PA168X SIP Phone User Manual (V1.42)
PA168X SIP Phone User Manual
................................................................................................................................ 4
........................................................................................................................................ 6
............................................................................................................................. 6
Beijing Centrality Communication Inc
......................................................................................................... 5
...................................................................................................... 6
........................................................................................................... 6
......................................................................................................................... 7
................................................................................................................ 7
........................................................................................................... 10
.......................................................................................................... 26
.............................................................................................. 45
............................................................................................................ 45
................................................................... 2
.......................................................... 3

Advertisement

Table of Contents
loading

Related Manuals for Centrality PA168X

Summary of Contents for Centrality PA168X

  • Page 1: Table Of Contents

    PA168X SIP Phone User Manual (V1.42) PA168X SIP Phone User Manual PA168X IP phone Appearance Introduction: ..............2 Function Keys of PA168X IP Phone Introduction ............3 Features ..........................4 Standard and Protocol ......................5 Operating requirements ...................... 6 Electric requirements ......................

  • Page 2: Pa168X Ip Phone Appearance Introduction

    PA168X SIP Phone User Manual (V1.42) PA168X IP phone Appearance Introduction: ● PA168X IP Phone Front Illustration (Refer to Fig 1.1): LCD Display Menu/Enter Phone Number Backspace Local IP Missed Received Phone book Flash Hold Transfer Redial Speaker Call Fig 1.1 PA168X IP Phone Front Illustration ●...

  • Page 3: Function Keys Of Pa168X Ip Phone Introduction

    PA168X SIP Phone User Manual (V1.42) Power Jack To network To PC Fig 1.2 PA168X Phone Back Illustration Function Keys of PA168X IP Phone Introduction: Keys Function Keys Function With handset hung, press this key With handset hung, press this...

  • Page 4: Features

    PA168X SIP Phone User Manual (V1.42) speaker，press this key to Increase the volumes of speaker. With pressing “missed” or“received” or “out” and then press this key to turn over the record backward. Enter the menu mode; press this key to turn over the item backward.

  • Page 5: Standard And Protocol

    ● Adjustable volume for both handset and speaker ● Voice prompt ● Hotline Standard and Protocol PA168X IP Phone supports following standard and protocol: ● IEEE 802.3 /802.3 u 10 Base T / 100Base TX ● Major G.7XX; GSM610 audio codec ● SIP (RFC 2543;RFC3261) ●...

  • Page 6: Operating Requirements

    PA168X SIP Phone User Manual (V1.42) ● DHCP：Dynamic Host Configuration Protocol ● PPPoE：PPP Protocol over Ethernet ● DNS：Domain Name Server ● Telnet：Internet's remote login protocol ● FTP：File Transfer protocol ● HTTP：Hyper Text Transfer protocol Operating requirements: ● Operation temperature: 0 to 50° C (32° to 122° F) ●...

  • Page 7: Configuration

    Configuration Three ways of configuring the PA168X SIP phone are available: phone keypad, web browser, Telnet commands. Phone Keypad setup ● Function Keys Introduction: When using keypad and LCD to configure...

  • Page 8: Menu Structure

    PA168X SIP Phone User Manual (V1.42) ● Menu Structure: Fig 2.1 Main Menu structure Illustration Fig 2.2 Network submenu structure Illustration Fig 2.3 Audio submenu structure Illustration Beijing Centrality Communication Inc...
  • Page 9 PA168X SIP Phone User Manual (V1.42) Fig 2.4 Phone submenu structure Illustration Fig 2.5 Protocol submenu structure Illustration Fig 2.6 other submenu structure Illustration Beijing Centrality Communication Inc...

