be removed from behind it.

  • Page 6: Fire Place Opening / Catchment Space

    There must be no leakage of smoke through the structure of the chimney during or after the smoke pellet test and it is important to check inside upstairs rooms adjacent to the chimney / flue. Check the chimney pot / terminal and general condition of the brickwork or masonry.

  • Page 7: Chair Bricks

    Table A - Installation Depth Requirements for a BFM Fires Avelli being installed into a brick built chimney, requiring 12.0 litres of debris collection volume (fig. 3). Opening Width (mm) Minimum Depth Required (mm) 550-565mm 265mm Fig. 3 Depth Required...

  • Page 8: Spillage Monitoring System

    SPILLAGE MONITORING SYSTEM This appliance is fitted with an atmosphere sensing spillage monitoring system in the form of an oxygen sensing burner. This is designed to shut the fire off in the event of a partial or complete blockage of the flue causing a build up of combus- tion products in the room in which the fire is operated.

  • Page 9: Installation Of Fire

    SECTION 2 INSTALLATION OF FIRE UNPACKING THE FIRE Carefully lift the fire out of the carton. Remove the loose item packaging, check the contents as listed below :- NOTE : DO NOT UNDER ANY CIRCUMSTANCES USE THIS APPLIANCE IF THE GLASS PANEL IS BROKEN OR NOT SECURELY FIXED TO THE FIREBOX.
  • Page 10 Remove the glass panel by firstly lowering the access door then affixing the glass clamp to the glass panel as shown below in fig. 4 (Images shown with surround installed, please install firebox before surround). Fig. 4 Unclip the glass frame retaining clips at the base of the glass frame assembly as shown in fig.
  • Page 11 Unhook the glass panel from the top retaining channel by lifting upwards then tilt the top edge of the glass assembly towards you as shown below in fig. 6 (sectional view shown through product for clarity) Fig. 6 Remove the glass frame assembly by dropping down, sliding to the left until the right hand edge of the glass frame can be released from behind the right hand leg of the surround as shown below in fig.
  • Page 12 Fig. 8 R/H edge of glass frame Store the glass frame assembly in a safe place. Re-assemble in reverse order when re-fitting the glass assembly. Ensure that the glass assembly is correctly located on the top flange of the combustion chamber, this can be achieved by putting your hand onto the top edge of the glass frame inside the convection air aperture and pushing down firmly to check the glass frame is correctly located.
  • Page 13 Remove the burner. To allow burner removal, the ceramic support panel must be removed to allow access to the burner fixings. Remove the 4 off ceramic support retaining screws as shown below in fig. 9 Fig. 9 Viewed from Top Four off ceramic support retaining screws...
  • Page 14 Remove the burner by lifting clear from the combustion chamber as shown below in Fig. 11, take care to also lift out the receiver unit and wiring loom, (the receiver unit is held in position with velcro, centrally on the base unit of the firebox). Fig.
  • Page 15 Continue as follows for all models :- Whilst the fire box is still in position, decide which side the gas supply is to enter the fire from. If concealed pipe work is required plan the pipe run to enter the fire box through one of the openings in the sides or rear of the fire box below the fuelbed support panel and connect to the isolating / inlet elbow.
  • Page 16 Carefully withdraw the fire box from the opening to enable the gas supply and fire fixing to be completed. There is a choice of methods of fixing the firebox which are provided to enable the installer to deal with any type of installation. The preferred method of fixing which is suitable for almost all situations is the cable fixing method which is described in the following section in detail.
  • Page 17 downwards through the pair of fixing eyes on the same side of the fire. Thread the free end of the cables through the corresponding circular hole on each side of the lower rear of the fire. Carefully slide the fire box back into the fire opening and pull both cables tight.

  • Page 18: Fitting The Batteries To The Receiver Unit & Handset

    The other firebox fixing method is as follows :- In installations where the cable method is not suitable (e.g. loose masonary in rear of fire opening) the firebox can be secured to the opening using four screws and wall plugs (not provided). Below (fig. 15) is a diagram to indicate the hole centre positions available on the firebox to facilitate the screw fixing to the fireplace / surround.

