HEXA-01 Owner's Manual
HEXA-01
HDMI Audio Extractor with Downmixing
TM
PureLink
535 East Crescent Avenue
Ramsey, NJ 07446
USA
Tel: +1.201.488.3232
Fax: +1.201.621.6118
E-mail:
sales@purelinkav.com
www.purelinkav.com
For order support, please contact your local dealer.
For technical support, please contact us at
support@purelinkav.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HEXA-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for PureLink HEXA-01

  • Page 1 HEXA-01 Owner’s Manual HEXA-01 HDMI Audio Extractor with Downmixing PureLink 535 East Crescent Avenue Ramsey, NJ 07446 Tel: +1.201.488.3232 Fax: +1.201.621.6118 E-mail: sales@purelinkav.com www.purelinkav.com For order support, please contact your local dealer. For technical support, please contact us at support@purelinkav.com...

  • Page 2: Table Of Contents

    PureLink by Dtrovision ABLE OF ONTENTS Chapter 1. Introduction 1.1 Safety Precautions -------------------------------------------------------------- 1.2 Product Introduction -------------------------------------------------------------- 1.3 Package Contents -------------------------------------------------------------- Chapter 2. Feature and Specifications 2.1 Features --------------------------------------------------------------------------- 2.2 Mechanical Specification ----------------------------------------------------- 2.3 Operation and Reliability Specification --------------------------------------- Chapter 3. Installation and Operating Instruction 3.1 Installation Guidelines...

  • Page 3: Chapter 1. Introduction

    PureLink by Dtrovision Chapter 1. Introduction 1.1 Safety Precautions When using and installing Dtrovision PureLink product, adhere to the following basic safety precautions.  Read and understand all instructions before using and installing this product.  The safety and operating instructions should be retained for future reference.

  • Page 4: Product Introduction

    PureLink by Dtrovision 1.2 Product Introduction PureLink’s HEXA01 is an audio extractor for HDMI with PCM multi-channel to 2-channel downmixing capabilities. * HEXA01 supports downmixing of up to 5.1 channel PCM audio sources. It does not support downmixing of 7.1 channel PCM audio sources.

  • Page 5: Chapter 2. Feature And Specifications

    Adopting latest HDMI version 1.4 enables to support 3D, 48-Bit Deep Color and 7.1 Channel Dolby TruHD & DTS MasterHD Auto-EDID (EDID Library, Emulation) PureLink's EDID library and emulation features failsafe EDID capture & storage to provide constant and continuous EDID for source devices. HDCP (High-bandwidth Digital Content Protection) Compliant...

  • Page 6: Mechanical Specification

    PureLink by Dtrovision 2.2 Mechanical specification Specifications Product Name HEXA01 Data Transfer Rate 2.25 Gbps Frequency Range 25 – 165 Mhz Input Signal Single link HDMI Output Signal Single link HDMI, SPDIF and Stereo audio Up to WUXGA(1920X1200) 60Hz Supported Resolution...

  • Page 7: Operation And Reliability Specification

    PureLink by Dtrovision 2.3 Operation and Reliability Specification *The following settings are recommended in order to maintain optimal performance: 1. Operating Environment Temperature : 50F ~ 104F (10℃~ 40℃) Humidity : 10% ~ 80% Altitude : 3,000m Max. 2. Transit Environment Temperature : -13F ~ 140F (-25℃~ 60℃)

  • Page 8: Chapter 3. Installation And Operating Instruction

    PureLink by Dtrovision Chapter 3. Installation and Operating Instruction 3.1 Installation Guidelines Before installing the HEXA01 audio extractor, turn OFF the source and display devices. Connect the HDMI and/or audio cable. Plug in the adapter to the HEXA01 power jack.

  • Page 9: Edid Settings

    PureLink by Dtrovision 3.3 EDID Settings 1) Internal EDID setting Turn ON switch 2. Select settings for switch 3, then press SAVE to store internal EDID data. 2) Display EDID settings Turn OFF switch 2, then press SAVE to reset the display EDID data.

  • Page 10: Chapter 4. Additional Information

    PureLink by Dtrovision Chapter 4. Additional Information 4.1 Manufacturer’s Warranty (2-Year) Dtrovision warrants this HEX01 to be free from defects in workmanship and materials, under normal use and service, for a period of two (2) year from the date of purchase from Dtrovision or its authorized resellers.

  • Page 11: Fcc/Ce Statement

    PureLink by Dtrovision 4.2 FCC/CE Statement This device complies with part 15 of FCC Rules and EN 55022/55024/61000-3 for CE certification. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must not accept any interference received, including interference that may cause undesired operation.
