Centrality PA168S IP Phone User Manual (V1.32)
................................................................................................................................ 5
........................................................................................................................................ 8
............................................................................................................................. 8
Beijing Centrality Communication Inc
PA168S IP Phone User Manual
......................................................................................................... 6
...................................................................................................... 7
........................................................................................................... 8
......................................................................................................................... 9
................................................................................................................ 9
........................................................................................................... 15
.................................................................................................... 35
.......................................................................................................... 36
............................................................................................................ 55
........................................................... 2
................................................................. 3
................................................. 4
............................................................................ 54
................................. 5

Advertisement

Table of Contents
loading

Related Manuals for Centrality PA168S

Summary of Contents for Centrality PA168S

  • Page 1: Table Of Contents

    Breif Introduction of Centrality PA168S IP phone ............2 Suitable Uses of Centrality PA168S IP phone ..............3 Centrality PA168S IP phone Appearance Introduction: ..........4 Function Keys of PA168S IP Phone Introduction (Normal State) ......... 5 Features ..........................5 Standard and Protocol ......................6 Operating requirements ......................

  • Page 2: Breif Introduction Of Centrality Pa168S Ip Phone

    ISP such as Net2phone or eTalk. Moreover, it possesses excellent sound quality just like ordinary phones. PA168S phone has 2X16 English LCD and supports being set by keypad. Beijing Centrality Communication Inc...

  • Page 3: Suitable Uses Of Centrality Pa168S Ip Phone

    Centrality PA168S IP Phone User Manual (V1.32) Suitable Uses of Centrality PA168S IP phone Centrality PA168S IP Phone is the ideal choice for those who always place international or long distance calls. If two parties both use Centrality PA168 serial IP Phone, they can communicate with each other even free.

  • Page 4: Centrality Pa168S Ip Phone Appearance Introduction

    ● PA168S IP Phone Front Illustration (Refer to Fig 1.1): Fig 1.1 PA168S IP Phone Front Illustration ● PA168S IP Phone Back and Side Illustrations(Refer to Fig 1.2 and 1.3): Fig 1.2 PA168S IP Phone Back Illustration Fig1.3 PA168S IP phone Side Illustration...

  • Page 5: Function Keys Of Pa168S Ip Phone Introduction (Normal State)

    Centrality PA168S IP Phone User Manual (V1.32) Function Keys of PA168S IP Phone Introduction (Normal State): Keys Function With handset hung, press this key to get local IP address of the phone Missed With handset hung, press this key to review missed number...

  • Page 6: Standard And Protocol

    ● Adjustable volume for both handset and speaker ● Voice prompt ● Hotline Standard and Protocol Centrality PA168S IP Phone supports following standard and protocol: ● IEEE 802.3 /802.3 u 10 Base T / 100Base TX Beijing Centrality Communication Inc...

  • Page 7: Operating Requirements

    Centrality PA168S IP Phone User Manual (V1.32) ● Major G.7XX and gsm610 audio codec ● H.323 V4 ● MGCP RFC2705 ● SIP RFC3261 ● Net2phone private protocol ● TCP/IP: Internet transfer and control protocol ● RTP: Real-time Transport Protocol ● RTCP：Real-time Control Protocol ●...

  • Page 8: Electric Requirements

    Centrality PA168S IP Phone User Manual (V1.32) Electric requirements: ● Voltage: 9V DC ● Power: 9W (max.) ● Power adapter: AC/DC input 100-230V，output 9V 1A ● Network interface:4X RJ-45 Ethernet Connectors Size： 170 x 175 x 85 mm (L x W x H) Installation: 1．...

  • Page 9: Configuration

    Refer to Fig 2.3. Fig 2.3 Power on IP phone Configuration Four different ways can be used to configure Centrality PA168S IP phone: phone keypad set; web browser, Telnet commands and PalmTool configuration on computer. Phone Keypad setup ●...
  • Page 10 Centrality PA168S IP Phone User Manual (V1.32) ● Configuration operation: We tack enabling eTalk prepaid card and setting the ID and pin as an example to explain how to change setting: 1. Enter setting mode: use the dial pad to enter the password of the phone (when debug is not set as 0[disable], default password is 1234;...
  • Page 11 Centrality PA168S IP Phone User Manual (V1.32) 4. Set eTalk pin (409466193597)：press to turn over the menu, Vol＋ once is displayed on the screen, please press Local IP enter change mode, then you will see a cursor flashing at the beginning of the second line.
  • Page 12 Centrality PA168S IP Phone User Manual (V1.32) Beijing Centrality Communication Inc...
  • Page 13 Centrality PA168S IP Phone User Manual (V1.32) Beijing Centrality Communication Inc...
  • Page 14 Centrality PA168S IP Phone User Manual (V1.32) Beijing Centrality Communication Inc...

