    INTRODUCTION Thank you for your purchase of the Selectronic Sine wave inverter, model WM1500-24V. Your WM1500 is a state-of-the-art high performance TRUE SINE WAVE DC-AC Inverter. Many hours of development time have been invested in the WM1500 so that we can provide you with a reliable high quality inverter.
  • Page 3 300mm 30mm 300mm 160mm DEMAND START STATUS 16 Watts AC Volts ON PO W E R 12 Watts AC Overload 8 Watts DC Volts Low/High 4 Watts TEMP Over load Demand Start Adj ust Al arms O ff Low Volts Adjust DC PO WER Mode PROUDLY DESIGNED &...

  • Page 4: Batteries

    You must have a suitable 24V DC battery bank that is maintained and operated to the battery manufacturer’s recommendation. To ensure operation to WM1500 specification, the battery bank should have a minimum capacity of 500 ampere hours at the 100 hour discharge rate 24V systems (ask your supplier if in doubt).
  • Page 5 Verify that the circuit breaker on the front panel is in the OFF position, LEVER DOWN. Now connect the battery cables. BATTERY POSITIVE (+) BLACK BATTERY NEGATIVE (-) These connections should be tight. If using nuts, bolts and washers, they should be stainless steel. At this point re-check the connections before proceeding any further.

  • Page 6: Operation

    OPERATION STANDBY mode means that the WM1500 is producing pulses of power to sense when an appliance is switched on. This is called the demand start because as soon as the appliance is switched on, the WM1500 will turn on and provide full power to the appliance. The inverter will drop back into standby mode once all loads have been switched off for longer than 10 seconds.

  • Page 7: Demand Start Adjust - Led 5 (Green) On

    LED 1 Stays ON, the inverter has been commanded to provide power to the load (e.g. a light switch has been turned on) so it has gone from SLEEP mode to ON. Once the load has been removed (e.g. the light switch is turned off) the inverter will wait 10 seconds and return to SLEEP mode.

  • Page 8: Low Volts Adjust - Led 5 (Green) Flashing

    LED 1 DEMAND START STATUS 16 Watts AC Volts ON LED 2 12 Watts AC Overload LED 3 8 Watts DC Volts Low/High 4 Watts TEMP Overload LED 4 Demand Start Adjust Alarms LED 5 Low Volts Adjust Mode Button Mode Demand Start Wattage LED 1...

  • Page 9: Handy Hint

    After “23.0 Volts”, the next button press “rolls back” the Low DC Volts Cut-out setting to “20.0 Volts” HANDY HINT It is very important that you become familiar with the functioning of your Inverter. Since most Inverters are not within sight, it is not always easy to know what STATUS your inverter is in. An easy way to determine this is to plug a small child's night-light (neon type) into a power point that is easily visible, or replace any power point with a neon indicator type.

  • Page 10: Fault Finding

    FAULT FINDING 1. INVERTER STAYS ON EVEN WHEN NO APPLIANCE IS BEING USED. Some appliances such as Microwave Cookers or Video Recorders still draw current when not in use. This is to power their displays. This is a common problem known as a "phantom load", but it can be easily overcome with the WM1500.

  • Page 11: System Maintenance

    SYSTEM MAINTENANCE To get the optimum performance from your WM1500 power inverter, particularly under heavy appliance loads, it is essential that the battery bank and the DC wiring all be in good condition. The small amount of time spent on the maintenance tasks below will maximise the reliability of your system.

  • Page 12: Wm1500 Electrical Specifications

    WM1500 ELECTRICAL SPECIFICATIONS INVERTER TYPE PWM Full Bridge power stage, with true sine wave AC output. SELECTRONIC WM1500 INVERTER SPECIFICATIONS ELECTRICAL PARAMETER WM1500 CONDITION Output Power 1,500 watts Max Continuous @ 25 °C Ambient 2,250 watts 1/2 Hour Rating 4,500 watts Max Surge Output Power 1,400 watts...

  • Page 13: Radio Frequency Interference

    RADIO FREQUENCY INTERFERENCE For many years, Radio Frequency Interference (RFI) has been an annoying problem for owners of Inverters. RFI in a domestic situation may produce noise or interference on a radio or TV receiver. Most of the problems with RFI in a Remote Area Power Supply (RAPS) installation involves AM radio reception.

  • Page 14: Using A Selectronic Keypad With The Wm1500-24

    USING A SELECTRONIC KEYPAD WITH THE WM1500-24 SERIAL PORT WIRING Serial Port Data Cable Wire Colour Function Pin Number RATINGS LABEL White with green stripe Transmit + Green Transmit - Serial Port White with orange stripe Receive + Blue +15V White with blue stripe Orange Receive -...

  • Page 15: Status

    STATUS When you turn on the WM1500 with a keypad installed, the keypad screen will be displayed. Press NEXT DISPLAY twice. Press NEXT twice WM1500 1.00 2000 The inverter STATUS will be displayed. The inverter can have one of three status conditions. When first turned on it will show STANDBY mode.
  • Page 16 AC Load readings (second button press)

  • Page 17: Settings (Keypad Light Blue Keys)

    The AC Amps reading shows the total current drawn from the AC output by AC Amps : 2.5A the appliances connected to the inverter. This reading is also handy for --- Readings --- knowing how much power a particular appliance draws. Pressing the AC LOAD READINGS button again will move back to the previous “AC Volts”...

  • Page 18: Options (Keypad Light Blue Keys)

    OPTIONS (Keypad Light Blue Keys) Press the Keypad OPTIONS Light Blue Key. This display allows access to logged alarms. -END- Press the OPTIONS key to scroll through logged alarms. --Alarms-- If there are no logged alarms, only this screen will be displayed. When in this END ALARMS screen, press any grey keypad key to return you to the STATUS menu.

  • Page 19: Warning

    AC wiring in your system. PRODUCT WARRANTY CONDITIONS Selectronic Australia Pty Ltd warrants your WM1500 inverter to be free from defects in materials and workmanship under normal use and service, for an initial period of five (5) years.
