1 P Re-Test Preparations
H Ardware
L Iquid Intrusion Indicator Inspection
S Oftware
Software Update
X10/SO-01B Gesture Lock Reset
2 T Ests
S Ervice Test Mode
S Ervice Tests
Keyboard & Switch
Touch Screen
Display
Led/Illumination
Speaker
Earphone
Microphone
Vibrator
Camera
Flash LED
Bluetooth
Wlan
Gps
Compass
Accelerometer
Proximity Switch
Real Time Clock
Total Call Time
External Memory Card
Security
M Anual Tests
1 B S IM
On/Off Key Test
Home Key Test
Light Sensor
2 B B Attery Charging
Network Test
4 B O N-The-Air Call to Mobile (no UMTS Network Available)
5 B O N-The-Air Call to Mobile (UMTS Network Available)
3 R Evision History
Sony Ericsson Mobile Communications AB – Company Internal
Advertisement
Quick Links
Download this manual
See also:
User Manual
Test Instructions
- mechanical -
X10i, X10a,SO-01B
1230-2323 Rev 1
©
Sony Ericsson Mobile Communications AB – Company Internal
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Need help?
Do you have a question about the Xperia X10i and is the answer not in the manual?
Ask a question
Questions and answers
Related Manuals for Sony Ericsson Xperia X10i
Cell Phone Sony Ericsson Xperia X10i Extended User Manual
Sony ericsson xperia x10i: user guide (100 pages)
Cell Phone Sony Ericsson X10i Working Instructions
(81 pages)
Cell Phone Sony Ericsson Xperia X10i User Manual
(31 pages)
Cell Phone Sony Ericsson X1ASILVER User Manual
User guide (40 pages)
Cell Phone Sony Ericsson XPERIA X1 User Manual
Sony ericsson cell phone user manual (26 pages)
Cell Phone Sony Ericsson Xperia X1a Important Information Manual
Warranty information (21 pages)
Cell Phone Sony Ericsson Xperia X10US Extended User Manual
User guide (113 pages)
Cell Phone Sony Ericsson Xperia X10 mini Extended User Manual
User guide for android 2.1 (99 pages)
Cell Phone Sony Ericsson X10 mini pro Extended User Manual
Xperia (85 pages)
Cell Phone Sony Ericsson X10 Extended User Manual
Sony ericsson cellphone user manual (85 pages)
Cell Phone Sony Ericsson Xperia Pureness User Manual
Sony ericsson xperia pureness: user guide (52 pages)
Cell Phone Sony Ericsson R800AT Extended User Manual
User guide (103 pages)
Cell Phone Sony Ericsson Xperia neo Extended User Manual
Sony ericsson xperia neo: user guide (113 pages)
Cell Phone Sony Ericsson Xperia Mini Extended User Manual
Sony ericsson xperia mini: user guide (114 pages)
Cell Phone Sony Ericsson Xperia mini pro Extended User Manual
User guide (116 pages)
Cell Phone Sony Ericsson Xperia Mini Pro Test Instructions
(22 pages)
Summary of Contents for Sony Ericsson Xperia X10i
Page 1
Test Instructions - mechanical - X10i, X10a,SO-01B 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal...
Page 2: Table Of Contents
3 5 B O n-the-air call to mobile (UMTS network available) ........ 15 2 B R evision History ................16 For general information about test procedures, refer to 1220-1333: Generic Repair Manual - mechanical 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 2(16)
Page 3: P Re-Test Preparations
If affected (red color) - handle the phone according to your local directives. If not affected by liquid, proceed to the ‘Pre-Test Preparation’ below. 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 3(16)
Page 4: S Oftware
• Press and keep the Back key down on the phone, connect the phone to the USB cable and release the Back key. • When prompted, select the ‘X10/SO-01B Gesture Lock Reset’ service and Flash. 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 4(16)
Page 5: T Ests
• to stop the test and return to the ‘Service tests’ menu, press the Back key For more information, refer to 1220-1333: Generic Repair Manual - mechanical 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 5(16)
Page 6: S Ervice Tests
White, Black, Red, Green, Blue colors on full screen. Make sure that there are no missing segments and that the colors and contrast are OK. Press Back key to return to Service Test Menu. 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 6(16)
Page 7: Led/Illumination
Press Volume up/Volume down key to adjust earphone volume. Press Back key to return to Service Test Menu. XPERIA 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 7(16)
Page 8: Microphone
Press the camera key to preview the photo’s quality about auto focus. Photos is taken but not saved during this test! Press Back key to return to Service Test Menu. 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 8(16)
Page 9: Flash Led
Step 4: Select the Target WLAN network, and Type Password to get connection; Step 5: when Connection succeeded, it shows “Test Complete”. Press Back key to return to Service Test Menu. 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 9(16)
Page 10: Gps
The accelerometer test displays the actual position of the Accelerometer X: 0,1234 phone as a 3D coordinate X:Y:Z Y: 6,7890 Z: 0,1234 Press Back key to return to Service Test Menu. XPERIA 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 10(16)
Page 11: Proximity Switch
During the actual test the text ‘Real time clock test’ is displayed, then followed by a message stating whether the test was OK or not. Press Back key to return to Service Test Menu. 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 11(16)
Page 12: Total Call Time
The DRM keys are shown in the display. There’re may be some different content showed based on the different market software versions. Press Back key to return to Service Test Menu. 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 12(16)
Page 13: M Anual Tests
Home key and then phone will go back to the Stand by screen directly. When phone is in Sleep mode, Press Home key and the Phone will be waked up. 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 13(16)
Page 14: Light Sensor
• Verify that the phone is being charged by Notification LED and Battery icon; • Remove the USB cable from the system connector and verify that Notification LED and Battery icon no longer indicates charging. 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 14(16)
Page 15: Network Test
Ensure that the UMTS/3G icon now is visible at the top of the display. To verify the radio functions (UMTS) of the phone, follow the ‘2.4.1.1 Procedure’ above. 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 15(16)
Page 16: R Evision History
Test Instruction Repair Instruction Mechanical/ R evision History Rev. Date Changes / Comments 2010-03-24 Initial version 1230-2323 Rev 1 © Sony Ericsson Mobile Communications AB – Company Internal 16(16)