  • Page 15: Configured By Web

    Centrality PA168S IP Phone User Manual (V1.32) Configured by WEB On a PC connecting with the phone or at the same segment of the phone, double click icon to open the IE browser. Input the IP address of the phone into address bar ( ), and then input password of the phone into the following page.

  • Page 16: Network Setting

    Centrality PA168S IP Phone User Manual (V1.32) Fig 3.1 Http Setting Page Network Setting： Fig 3.2 Network Setting Page ● iptype: Set how IP phone gets relevant network parameters by selecting corresponding item from drop down list. static ip: Select this item to authorize users set IP address, subnet mask...
  • Page 17 Select this item to enable DHCP mode. With this system, your LAN or router automatically assigns all the required network parameters to any device connected to it when the device log on. Centrality PA168S IP phone is shipped from the factory with DHCP on. So, if your LAN or router is configured to use DHCP addressing, the IP phone’s LAN...
  • Page 18 DNS server here. ● mac: MAC address is the physical address supplied by the Ethernet NIC. Centrality PA168S phone is shipped from the factory with a unique algorism MAC address printed on the back of the base.
  • Page 19 Centrality PA168S IP Phone User Manual (V1.32) ● protocol: Select an item from dropdown list to set the protocol used by the phone. h323: Select this item to set the phone use H323 protocol. sip: Select this item to set the phone use SIP protocol.
  • Page 20 Centrality PA168S IP Phone User Manual (V1.32) default value 0.0.0.0. Then please make port mapping on NAT device. citron: With Citron private protocol used, select this item to fit into the GnuGK system transferring the voice and signal by router.
  • Page 21 Centrality PA168S IP Phone User Manual (V1.32) requirement, just remain it as default value 0.0.0.0. ● use service: Enable/disable service by checking/unchecking this box. Different service responses different protocol as follows: With H323 protocol used, the protocol service refers to the gatekeeper searching the address.
  • Page 22 Centrality PA168S IP Phone User Manual (V1.32) Note Designated Net2phone server IP address are: 216.53.3.52; 4.43.114.39; 4.43.114.38 or 05.228.245.8. Domain names are: call1.net2phone.com; call2.net2phone.com; skip1.net2phone.com; skip2.net2phone.com; skip1.f8g9h0.net or skip2.f8g9h0.net. ● service id: Set service ID according to requirement of system. For example, when eTalk card is used, the ID should be ETNSGK, so please type ETNSGK into this field.
  • Page 23 Centrality PA168S IP Phone User Manual (V1.32) UDP protocol. Please fill an even number between 1024 and 65535 into this field. ● register port: According to used protocol, set as follows: With H323 protocol used, please enter a number from 1024 through 65535 into this field.
  • Page 24 Centrality PA168S IP Phone User Manual (V1.32) cat account: Select this item to use cat （ Cisco Access Talk ） authentication. With this item selected, please fill the user name and password into account and pin fields respectively. md5 account: With H323 protocol used, according to the log in gatekeeper, enable/disable H235 encryption by selecting/diselecting this item.
  • Page 25 Centrality PA168S IP Phone User Manual (V1.32) etalk: Use eTalk prepaid card by selecting this item. With eTalk selected here, please select dialnum in dial plan drop down list and then fill 00 into dial number field. Note When eTalk card is used, besides above configuration, please set other parameters as follows: service addr: 202.91.230.91;...
  • Page 26 Centrality PA168S IP Phone User Manual (V1.32) the account of chosen card into this field; while md5 account item selected in local type dropdown list, enter ID here; while account is selected in local type dropdown list, enter H323 ID here. While prefix item selected in use dialplan dropdown list, enter language indicating number, card number and # here, such as 14589653185＃.
  • Page 27 Centrality PA168S IP Phone User Manual (V1.32) Fig 3.4 Phone Setting Page ● phone number: With H323, MGCP and Net2phone protocol used, enter an 8 or 9 digits number to set the phone number of IP Phone. With SIP protocol used, enter local ID here.
  • Page 28 Centrality PA168S IP Phone User Manual (V1.32) ● use dialplan: Set whether use dial plan or use dial number by selecting the corresponding item in drop down list. disable: Do not use dial plan or dial number by selecting this item.
  • Page 29 ● innerline: Enable/disable multi-settings by selecting corresponding items from dropdown list. PA168S IP phone allows saving 5 settings totally. disable: Disable multi-settings by selecting this item, then the phone will call out using current setting.
  • Page 30 Centrality PA168S IP Phone User Manual (V1.32) please fill the number switching to backup setting 2 here, such as 57. ● use digitmap: Enable/disable digitmap by checking/unchecking the box. ● ring type: Set ring type by selecting corresponding item from drop down list.
  • Page 31 Centrality PA168S IP Phone User Manual (V1.32) Fig 3.5 Audio Setting Page ● audio type: Set audio type of the phone by selecting item from drop down list. The options are g7231，g729，gsm610，g711u，g711a and auto. ● audio frame: Set audio frames in RTP package. With G723 audio codec used, set it as 1;...
  • Page 32 Centrality PA168S IP Phone User Manual (V1.32) volume. ● speaker out: Drag the slider to adjust the volume of handfree output. Drag it to the left to reduce the volume; while drag it to the right to increase the volume.
  • Page 33 Centrality PA168S IP Phone User Manual (V1.32) server supplying updated program here. ● nts ip: Fill IP address of time server here. ● use daylight: Enable/disable daylight by checking/unchecking this box. ● timezone: Select correct time zone in dropdown list.
  • Page 34 Centrality PA168S IP Phone User Manual (V1.32) button to confirm the modification. Phone Book: Click this button to open the speed dial settings page. Please refer to Fig 3.7. In this page, you can set and save the speed dial number by typing the name into the Name field and then entering the corresponding number following the name.

