U.S. Products SOLUS-500 Information & Operating Instructions

Extractor 120v
Hide thumbs Also See for SOLUS-500:
Table of Contents

Advertisement

Quick Links

See also: Information & Operating Instructions
SOLUS-500
EXTRACTOR
120V
INFORMATION
&
OPERATING
INSTRUCTIONS
DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THIS INSTRUCTIONS
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, extremes in temperatures, and store in a
heated location. DO NOT let the machine or the wand freeze. Do not use outdoors.
3. Do not let the pump run dry.
4. Use approved chemicals only. NO SOLVENTS.
5. Wear gloves or use rags when removing quick disconnects to prevent burns.
6. Never use water above 130 ºF/54 ºC in the solution tank.
05.20.2008
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOLUS-500 and is the answer not in the manual?

Questions and answers

Related Manuals for U.S. Products SOLUS-500

Summary of Contents for U.S. Products SOLUS-500

  • Page 1 SOLUS-500 EXTRACTOR 120V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THIS INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine.

  • Page 3: Cleaning Solutions

    INSPECTION: Carefully unpack and inspect your SOLUS-500 for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts CLEANING SOLUTIONS: We recommend liquid cleaning chemicals, such as our Magic Fabric Cleaner.

  • Page 4: Know Your Machine

    KNOW YOUR MACHINE VACUUM LID - This lid provides access into your recovery tank so that you can clean the tank. The lid must be closed before you try to clean.. SOLUTION TANK FILL HOLE - This is where you fill the tank with water and cleaning solution. VACUUM HOSE BARB - This is where you connect your vacuum hose to the machine.

  • Page 5: Switch Plate

    SOLUS-500 HEAT CONTROL (1): SWITCH PLATE This dial controls the water temperature. Turn it clockwise to increase water temperature and counterclockwise to decrease temperature. The heater will operate only if the circuit locator light (#5) or the bypass switch (#6) is on.
  • Page 6 SET-UP: 1. Fill the holding tank with clear water and prespray with the detergent of your choice (we recommend a CRI approved chemical). Mix well. Although this machine is designed to supply instant hot water, the addition of warm water to the holding tank would increase heater efficiency. Never use water above 130º F/54º C in the solution tank. 2.
  • Page 7 Pump inlet hose Pump bypass hose SOLUS-500 05.20.2008...

  • Page 8: Part List

    SOLUS-500 EXTRACTOR PART LIST 120V ITEM PART No DESCRIPTION ITEM PART No. DESCRIPTION FP312 Switch, DPDT,with cover 923B Dual Cord Sensor PCB Light, red Hose clamp Light, green 948B Motor, DC, for pump Knob, red FP____ Pump complete, no mtr FP544 Potentiometer, heat, w/wires &...

  • Page 9: Troubleshooting

    TROUBLE SHOOTING: IF THIS OCCURS CHECK THIS Solution tank is empty. NO SPRAY Clogged spray tip. Pump not running or not primed. Valve on wand not operating. Check the brushes in the pump motor. Replace if necessary. PUMP DOES NOT RUN No power to pump.
  • Page 10 SOLUS-500 EXTRACTOR 120V NOTES: 208-772-0573 800-257-7982 FAX: 208-772-0577 • • Coeur d’Alene, Idaho VISIT US AT: http://www.usproducts.com...
