- Page 1 OPERATION MANUAL MBP-100MP Series Multi Format Player MBP-100MP64G MBP-100MP128G Edition...
- Page 2 Description Section/Page 2012/02/03 ※ MediaConcierge is a trademark of FOR-A Company Limited. ※ XDCAM is a trademark of Sony Corporation. ※ AVC-Intra and DVCPRO are trademarks of Panasonic Corporation. ※ AVCHD is a trademark or registered trademark of Panasonic Corporation and Sony Corporation.
- Page 3 Precautions Important Safety Warnings [Power] Operate unit only on the specified supply voltage. Caution Disconnect power cord by connector only. Do not pull on cable portion. Do not place or drop heavy or sharp-edged objects on power cord. A damaged cord can cause fire or electrical shock hazards.
- Page 4 [Circuitry Access] Do not remove covers, panels, casing, or access circuitry with power applied to the unit! Turn power off and disconnect power cord prior to removal. Internal servicing / adjustment of unit should only be performed by qualified personnel. Do not touch any parts / circuitry with a high heat factor.
- Page 5 MBP-100MP units and their accessories are fully inspected and adjusted prior to shipment. Operation can be performed immediately upon completing all required connections and operational settings. Check your received items against the packing lists below. ITEM REMARKS MBP-100MP64G MBP-100MP128G AC Cord 1 set Rack Mount Brackets 1 set...
-
Page 6: Table Of Contents
Table of Contents 1. Prior to Starting ........................1 1-1. Welcome ........................... 1 1-2. Features ..........................1 1-3. Notes on Using The MBP-100MP ..................1 2. Panel Descriptions ........................2 2-1. Front Panel ........................2 2-2. Rear Panel ........................3 2-3. -
Page 7: Prior To Starting
FOR-A provides a wide range of products, from basic support units to complex system controllers, which have been increasingly joined by products for computer video based systems. Whatever your needs, talk to your FOR-A representative. We will do our best to be of continuing service to you. -
Page 8: Panel Descriptions
2. Panel Descriptions 2-1. Front Panel MBP-100MP MULTIFORMAT PLAYER POWER POWER ACT USB 1 USB 2 RESET Name Description Lit green Power is supplied to the unit. POWER Unlit Power is not supplied to the unit. Status Not used Indicators Unlit All cooling fans are operating properly. -
Page 9: Rear Panel
2-2. Rear Panel LAN2 LAN1 USB4 USB3 12 13 Name Description For external reference signal input (Black Burst signal or Tri-level sync signal). Either one of two connectors can be used to input the reference signal. If one connector is used to input a reference GENLOCK signal, the other is used as a loop through output to pass through the signal. -
Page 10: Serial Interfaces
2-3. Serial Interface 2-3-1. REMOTE 9-pin D-sub, female inch type screws Connector Pin Assignment Pin No. Signal Description Frame ground Transmit data (-) Receive data (+) Signal ground No connection Signal ground Transmit data (+) Receive data (-) Frame ground 2-3-2. -
Page 11: Parallel Interface
2-4. Parallel Interface 15-pin D-sub, female Inch type screws Connector Pin Assignment Pin No. Signal Description Signal ground － POW ALARM Power alarm output (*1) FAN ALARM Fan alarm output (*1) Not used － GPI IN3 GPI input (*2) GPI IN2 GPI input (*2) GPI IN1... - Page 12 Alarm output MBP-100MP Max:30V Relay contact POW ALARM Closed when a Relay contact malfunction FAN ALARM occurs or power is off. COMMON GPI IN Circuit GPI input behaves as below. The circuit between the GPI IN pin and Ground pin are closed: The function is ON. The circuit between the GPI IN pin and Ground pin are open: The function is OFF.
-
Page 13: Connection
3. Connection Connect peripheral devices as depicted as follows. IMPORTANT Serial control via REMOTE can only be used for one-way, VTR control or controlled. MXF files stored on the built-in SSD are converted to HD/SD-SDI signals and output from the MBP-100MP. -
Page 14: Genlock Settings
3-1. Genlock Settings The vertical and horizontal system phases applied to the output video can be adjusted with the genlock signal on the MC Server Tool. IMPORTANT To use the MC Server Tool, connect a VGA monitor, a mouse and a keyboard. Note that all applications should be closed before starting the MC Server Tool. - Page 15 4. Adjust genlock phase. Adjust the genlock phases by using sliders or entering numeric values. H Phase Adjust the horizontal phase by using the slider or entering the numeric value. TV Format Setting Range Step value Default -1100 to +1099 1080/59.94i （-14.83μs to +14.81μs）...
