PA168X IAX2 Phone User Manual (V1.42)
PA168X IAX2 Phone User Manual
................................................................................................................................ 4
........................................................................................................................................ 6
............................................................................................................................. 6
Beijing Centrality Communication Inc
......................................................................................................... 5
...................................................................................................... 6
........................................................................................................... 6
......................................................................................................................... 7
................................................................................................................ 7
........................................................................................................... 10
.......................................................................................................... 22
.............................................................................................. 38
............................................................................................................ 39
................................................................... 2
.......................................................... 3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PA168X IAX2 and is the answer not in the manual?

Questions and answers

Related Manuals for Centrality PA168X IAX2

Summary of Contents for Centrality PA168X IAX2

  • Page 1: Table Of Contents

    PA168X IAX2 Phone User Manual (V1.42) PA168X IAX2 Phone User Manual PA168X IP phone Appearance Introduction: ..............2 Function Keys of PA168X IP Phone Introduction ............3 Features ..........................4 Standard and Protocol ......................5 Operating requirements ...................... 6 Electric requirements ......................

  • Page 2: Pa168X Ip Phone Appearance Introduction

    PA168X IAX2 Phone User Manual (V1.42) PA168X IP phone Appearance Introduction: ● PA168X IP Phone Front Illustration (Refer to Fig 1.1): LCD Display Menu/Enter Phone Number Backspace Local IP Missed Received Phone book Flash Hold Transfer Redial Speaker Call Fig 1.1 PA168X IP Phone Front Illustration ●...

  • Page 3: Function Keys Of Pa168X Ip Phone Introduction

    PA168X IAX2 Phone User Manual (V1.42) Power Jack To network To PC Fig 1.2 PA168X Phone Back Illustration Function Keys of PA168X IP Phone Introduction: Keys Function Keys Function With handset hung, press this key With handset hung, press this...

  • Page 4: Features

    PA168X IAX2 Phone User Manual (V1.42) speaker，press this key to Increase the volumes of speaker. With pressing “missed” or“received” or “out” and then press this key to turn over the record backward. Enter the menu mode; press this key to turn over the item backward.

  • Page 5: Standard And Protocol

    PA168X IAX2 Phone User Manual (V1.42) ● Support major G.7XX ;GSM610 audio codec ● VAD(Voice active detect) ● CNG (Comfort noise generation) ● Dynamic voice jitter buffer ● G.168/165 compliant 16ms echo cancellation ● Tone generation and Local DTMF re-generation according with ITU-T ●...

  • Page 6: Operating Requirements

    PA168X IAX2 Phone User Manual (V1.42) ● DHCP：Dynamic Host Configuration Protocol ● PPPoE：PPP Protocol over Ethernet ● DNS：Domain Name Server ● Telnet：Internet's remote login protocol ● FTP：File Transfer protocol ● HTTP：Hyper Text Transfer protocol Operating requirements: ● Operation temperature: 0 to 50° C (32° to 122° F) ●...

  • Page 7: Configuration

    Configuration Three ways of configuring the PA168X IAX2 phone are available: phone keypad, web browser, Telnet commands. Phone Keypad setup ● Function Keys Introduction: When using keypad and LCD to configure...

  • Page 8: Menu Structure

    PA168X IAX2 Phone User Manual (V1.42) ● Menu Structure: Fig 2.1 Main Menu structure Illustration Fig 2.2 Network submenu structure Illustration Fig 2.3 Audio submenu structure Illustration Beijing Centrality Communication Inc...
  • Page 9 PA168X IAX2 Phone User Manual (V1.42) Fig 2.4 Phone submenu structure Illustration Fig 2.5 Protocol submenu structure Illustration Fig 2.6 other submenu structure Illustration Beijing Centrality Communication Inc...