  • Page 10: Configured By Web

    PA168X SIP Phone User Manual (V1.42) Fig 2.7 advanced submenu structure Illustration Configured by WEB Double click icon to open the IE browser. Input the IP address of the phone into address bar ( ), and then input password of the phone into the following page.
  • Page 11 Select this item to enable DHCP mode. With this system, your LAN or router automatically assigns all the required network parameters to any device connected to it when the device log on. PA168X IP phone is shipped from the factory with DHCP on. So, if your LAN or router is configured to use DHCP addressing, the IP phone’s LAN parameters...
  • Page 12 PA168X SIP Phone User Manual (V1.42) it is a protocol especially designed for them. With this system, ADSL ISP automatically assigns all the required IP parameters to any device connected to it when the device log on. modem：If the IP phone used with modem, please select this item to get relevant network parameters auto.
  • Page 13 DNS server here. ● mac: MAC address is the physical address supplied by the Ethernet NIC. PA168X phone is shipped from the factory with a unique algorism MAC address printed on the back of the base. Audio settings: Fig 3.3 Audio Setting...
  • Page 14 PA168X SIP Phone User Manual (V1.42) ● codec5: Set the priority 5 of the audio compression algorithm. The options are g729，g7231，g711u，g711a and gsm. ● codec6: Set the priority 6 of the audio compression algorithm. The options are g729，g7231，g711u，g711a and gsm.
  • Page 15 PA168X SIP Phone User Manual (V1.42) ● use dialplan: Set whether use dial plan or use dial number by selecting the corresponding item in drop down list. disable: Do not use dial plan or dial number by selecting this item.
  • Page 16 PA168X SIP Phone User Manual (V1.42) Note With dialnum seletcted in use dialplan drop down list, you can also set dddcode, iddcode, iddprefix and dddprefix according to requirement of system. ● innerline: Enable/disable innerline call by selecting corresponding items from dropdown list.
  • Page 17 PA168X SIP Phone User Manual (V1.42) receiving forwarded calls phone number into fwd number field. ● answer: Enter a number from 0 through 60 to set the entries of the seconds before the phone answer the call auto or forward the calls.
  • Page 18 PA168X SIP Phone User Manual (V1.42) Fig 3.5 Protocol Setting ● use service: Enable/disable service by checking/clearing this box. To make calls through SIP Proxy Server, please check this box; otherwise, phone can only make IP-to IP calls. ● register ttl : IP phone will send a keep-alive registration message to SIP proxy server every “register ttl”...
  • Page 19 PA168X SIP Phone User Manual (V1.42) uptech: Use Uptech’s system keimen: Use Keimen’s system mediaring: Use Mediaring’s SIP system italkbb: Use ItalkBB’s SIP system stanaphone: Use Stanaphone’s SIP system net2phone: Use Net2phone’s SIP system Fwd: Free SIP service; please visit www.freeworldialup.com...
  • Page 20 PA168X SIP Phone User Manual (V1.42) URI of the Outbound proxy into “sip proxy” and set the domain name of SIP proxy server into “domain/realm”. The default service port is 5060. If “use service” is not checked, please clear “sip proxy” and “domain/realm”.
  • Page 21 PA168X SIP Phone User Manual (V1.42) When “nat traversal” is set to “stun”, please put the URI of the stun server into “nat addr”, in the format as “domain name/IP address : service port”. The default service port for stun is 3478.
  • Page 22 PA168X SIP Phone User Manual (V1.42) ● call type: Set call type by selecting the items in drop down list. normal: When SIP system not support “outbound proxy”, selecting this item. advanced: When SIP system support “outbound proxy”, selecting this item.
  • Page 23 MAC address only at the FTP server specify by upgradeaddr item . ppp id: pa168X phone will find matching firmware binary file and configuration file of the ppp id only at the FTP server specify by upgradeaddr item .
  • Page 24 FTP server specify by upgradeaddr item . phonenumber: pa168X phone will find matching firmware binary file and configuration file of the phone only at the FTP server specify by upgradeaddr item .
  • Page 25 PA168X SIP Phone User Manual (V1.42) Fig 3.7 Setting Page using ordinary pin with Debug set as 0 [disable] ● Update: Click this button to save the configuration and the phone will reboot. Once the phone reboots successfully, the new configuration is effective.

