2.2 Mechanical specification

Specifications
Product Name HEXA01
Data Transfer Rate 2.25 Gbps
Frequency Range 25 – 165 Mhz
Input Signal Single link HDMI
Output Signal
Single link HDMI, SPDIF and Stereo audio
Up to WUXGA(1920X1200) 60Hz
Supported Resolution
480P~1080i/P
DC Power Jack,
Input Connector Type
19-pin Type A HDMI female
19-pin Type A HDMI female
Output Connector Type
S/PDIF coaxial digital audio
5-pin 3.5mm detachable terminal block
HDMI Ver1.4
Standard
Compliant with High-bandwidth Digital Content Protection (HDCP) using
DVI and HDMI standards
Power Consumption DC +12V 3A, 36W Max
Dimensions 4.7''(w) x 4.4'(D)' x 1.5''(H) mm
Net Weight 1 lb
