Phase CI110 II Owner's Manual

OWNER'S MANUAL & INSTALL GUIDE
R
T E C H N O L O G Y
[CI CUSTOM INSTALLATION SERIES] CI110 II
FOR EFFICIENT INSTALLATION, YOU WILL NEED THE FOLLOWING TOOLS: • ELECTRIC SCREWDRIVER (DRILL) WITH PHILIPS BIT • TAPE MEASURE
• STUD-FINDER • 3/32" STANDARD SCREWDRIVER • DRYWALL SAW OR KNIFE • BUBBLE LEVEL • PENCIL
SPEAKER/BAFFLE ASSEMBLY
AIMABLE
TWEETER
BAFFLE
CLAMP
SCREWS
(6x)
Thank you for purchasing the Phase Technology
system. The mounting frame of extruded aluminum has a uniquely designed self-aligning
clamping system to secure the flange assembly to the drywall. This patent pending design
simplifies installation and reduces unwanted wall vibration resulting in improved performance
and definition.
All CI Series speakers include self-resetting solid-state PTC protection circuits. This unique
system is able to detect when the speaker is being over-driven and lowers the speaker
volume until the problem is corrected. The PTC device then resets itself for normal operation.
Regardless of application, serious audiophile listening or home theater, we recommend
that you take the time to read this manual thoroughly before connecting speakers to your
amplifier or receiver. In the highly unlikely event that you should experience a problem with
set-up or operation, please contact one of our authorized dealers for assistance, or contact
us directly.
[GETTING STARTED]
FLANGE ASSEMBLY
CI110 II high definition in-wall speaker
®
GRILLE
Phase Technology
®
8005 W. 110th St., Suite 208
Overland Park, KS 66210
855.663.5600 (Domestic)
+1.913.663.5600 (International)
913.663.3200 (Fax)
SAFETY INSTRUCTIONS
INSTALLATION GUIDELINES
SPEAKER INSTALLATION
CARING FOR YOUR SPEAKER
MAINTENANCE AND SERVICE
WARRANTY
SPECIFICATIONS
SELF-ALIGNING
CLAMPING SYSTEM
Corporation
2
3
3
4
4
4
4