  • Page 26: Telnet Configuration

    PA168X SIP Phone User Manual (V1.42) 5989426454 is saved in phone book. Then please click Save/Back button. In normal state, you can use speed dial to call numbers saved in phone book. Fig 3.8 Phone Book Illustration Upgrade Program: Click this button to update the program of IP phone.
  • Page 27 If you type super password, then you will see: Password : ******** P:\> Above information indicates that IP phone is under setting mode, and then you can set the PA168X IP phone by using the telnet commands. PA168X Telnet Commands Explanation PA168X Telnet Commands Command...
  • Page 28 Command Syntax description: No optional parameter of keywords Usage: Display basic parameters of the PA168X IP phone Relevant usage: None Detailed description: Display basic running parameters of the PA168X IP phone. Input ordinary password without debug being set as 0[disable], or input...
  • Page 29 PA168X SIP Phone User Manual (V1.42) ***************Network Settings*************** iptype 0[static] ip 192.168.1.100 subnetmask 255.255.255.0 router 192.168.1.254 dns 202.106.196.152 dns 2202.106.196.115 mac 00-09-45-65-a3-e6 ***************Audio Settings*************** codec1 0[g729] codec2 1[g7231] codec3 2[g711u] codec4 3[g711a] codec5 4[gsm] codec6 6[null] vad 1[enable] agc 0[disable]...
  • Page 30 PA168X SIP Phone User Manual (V1.42) ***************Network Settings*************** iptype 0[static] ip 192.168.1.100 subnetmask 255.255.255.0 router 192.168.1.254 dns 202.106.46.151 dns2 202.96.128.68 mac 00-0d-ea-00-00-03 ***************Audio Settings*************** codec1 0[g729] codec2 1[g7231] codec3 2[g711u] codec4 3[g711a] codec5 4[gsm] codec6 6[null] vad 1[enable] agc 0[disable]...
  • Page 31 PA168X SIP Phone User Manual (V1.42) required network parameters to any device connected to it when the device log on. PA168X IP phone is shipped from the factory with DHCP on. So, if your LAN or router is configured to use DHCP addressing, the IP phone’s LAN parameters will...
  • Page 32 With iptype set as 0, use this command to set IP of backup DNS server. set mac XX-XX-XX-XX-XX-XX Set MAC address of the PA168X IP phone. Parameter xx-xx-xx-xx-xx-xx must be an HEX number. set codec1 X Set the priority 1of the audio compression algorithm.
  • Page 33 PA168X SIP Phone User Manual (V1.42) from 0 through 4: 0: g729; 1:g7231; 2: g711u; 3: g711a; 4: gsm. set codec4 X Set the priority 4 of the audio compression algorithm. X is range from 0 through 4: 0: g729; 1:g7231; 2: g711u; 3: g711a; 4: gsm.
  • Page 34 X Set buffer size of RTP package. X is range from 0-32. With G.7231, set PA168X IP phone to use 6.3K rate or not. X is ranged from 0 through 1: 0: use 6.3K rate; 1: use 5.3K rate.
  • Page 35 PA168X SIP Phone User Manual (V1.42) example, the country code of China is 86; the country code of USA is 1, etc. Parameter xxxx must be an Arabic numeral and no longer than 4 characters. set iddprefix XX Set IDD service prefix number when set dialplan value set as 1 or 2.
  • Page 36 PA168X SIP Phone User Manual (V1.42) call wait; 1: use call wait. set fwdnumber XXXXXXX Set receiving forwarded calls phone number. XXXX must be an Arabic numeral and no longer than 16 characters set fwdalways X Enable/disable forward all calls. X is ranged from 0 through 1. 0: do not forward all calls;...
  • Page 37 PA168X SIP Phone User Manual (V1.42) set handsetout X Set initial volume of handout. X is ranged from 0 through 31. set ringtype X Set types of ring. X is ranged from 0 through 3: 0: ring as ordinary rings in different frequency; 1: do not ring; 2: ring as music saved by user;...
  • Page 38 PA168X SIP Phone User Manual (V1.42) 0: common: disable repaid card or specially system ; 1: use huawei’s system; 2: use ZTE’s system; 3: use harbour’s system; 4: use utstarcom’s system; 5:use uptech system; 6: use keimen’s system; 7: use meidaring’s...
  • Page 39 PA168X SIP Phone User Manual (V1.42) If the system has an Outbound Proxy， Set the domain name of SIP proxy server such as xxxx. set nattraversal X X ranged from 0 through 2: 0: do not use NAT traversal. When the log in server and IP phone in the same LAN, or the log in system supports the IP phone working behind the LAN;...
  • Page 40 PA168X SIP Phone User Manual (V1.42) value is 20 sec. set phonenumber XXXXXXXX Set a local ID of PA168X IP phone. Value xxxxx must be an Arabic numeral and no longer than 16 characters. set account XXXXXX Set the account; Value xxxxxx must be an Arabic numeral and no longer than 32 characters.
  • Page 41 Set password of the PA168X IP phone. XXX must be ASCII characters. set superpassword XXXX Set super password of the PA168X IP phone. XXX must be ASCII characters. set debug X Set open debugging message output grade for special tool. X is ranged from 0 through 5: 0: close debugging output;...
  • Page 42 PA168X SIP Phone User Manual (V1.42) Set auto-upgrade matching type，X is range from 0 through 5， 0------disable；1------all ；2------ mac；3------ppp id; 4------ account; 5------ phone number。 set upgradeaddr XXX.XXX.XXX.XXX Set IP address or domain name of FTP server supplying upgraded program of PA168X IP phone.
  • Page 43 Relevant usage: None write Command Syntax description: No keyword and parameter Usage: Save the configuration and restart the PA168X IP phone. Command ping Syntax description: ping IP address Usage: ping IP address of other NAT device Relevant usage: In telnet window, input ping xx.xxx.xx.xx（an IP address）...
  • Page 44 So if nothing is displayed after too long time, it means that ftp is fail. Note All the Telnet commands of PA168X IP phone should be written in low case and the password is case sensitive.