  • Page 19: Installing The Avelli Surround

    INSTALLING THE AVELLI SURROUND Unpack the surround from the wooden crate, check all parts are present as per Fig. 16 overpage and carefully store the components. The underside of the hearth should be painted with a weak PVA (8 parts water to 1 part PVA).
  • Page 20 Fig. 16 NOTE : It is recommended that a spillage test is completed before fixing / sealing the fire surround Shelf Top Section in place. Shelf Infill Section L/H Leg Top Infill Section Controls Access Panel R/H Leg Hearth Panel...

  • Page 21: Centralising The Surround Legs

    CENTRALISING THE SURROUND LEGS In order to ensure that controls access cover does not bind on the surround legs, it also necessary to set the surround legs to assume a 4mm gap at each side of the controls access cover, centrally about the opening.

  • Page 22: Gas Tightness And Inlet Pressure

    GAS TIGHTNESS AND INLET PRESSURE Remove the pressure test point screw from the inlet elbow and fit a manometer. Turn on the main gas supply and carry out a gas tightness test. Depress both the round buttons on the handset. The fire will then commence its ignition sequence and will light to high.

  • Page 23: Fitting The Log Fuelbed

    SECTION 3 ASSEMBLING THE LOG FUEL-BED Place the L/H and R/H ceramic base pieces onto the ceramic support panel as shown below in fig. 18 Fig. 18 Place the front ceramic base piece onto the ceramic support ensuring the location tabs fit into the L/H & R/H ceramic base pieces as shown below in fig.
  • Page 24 Place the base log onto the ceramic support panel as shown below in fig. 20, ensuring the spacer locating blocks on the rear face are fitted flush up against the rear panel. Fig. 20 Ensure spacer blocks are fitted flush to the rear panel Cover the burner and fuel-bed base ceramic in a single, even layer of bark chippings as shown below in fig.
  • Page 25 Position log “H” onto the base log using the location lug on the back face of log “H” and the groove on the base log to find the correct location, as shown below in fig. 22 Fig. 22 Log H Position log “E”...
  • Page 26 Position log “B” onto the base log using the location lug on the back face of log “B” and the groove on the base log to find the correct location as shown below in fig. 24 Fig. 24 Log B Position log “G”...
  • Page 27 Re-fit the glass frame assembly before proceeding to section 3.2 Warning : Use only the log fuel-bed supplied with the fire. When replacing the log fuel-bed remove the old log fuel-bed and discard it. Fit a complete log fuel-bed from the manufacturer, only use genuine replacements. THE FOLLOWING STATEMENT IS APPLICABLE TO ALL FUEL-BED TYPES This appliance uses fuel effect pieces containing Refractory Ceramic Fibres (R.C.F.), which are man-made vitreous silicate fibres.

  • Page 28: Lighting The Appliance

    LIGHTING THE APPLIANCE IMPORTANT : IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU MUST ENSURE THAT YOU WAIT A FULL THREE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. The product is controlled by the remote handset supplied with the fire. Ensure the 9V battery as supplied in the loose items pack has been fitted to the fire before attempting to light it and the 4 off AA batteries have been fitted to the reciever unit, located centrally on the firebox base.
  • Page 29 With the product in “MANUAL” mode the fire can now be switched between HIGH rate heat input and LOW rate heat input by pressing the “DOWN” arrow on the handset. To reduce the flame height of the main burner incrementally, press the arrow momentarily. To reduce the heat input directly down to the minimum level, press and hold the “DOWN”...
  • Page 30 3.2.2 Operation of the Fire in “TEMPERATURE” mode In order to change the mode of operation from “MANUAL” to “TEMPERATURE”, press the “SET” button, the fire will then change to either “DAY TEMP” (fig. 29) mode or “NIGHT TEMP” mode (fig 30). To alternate between the 2, press the “SET”...
  • Page 31 3.2.3 Operation of the Fire in “TIMER” mode In order to change the mode of operation from “MANUAL” to “TIMER”, press the “SET” button, the fire will then alternate between the settings until the “TIMER” mode is displayed. NOTE : The “SET” button allows you to alternate between all modes of operation :- “...