  • Page 10: Configured By Web

    PA168X IAX2 Phone User Manual (V1.42) Fig 2.7 advanced submenu structure Illustration Configured by WEB Double click icon to open the IE browser. Input the IP address of the phone into address bar ( ), and then input password of the phone into the following page.
  • Page 11 PA168X IAX2 Phone User Manual (V1.42) The following configured page wills popup. Refer to Fig 3.1 please. Network Setting： Fig 3.2 Network Setting ● iptype: Set how IP phone gets relevant network parameters by selecting corresponding item from drop down list.
  • Page 12 PA168X IAX2 Phone User Manual (V1.42) modem：If the IP phone used with modem, please select this item to get relevant network parameters auto. Then please fill ID and pin into ppp id and ppppin fields. ● ppp id: With pppoe or modem selected in iptype drop down list, please enter the user name here.
  • Page 13 PA168X IAX2 Phone User Manual (V1.42) NIC. PA168X phone is shipped from the factory with a unique algorism MAC address printed on the back of the base. Audio settings: Fig 3.3 Audio Setting ● codec1: Set the priority 1 of the audio compression algorithm. The options are g729，g7231，g711u，g711a and gsm.
  • Page 14 PA168X IAX2 Phone User Manual (V1.42) options are g729，g7231，g711u，g711a and gsm. ● vad: Enable/disable VAD (voice activity detection). ● agc: Enable/disable AGC. ● aec: Enable/disable VEC. ● audio frame: Set audio frames in RTP package. Minimum is 1 and maximum is 8.
  • Page 15 PA168X IAX2 Phone User Manual (V1.42) disable: Do not use dial plan or dial number by selecting this item. enable: Use dial plan by selecting this item. dialnum: Use dial number by selecting this item. With this item selected, please enter the dial prefix into dial number field.
  • Page 16 PA168X IAX2 Phone User Manual (V1.42) ● innerline: Enable/disable innerline call by selecting corresponding items from dropdown list. disable: Disable call innerline by selecting this item. enable: enable call innerline by selecting this item. ● innerlineprefix: With enable selected in innerline dropdown list, please fill the prefix number pick up to inner line, such as 0.
  • Page 17 PA168X IAX2 Phone User Manual (V1.42) ● Use digitmap: Enable/disable digit map by checking/unchecking the box. ● handset in: Set the volume of handset input. ● handset out: Set the volume of handset output. ● ring type: Set ring type by selecting corresponding item from drop down list.
  • Page 18 PA168X IAX2 Phone User Manual (V1.42) ● use service: Enable/disable service by checking/clearing this box. To make calls through Asterisk Server, please check this box; otherwise, phone can only make IP-to IP calls. ● service addr: If “use service” is checked, please set the URI of the Asterisk Server into “service addr”.
  • Page 19 PA168X IAX2 Phone User Manual (V1.42) ● super password: Set the super password of the phone.(Default super password is 12345678). ● debug: Set the debug level of the phone. disable: Disable output the debug message by selecting this item. output: Output the operation information to the window, such as register, input by selecting this item.
  • Page 20 PA168X IAX2 Phone User Manual (V1.42) all: pa168X phone will find matching firmware binary file and configuration file of the hardware type only at the FTP server specify by upgradeaddr item . mac: pa168X phone will find matching firmware binary file and configuration file of the MAC address only at the FTP server specify by upgradeaddr item .
  • Page 21 PA168X IAX2 Phone User Manual (V1.42) ● timezone: Select correct time zone in list box. When debug set as 0[disable], if input ordinary password (default one is 1234), then following page will pop up after clicking . And only those parameters can be modified.