  • Page 45: Upgrade Pa168X Ip Phone

    Note Please do not change the name of the upgraded program, or the operation will be fail. Usage of the phone Receiving calls: PA168X IP phone can receive incoming calls from other PA168X IP phone and devices that support the SIP protocol. It works just like an ordinary Beijing Centrality Communication Inc...
  • Page 46 PA168X SIP Phone User Manual (V1.42) phone for incoming calls. When it rings, you can receive the call by following methods: ① Use handset: Lift the handset and begin speaking. When the call is over, put the handset back. ② Handset to hand free: While receiving call with handset, press Speake on the keypad and then put down the handset.
  • Page 47 ● Place a call without login the SIP proxy If PA168X IP phone does not login the SIP proxy, you can place a call by lifting the handset or pressing and then inputting the IP...
  • Page 48 ＃ place a call directly. Note PA168X IP phone supports saving 80 entries unanswered call, dialed call and received call ranged from 1-80 at best. When the entries arrives 80, the latest record will cover the first one. The record will be lost when the phone restarts or turned on.
  • Page 49 PA168X SIP Phone User Manual (V1.42) Appendix Table： PA168X IP phone digital-character key map: Keys Press Once Press Twice Press Thrice Press quartic Press quintic space \ /& Case change Beijing Centrality Communication Inc...
  • Page 50 PA168X SIP Phone User Manual (V1.42) Reserves the right to make changes in technical and product specification without prior notice. PA168X SIP Phone User Manual (V1.42) Copyright© 2003---2005 Beijing Centrality Communication Inc. All rights reserved Beijing Centrality Communication Inc...