  • Page 32: Fitting The Handset Wall Bracket

    3.2.4 Low Battery Signal When the battery in the handset needs replacing, “BATT” will be displayed on the handset. Remove the cover on the rear of the handset and replace the 9V battery as necessary. 3.2.5 To Set the Time on the Remote Handset Simultanelously press the “UP”...

  • Page 33: Checking For Clearance Of Combustion

    CHECKING FOR CLEARANCE OF COMBUSTION PRODUCTS Close all doors and windows in the room. Light the fire and allow to run for approximately 5 minutes on high position. After approximately 5 minutes hold a smoke match just 10mm inside and below the centre of the lower front edge of the top of the fire, as shown below in fig.

  • Page 34: Removal / Re-Fitting The Restrictor Baffle

    REMOVING / RE-FITTING THE FLUE RESTRICTOR BAFFLE The restrictor baffle is secured with 2 off screws to the spigot area of the fire. Remove the fire if necessary from the fireplace opening and unscrew or re-fit the baffle as shown below in fig. 33 Fig.

  • Page 35: Maintenance

    SECTION 4 MAINTENANCE Servicing Notes Servicing should be carried out annually by a competent person such as a GAS SAFE registered engineer. This is a condition of the guarantee schemes. The service should include visually checking the chimney and fire opening for accumulations of debris and a smoke test to check for a positive up-draught in the chimney.

  • Page 36: Removal Of The Oxypilot

    Removing the Pilot Assembly. Note : Because this appliance is fitted with an atmosphere sensing ‘Oxy- Pilot’ it is not possible to replace the thermocouple separately, because the thermocouple position is factory set to a tight tolerance. Any replacement of parts on the pilot requires a complete new pilot assembly.

  • Page 37: Spare Parts Shortlist

    GAS SAFE registered gas installer. The part numbers of the main replaceable parts are as follows, these are available from your local BFM Fires stockist, whose details can be found on the BFM Europe website, in the “stockist” section.

  • Page 38: Conditions Of Installation / About Your New Gas Fire

    This should be considered when installing or decorating. The Model number of this appliance is as stated on the rating plate affixed to the control panel of the fire and the appliance is manufactured by:- BFM Europe Ltd. Trentham Lakes Stoke on Trent...

  • Page 39: Important Safety Information

    About your BFM Fires “Avelli” Gas Fire The BFM Fires Avelli range of log effect gas fires incorporates a unique and highly developed fuel bed which gives the realism of a loose log layout combined with realistic flames and glow. The use of durable ceramic material in the construction of the fuel-bed components ensures long and trouble free operation.

  • Page 40: Operating The Fire

    OPERATING THE FIRE IMPORTANT : IF THE BURNER IS EXTINGUISHED FOR ANY REASON YOU MUST ENSURE THAT YOU WAIT A FULL FIVE MINUTES BEFORE ATTEMPTING TO RE-LIGHT THE FIRE. The product is controlled by the remote handset supplied with the fire. Ensure the 9V battery as supplied in the loose items pack has been fitted to the fire before attempting to light it.
  • Page 41 With the product in “MANUAL” mode the fire can now be switched between HIGH rate heat input and LOW rate heat input by pressing the “DOWN” arrow on the handset. To reduce the flame height of the main burner incrementally, press the arrow momentarily. To reduce the heat input directly down to the minimum level, press and hold the “DOWN”...
  • Page 42 5.2.2 Operation of the Fire in “TEMPERATURE” mode In order to change the mode of operation from “MANUAL” to “TEMPERATURE”, press the “SET” button, the fire will then change to either “DAY TEMP” (fig. 4) mode or “NIGHT TEMP” mode (fig 5). To alternate between the 2, press the “SET”...
  • Page 43 5.2.3 Operation of the Fire in “TIMER” mode In order to change the mode of operation from “MANUAL” to “TIMER”, press the “SET” button, the fire will then alternate between the settings until the “TIMER” mode is displayed. NOTE : The “SET” button allows you to alternate between all modes of operation :- “...
  • Page 44 5.2.4 Low Battery Signal When the battery in the handset needs replacing, “BATT” will be displayed on the handset. Remove the cover on the rear of the handset and replace the 9V battery as necessary. 5.2.5 To Set the Time on the Remote Handset Simultanelously press the “UP”...

