Selectronic Australia SE10 Operating Manual

24 volt sine wave inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SE10 - 24 Volt Operating Manual
o
Serial N
_____________________________ Purchase Date ______________
Note - Your 2 Year Warranty can only be valid once your
warranty card is completed and returned to Selectronic Australia
S
E L E C T R O N I C
A
U S T R A L I A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SE10 and is the answer not in the manual?

Questions and answers

Related Manuals for Selectronic Australia SE10

Summary of Contents for Selectronic Australia SE10

  • Page 1 _____________________________ Purchase Date ______________ Note - Your 2 Year Warranty can only be valid once your warranty card is completed and returned to Selectronic Australia E L E C T R O N I C U S T R A L I A...

  • Page 2: Table Of Contents

    SE10-24 Volt Owners Manual Contents Page No. Introduction Warranty Card Installation Batteries and Connections System Wiring Getting Started Quickly Parts Identification Operation STATUS Indicators 9-10 Voltmeter Auto Start Setting 11-12 Low Voltage Shutdown Setting Maintenance Inverter Batteries 13-14 Other System Components...

  • Page 3: Introduction

    Introduction Thank you for choosing to purchase the Selectronic SE10 TRUE SINE WAVE inverter. Many hours of Research and Development have gone into the SE10 to ensure this inverter provides you with many years of reliable service Warranty Card It is imperative that you complete your warranty card NOW. Your SE10 is covered by a TWO year warranty.
  • Page 4 Large amounts of DC current can be drawn by your SE10, care must be taken. Fixed Installation All fixed installation battery connections must be securely bolted, using stainless steel nuts and bolts. To protect the connection from corrosion smear a small amount of Vaseline or similar over the joint.
  • Page 5 (see your auto electrician). The SE10 has sufficient battery cable length to allow it to sit underneath the vehicle whilst in use. If the ground is wet, place the SE10 on a waterproof liner.

  • Page 6: Batteries And Connections

    To achieve maximum performance from your SE10 you must have a battery capable of delivering 50 Amps for a short period whilst maintaining at least 21 volts. To provide a 24 volt supply to your SE10 you will need to join more than one battery together.
  • Page 7 As a general guide never discharge a battery below 50%. The deeper a battery is discharged on a regular basis, the less life you can expect from the battery. See you battery specifications for full details. SE10 Manual Selectronic Australia...
  • Page 8 RAPS System Wiring Diagram SE10 Manual Selectronic Australia...

  • Page 9: System Wiring

    System Wiring Your SE10 may form part of a complete power system, If this is the case, the diagram on page 6 may give you a guide. See your designer / installer for full details. Electrician’s Note • All earth’s AC and DC should be bonded •...

  • Page 10: Parts Identification

    SE10 Parts Identification SE10 Manual Selectronic Australia...

  • Page 11: Operation

    ON. Once the load has been removed (e.g. the light switch is turned off) the inverter will wait 10 seconds and return to SLEEP mode. It is good practice to have your SE10 in SLEEP mode as often as possible. When the SE10 is in SLEEP mode it uses 0.045 amps from the battery, when the inverter is in the ON mode it uses at least 0.3 amps from the battery.
  • Page 12 LED (2) AC Overload should normally remain OFF. If the inverter shuts down due to too much AC load being drawn from it then LED (2) will come ON. The SE10 will remain in this condition for 1 minute after the AC load has been decreased to a safe level.

  • Page 13: Voltmeter

    LED (6) begins to flash, (approximately 1 second) indicating you are ready to adjust this setting. The SE10 will leave the factory with a setting of 4 watts. Now press the Mode button (7) until the desired value is sought.

  • Page 14: Low Voltage Shutdown Setting

    Low Volts Adjust LED (6) (red) ON To avoid total discharging of your battery the SE10 shuts down at a pre-set low voltage. As all batteries are different, so too is the minimum voltage they should be discharged to.

  • Page 15: Maintenance

    Maintenance Inverter Periodic maintenance of your SE10 inverter involves little more than checking for any obstructions to the black cooling heatsink at the rear of the inverter. The heatsink must be cleared of any accumulated foreign matter that may have lodged itself between the fins since the last maintenance check, e.g.

  • Page 16: Other System Components

    This will indicate the inverter's operation by flashing when the inverter is in SLEEP mode and remaining ON when the inverter is brought ON by a load. SE10 Manual Selectronic Australia...

  • Page 17: Radio Frequency Interference

    Connection from the aerial to the radio should be via a low loss coaxial cable. Please note the aerial must be an AM RADIO type; a TV aerial will not work. SE10 Manual Selectronic Australia...

  • Page 18: Fault Finding

    (as described in Handy Hint, check to see if the SE10 returns to pulsing (SLEEP) mode after a 10 second delay. Once you have found the offending appliance, increase the sensitivity of the “Auto Start”...

  • Page 19: Product Warranty Conditions

    Product Warranty Conditions Selectronic Australia Pty Ltd warrants your SE10 inverter to be free from defects in materials and workmanship under normal use and service, for an initial period of two (2) years. This warranty is applicable only from the date of original purchase.

  • Page 20: Specifications

    SE10 24 Volt Specifications Inverter Type Microprocessor control circuit with PWM full bridge power stage. True sine wave AC output Current draw from Battery Condition Amperage Auto Start SLEEP mode (average) 0.045 Amps Inverter ON, with no Load 0.30 Amps Maximum Continuous Load (350 Watt) 17.5 Amps...
  • Page 21 -10º C to 50º C Transformer Type Toroidal Cooling Method Convection Power Point 10 Amp Single Pole Weight 4.6 kg Shipping Weight 5.2 kg Chassis Material Zinc Coated Steel Chassis Coating Powder Coated Size 176W x 122H x 260mm D SE10 Manual Selectronic Australia...

  • Page 22: Selectronic Service Network

    Selectronic Authorised Service Network If service is required, contact your supplier or return your inverter in its original carton with proof of purchase to any of the following service centres. Selectronic Australia Pty Ltd Rainbow Power Company 25 Holloway Drive...
  • Page 23 Notes: SE10 Manual Selectronic Australia...
  • Page 24 E L E C T R O N I C U S T R A L I A 25 Holloway Drive Bayswater, Victoria 3153 Australia Phone 03 9762 4822 03 9762 9646 Email sales@selectronic.com.au Part No ST-M-SE102 REV-3 9/8/2000 SE10 Manual Selectronic Australia...