  • Page 35: Configured By Palmtool

    Centrality PA168S IP Phone User Manual (V1.32) Update Digitmap: Click this button to update the digitmap of the phone. Before updating, please fill IP address of FTP server into upgrade addr field, and then click this button. Then the phone will read the corresponding map files from the server and then load into the phone.

  • Page 36: Telnet Configuration

    If you type super password, then you will see: Password : ******** P:\> Above information indicates that IP phone is under setting mode, and then you can set the Centrality PA168S IP phone by using the telnet commands. Centrality PA168S Telnet Commands Explanation Centrality PA168S Telnet Commands Command...
  • Page 37 Centrality PA168S IP Phone User Manual (V1.32) Display basic parameters of the Centrality PA168S IP phone Set parameters of the Centrality PA168S IP phone store Save current settings to designated position load Load designated settings to current position exit Exit from the setting mode without saving the configuration...
  • Page 38 Command Syntax description: No optional parameter of keywords Usage: Display basic parameters of the Centrality PA168S IP phone Relevant usage: None Detailed description: Display basic running parameters of the Centrality PA168S IP phone. Input ordinary password without debug being set as...
  • Page 39 Centrality PA168S IP Phone User Manual (V1.32) vad 1[enable] agc 0[disable] aec 1[enable] handsetin 8 handsetout 12 speakerout 11 password 1234 debug 0[disable] upgradeaddr [empty] ntsip 210.59.157.10 daylight 0[disable] timezone 20[(GMT-03:00)Greenland] Input ordinary password with debug set as 0[disable], following information will be seen: PA168S V1.32 settings...
  • Page 40 With this system, your LAN or router automatically assigns all the required network parameters to any device connected to it when the device log on. Centrality PA168S IP phone is shipped from the factory with DHCP on. So, if your LAN or router is configured to use DHCP addressing, the IP phone’s LAN parameters will...
  • Page 41 With iptype set as 0, use this command to set IP of backup DNS server. set mac XX-XX-XX-XX-XX-XX Set MAC address of the Centrality PA168S IP phone. Parameter xx-xx-xx-xx-xx-xx must be an HEX number. set protocol X Set protocol of the Centrality PA168S IP phone. Parameter X ranged from 0 through 3: 0 –...
  • Page 42 Centrality PA168S IP Phone User Manual (V1.32) Set use proxy or not. X ranged from 0 through 6: 0: do not use proxy. When the log in server and IP phone in the same LAN, or the log in system supports the IP phone working behind the LAN; 1: Use proxy.
  • Page 43 Centrality PA168S IP Phone User Manual (V1.32) name of gatekeeper; With MGCP protocol used, set IP address or domain name of Call Agent; With SIP protocol used, set IP address or domain name of SIP Proxy Server; With Net2phone protocol used, set IP address or domain name of designated server.
  • Page 44 Centrality PA168S IP Phone User Manual (V1.32) protocol used, please set it as 5060; With Net2phone protocol used, this port could be any number. set signalport XXXX With H323 protocol used, signal port is Q.931 port using TCP protocol. XXXX is arranged from 1024 through 65535.
  • Page 45 Centrality PA168S IP Phone User Manual (V1.32) Set DTMF relay type. X is ranged form 0 through 3: 0:control string；1:inband audio；2: signal keypad；3:rfc 2833. set service type X Enable/disable the repaid and service system .choose the repaid server provider. Parameter x ranged from 0 through 16: 0: disable repaid card;...
  • Page 46 With Net2phone system used, set password of Net2phone card by this command. set phonenumber XXXXXXXX Set a number of Centrality PA168S IP phone according to systems. Value xxxxx must be an Arabic numeral and no longer than 16 characters.