  • Page 45: Removal / Re-Fitting The Glass Frame Assembly

    REMOVAL / RE-FITTING THE GLASS FRAME ASSEMBLY Remove the glass panel by firstly affixing the glass clamp to the glass panel as shown below in fig. 8 Fig. 8 Unclip the glass frame retaining clips at the base of the glass frame assembly as shown in fig.
  • Page 46 Unhook the glass panel from the top retaining channel by lifting upwards then tilt the top edge of the glass assembly towards you as shown below in fig. 10 (sectional view through product for clarity) Fig. 10 Remove the glass frame assembly by sliding to the left until the right hand edge of the glass frame can be released from behind the right hand leg of the surround as shown below in fig.
  • Page 47 Fig. 12 R/H edge of glass frame Store the glass frame assembly in a safe place. Re-assemble in reverse order when re-fitting the glass assembly. Ensure that the glass assembly is correctly located on the top flange of the combustion chamber, this can be achieved by putting your hand onto the top edge of the glass frame inside the convection air aperture and pushing down firmly to check the glass frame is correctly located.

  • Page 48: Removal / Replacement Of The Fuelbed

    RE-LAYING THE FUEL-BED Place the L/H and R/H ceramic base pieces onto the ceramic support panel as shown below in fig. 13 Fig. 13 Place the front ceramic base piece onto the ceramic support ensuring the location tabs fit into the L/H & R/H ceramic base pieces as shown below in fig.
  • Page 49 Place the base log onto the ceramic support panel as shown below in fig. 15, ensuring the spacer locating blocks on the rear face are fitted flush up against the rear panel. Fig. 15 Ensure spacer blocks are fitted flush to the rear panel Cover the burner and fuel-bed base ceramic in a single, even layer of bark chippings as shown below in fig.
  • Page 50 Position log “H” onto the base log using the location lug on the back face of log “H” and the groove on the base log to find the correct location, as shown below in fig. 17 Fig. 17 Log H Position log “E”...
  • Page 51 Position log “B” onto the base log using the location lug on the back face of log “B” and the groove on the base log to find the correct location as shown below in fig. 19 Fig. 19 Log B Position log “G”...

  • Page 52: Cleaning The Fire

    Re-fit the glass frame assembly before proceeding. Warning : Use only the log fuel-bed supplied with the fire. When replacing the log fuel-bed remove the old log fuel-bed and discard it. Fit a complete log fuel-bed from the manufacturer, only use genuine replacements. THE FOLLOWING STATEMENT IS APPLICABLE TO ALL FUEL-BED TYPES This appliance uses fuel effect pieces containing Refractory Ceramic Fibres (R.C.F.), which are man-made vitreous silicate fibres.

  • Page 53: User Replaceable Parts

    GAS SAFE registered gas installer. The part numbers of the user replaceable parts are as follows, these are available from BFM Europe Ltd. who may be contacted at the number on the rear cover of this book.

  • Page 54: Bfm Europe Ltd

    Due to our policy of continual improvement and development the exact accuracy of descriptions and illustrations cannot be guaranteed. Part No. B-146240 Issue 3 BFM Europe Ltd. Trentham Lakes Stoke-on-Trent Staffordshire ST4 4TJ www.bfm-europe.com Telephone - General Enquiries : (01782) 339000...
