Bus Traffic
NetMeter continuously monitors the CAN bit-stream for
message traffic. NetMeter reports Bus Traffic as either
network bandwidth consumed (including bandwidth
consumed by errors/retries) or bus frames per second.
Display
MIN
MAX
MIN
MAX
Node traffic measurements include only messages
transmitted by the device except Group 2 master/slave
traffic, where ALL traffic shows up on the slave MAC ID.
What it means
250
%
250
%
x
1
250
%
x 2
250
x 3
/S
K
250
x 4
/S
K
250
x 5
/S
K
Current network or
node bandwidth
utilization.
Minimum network or
node bandwidth
recorded since the
NetMeter was
plugged into the
network or reset.
Maximum network or
node bandwidth
recorded since
NetMeter was
connected or reset.
Number of message
frames per second
on the network or
node.
Miinimum frame rate
(/S) on the network
or node since the
NetMeter was
plugged in or reset.
Maximum frame
rate(/S) on the
network or node
since the NetMeter
was plugged in or
reset.