  • Page 47 Centrality PA168S IP Phone User Manual (V1.32) through 1. 0: do not forward calls without replying; 1: forward call without replying. set dialplan X Enable/disable dial plan and dial number. Parameter X ranged from 0 through 3: 0: disable dial plan; 1: enable dial plan; 2: use dial number;...
  • Page 48 Centrality PA168S IP Phone User Manual (V1.32) Set IDD service prefix number when set dialplan value set as 1 or 2. For example, IDD service prefix number of china is 00; IDD service prefix number of USA is 1, etc. Parameter xxx must be an Arabic numeral and no longer than 3 characters.
  • Page 49 Centrality PA168S IP Phone User Manual (V1.32) Set whether to use digitmap. X ranged from 0 to 1: 0: do not use digitmap; 1: use digitmap. set ringtype X Set types of ring. X is ranged from 0 tohrough 12: 0-9: ring as ordinary rings in different frequency;...
  • Page 50 Set audio frames in RTP package. X is Arabic numerals between 0 and 7. With G.7231, set Centrality PA168S IP phone to use 6.3K rate or not. X is ranged from 0 through 1: 0: use 6.3K rate; 1: use 5.3K rate.
  • Page 51 Centrality PA168S IP Phone User Manual (V1.32) Set initial volume of handout. X is ranged from 0 through 31. set password XXXX Set password of the Centrality PA168S IP phone. XXX must be ASCII characters and no longer than 7 characters. set debug X Set open debugging message output grade for special tool.
  • Page 52 Usage: Exit from Telnet command window without saving the configuration. Relevant usage: None write Command Syntax description: No keyword and parameter Usage: Save the configuration and restart the Centrality PA168S IP phone. Command ping Syntax description: ping IP address Beijing Centrality Communication Inc...
  • Page 53 Centrality PA168S IP Phone User Manual (V1.32) Usage: ping IP address of other NAT device Relevant usage: In telnet window, input ping xx.xxx.xx.xx（an IP address） and return, then the result will be displayed. If the address is effective, “ping OK” will be seen; if the address is ineffective, nothing will be seen.

  • Page 54: Upgrade Centrality Pa168S Ip Phone

    So if nothing is displayed after too long time, it means that ftp is fail. Note All the Telnet commands of Centrality PA168S IP phone should be written in low case and the password is case sensitive.

  • Page 55: Usage Of The Phone

    Receiving calls: Centrality PA168S IP phone can receive incoming calls from other Centrality PA168S IP phone and devices that support the H.323 protocol. It works just like an ordinary phone for incoming calls. When it rings, you can receive the call by following methods: ①...
  • Page 56 Centrality PA168S IP Phone User Manual (V1.32) Call another Centrality PA168 IP phone under the same Gatekeeper: ● 1. Handset: Pick up the handset and listen for the Internet dial tone. Then dial the phone number you wish to call and press ＃...
  • Page 57 Centrality PA168S IP Phone User Manual (V1.32) If Centrality PA168s IP phone does not login the Gatekeeper, you can place a call by lifting the handset or pressing and then Speaker inputting the IP address of the other party, and then pressing ＃...
  • Page 58 ＃ place a call directly. Note Centrality PA168S IP phone supports saving 127 entries unanswered call, dialed call and received call ranged from 0-126 at best. When the entries arrives 127, the latest record will cover the first one. The record will be lost when the phone restarts or turned on.
  • Page 59 Centrality PA168S IP Phone User Manual (V1.32) Reserves the right to make changes in technical and product specification without prior notice. Centrality PA168S IP (V1.32) Net Phone User Manual Copyright© 2003,2004Beijing Centrality Communication Inc All rights reserved Beijing Centrality Communication Inc...
