At Least 1.5°
D
Heating
© Baxi Heating UK Ltd 2007
G
A
B
360° Orientation
C
F
32.5 mm
Condensate
Drain
65 mm
65 mm
Domestic Hot
Flow
Water Outlet
(22mm)
(15mm)
Dimensions
A 780mm
E
B 345mm
C 450mm
D 116mm Ø Min.
E 185mm
(207mm for 80/125mm
flue systems)
F 145mm
G 131mm
H 180mm
H
Tube Ø 100mm
Tap Rail
65 mm
Gas
Cold Water
Inlet
Inlet
(22mm)
(15mm)
5.0 Dimensions and Fixings
65 mm
65 mm
Heating
Pressure Relief
Return
Valve
(22mm)
(15mm)
11