  • Page 22: Telnet Configuration

    PA168X IAX2 Phone User Manual (V1.42) Phone Book: Click this button to open the speed dial settings page. Please refer to Fig 3.7. In this page, you can set and save the speed dial number by typing the name into the Name field and then entering the corresponding number following the name.
  • Page 23 PA168X IAX2 Phone User Manual (V1.42) Password : Then please type password. With debug is set as 0[disable], if type ordinary password (default one is 1234), after Retun, you will see： Password : **** P:\> If you type super password, then you will see: Password : ******** P:\>...
  • Page 24 PA168X IAX2 Phone User Manual (V1.42) ping Ping other net parameter The phone connects to FTP server and then get the files Detail description of PA168X Telnet commands Command Syntax description: No optional parameter Usage: Type command name and parameters following P:\> . Be used as the keyword to supply keyword and parameters of the relevant commands.
  • Page 25 PA168X IAX2 Phone User Manual (V1.42) Display basic running parameters of the PA168X IP phone. Input ordinary password without debug being set as 0[disable], or input super password with debug set as 0[disable], then following parameters of IP phone will be displayed: PA168X V1.42 settings...
  • Page 26 PA168X IAX2 Phone User Manual (V1.42) be seen: PA168X V1.42 settings Password:**** P:\>get ***************Network Settings*************** iptype 0[static] ip 192.168.1.100 subnetmask 255.255.255.0 router 192.168.1.254 dns 202.106.46.151 dns2 202.96.128.68 mac 00-0d-ea-00-00-03 ***************Audio Settings*************** codec1 0[g729] codec2 1[g7231] codec3 2[g711u] codec4 3[g711a] codec5 4[gsm]...
  • Page 27 PA168X IAX2 Phone User Manual (V1.42) Set how IP phone gets relevant network parameters. X ranged from 0 through 3: 0: authorize users set IP address, subnet mask and router IP address of IP phone manually; 1: use DHCP mode.
  • Page 28 PA168X IAX2 Phone User Manual (V1.42) With iptype set as 0, use this command to set IP address of PA168X IP phone. set subnetmask XXX.XXX.XXX.XXX With iptype set as 0, use this command to set subnet mask of PA168X IP phone.
  • Page 29 PA168X IAX2 Phone User Manual (V1.42) Set the priority 2 of the audio compression algorithm. X is range from 0 through 4: 0: g729; 1:g7231; 2: g711u; 3: g711a; 4: gsm. set codec3 X Set the priority 3 of the audio compression algorithm.
  • Page 30 PA168X IAX2 Phone User Manual (V1.42) 1: disable AEC. set audioframes X Set audio frames in RTP package. X is Arabic numerals between 0 and 7. set jittersize X Set buffer size of RTP package. X is range from 0-32.
  • Page 31 PA168X IAX2 Phone User Manual (V1.42) is 21, and the area code of Chengdu is 28, etc. Parameter xxx must be an Arabic numeral and no longer than 3 characters. set iddcode XXX Set the country code when set dialplan value set as 1 or 2. For example, the country code of China is 86;...
  • Page 32 PA168X IAX2 Phone User Manual (V1.42) With innerline set as 1[enable] , please set the prefix to pick up inner line, such as 0. set callwait X Set whether to use call wait. X ranged from 0 to 1: 0: do not use call wait;...
  • Page 33 PA168X IAX2 Phone User Manual (V1.42) Set whether to use digitmap. X ranged from 0 to 1: 0: do not use digitmap; 1: use digitmap. set handsetin X Set initial volume of handset. X is ranged from 0 through 15.
  • Page 34 PA168X IAX2 Phone User Manual (V1.42) value is 60 Sec. set service addr XXXX Set IP address or URI of Asterisk Server. set phonenumber XXXXXXXX Set a phone number of PA168X IP phone. Value xxxxx must be an Arabic numeral and no longer than 16 characters.
  • Page 35 PA168X IAX2 Phone User Manual (V1.42) set superpassword XXXX Set super password of the PA168X IP phone. XXX must be ASCII characters. set debug X Set open debugging message output grade for special tool. X is ranged from 0 through 5: 0: close debugging output; 1: output the operation information to the window;...
  • Page 36 PA168X IAX2 Phone User Manual (V1.42) daylight; 1: use daylight. set timezone XX Set time zone. store Command Syntax description: no keyword. Parameter ranged from 0 through 4. Usage: Save the current settings to the designated position. Relevant Usage: store 1...
  • Page 37 PA168X IAX2 Phone User Manual (V1.42) Command ping Syntax description: ping IP address Usage: ping IP address of other NAT device Relevant usage: In telnet window, input ping xx.xxx.xx.xx（an IP address） and return, then the result will be displayed. If the address is effective, “ping OK”...

  • Page 38: Upgrade Pa168X Ip Phone

    PA168X IAX2 Phone User Manual (V1.42) update program Flash. This operation aims at updating program. X-2: Connect to FTP Server to get the file of updating dial rules and update program Flash. This operation aims at updating dial rule. Note When you use ftp 0 and ftp 1 commands, if the file get from FTP server is too large or the net speed is too slow, then the process will not be seen in telnet window.

  • Page 39: Usage Of The Phone

    PA168X IAX2 Phone User Manual (V1.42) c) Press , then No19 light will blink twice a second. Once Local IP the phone restarts successfully, the new program is effective. Note Please do not change the name of the upgraded program, or the operation will be fail.
  • Page 40 PA168X IAX2 Phone User Manual (V1.42) Note When you communicate with the other party without lifting the handset, please do not exceed 40 CM from speaker. Place a call Call another PA168 IP phone under the Asterisk Server: ● 1. Handset: Pick up the handset and listen for the Internet dial tone. Then dial the phone number you wish to call and press ＃...
  • Page 41 PA168X IAX2 Phone User Manual (V1.42) dialed number has been saved into the buffer. ● Place a call without login the Asterisk Server If PA168X IP phone does not login the SIP proxy, you can place a call by lifting the handset or pressing...
  • Page 42 PA168X IAX2 Phone User Manual (V1.42) and received call ranged from 1-80 at best. When the entries arrives 80, the latest record will cover the first one. The record will be lost when the phone restarts or turned on. Beijing Centrality Communication Inc...
  • Page 43 PA168X IAX2 Phone User Manual (V1.42) Appendix Table： PA168X IP phone digital-character key map: Keys Press Once Press Twice Press Thrice Press quartic Press quintic space \ /& Case change Beijing Centrality Communication Inc...
  • Page 44 PA168X IAX2 Phone User Manual (V1.42) Reserves the right to make changes in technical and product specification without prior notice. PA168X IAX2 Phone User Manual (V1.42) Copyright© 2003---2005 Beijing Centrality Communication Inc. All rights reserved Beijing Centrality Communication Inc...