-
Page 16: How To Change Network Settings
4. How to Change Network Settings The Windows Operation System (Microsoft Windows XP Embedded) is installed in the MBP-100MP. There are a few cases in which users will need to change network settings in order to use the MBP-100MP over a network. This section describes how to change the computer name and IP address for such cases. - Page 17 4. The following message appears. Check that Boot Command is set to DISABLE, and then press any key on the keyboard once. Windows automatically restarts. ** Enabling overlay Protected Volume Configuration Type State DISABLED Boot Command DISABLE Param1 Param2 Persistent Data '' '' Volume ID XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX...
-
Page 18: Changing The Computer Name
4-3. Changing the Computer Name 1. Right-click My Computer, and then click Properties. 2. A dialog box as shown below opens. Click Change. 3. Type a new name for the computer in the Computer name box, and click OK. - Page 19 4. The confirmation dialog box appears. Click OK. 5. The screen returns to the dialog box that appeared in step 3. Click OK. 6. The dialog box as shown below appears. If you want to continue to change the settings, click No.
-
Page 20: Changing The Ip Address
4-4. Changing the IP Address 1. Right-click My network places, and then click Properties. 2. Right-click LAN1, and then click Properties. 3. A dialog box as shown below appears. Double-click Internet Protocol(TCP/IP). -
Page 21: Enabling Write-Protection
4. Enter a new IP address, Subnet mask and other necessary setting values that suit your network, and then click OK. 5. It returns to the dialog box that appeared in step 3. Click OK. Other drivers can be installed in the same manner. 4-5. -
Page 22: Specifications And Dimensions
Process Control Video level: 0.0% to 200.0% Chroma level: 0.0% to 200.0% Black level: -20.0% to 100.0% Chroma phase: -179.8° to 180.0° Storage Capacity MBP-100MP64G Actual storage capacity: 64 GB (SSD) MBP-100MP128G Actual storage capacity: 128 GB Interfaces 15-pin mini D-sub (female) x 1 USB 2.0 Series-A type connector x 4 (2 ports on front panel, 2 ports on... -
Page 23: External Dimensions
5-2. External Dimensions (All dimensions in mm.) 4-6.4X12 MBP-100MP MULTIFORMAT PLAYER POWER POWER USB 1 USB 2 RESET... -
Page 24: Appendix. How To Reset Bios
Appendix. How to Reset BIOS This appendix explains how to reset the BIOS. Please follow the procedure below in case you need to reset the BIOS due to the battery failure or such reason. 1. Opening the BIOS Setup Menu 1. -
Page 25: Setting Procedure
On the BIOS SETUP UTILITY screen, set the values for the menus as shown below. The detailed procedure is given in the following section. Item Top Menu Top Menu (a) Submenu (b) Value Main System Time Current time System Date Current date Advanced Floppy Configuration... - Page 26 (2) Set the Floppy Configuration parameters in the Advanced menu on the menu bar. Advanced menu screen (a) On the menu bar, select Advanced using the right and left arrow keys. (b) Select Floppy Configuration using the up and down arrow keys, and press Enter. The Floppy Configuration menu will be displayed.
- Page 27 * After you finish the setting, verify that the value in the square brackets opposite the item is set to Disabled. The Esc key on the keyboard allows you to return to the previous screen. (3) Set the Boot Settings Configuration parameters and Boot Device Priority in the Boot menu on the menu bar.
- Page 28 Boot Settings Configuration menu (c) Set Wait For ‘F1’ If Error to Disabled. Select Wait For ‘F1’ If Error using the up and down arrow keys. Press Enter. The Options window as shown below appears. Select Disabled, and press Enter. * After you finish the setting, verify that the value in the square brackets opposite the item is set to Disabled.
- Page 29 (d) Set the Boot Device Priority. Select Boot Device Priority using the up and down arrow keys, and press Enter. The Boot Device Priority menu will be displayed. Boot Device Priority menu (e) Set 1st Boot Device to HDD: xxxxxxx. Select 1st Boot Device using the up and down arrow keys.
- Page 30 * After you finish the setting, verify that the value in the square brackets opposite the item is set to HDD: xxxxxxx. The Esc key on the keyboard allows you to return to the previous screen. (4) Set the South Bridge Chipset Configuration parameters in the Chipset menu on the menu bar.
- Page 31 South Bridge Chipset Configuration menu (c) Set Restore on AC Power Loss to Power On. Select Restore on AC Power Loss using the up and down arrow keys. Press Enter. The Options window as shown below appears. Select Power On, and press Enter.
- Page 33 Warning This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
- Page 34 FOR-A America East Coast Office 2 Executive Drive, Suite 670, Fort Lee Executive Park, Fort Lee, NJ 07024, USA Phone: +1-201-944-1120 Fax : +1-201-944-1132 FOR-A America Distribution & Service Center 2400 N.E. Waldo Road, Gainesville, FL 32609, USA Phone: +1-352-371-1505 Fax: +1-352-378-5320...
