LT-350
EXTRACTOR
120V
INFORMATION
&
OPERATING
INSTRUCTIONS
DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THE INSTRUCTIONS
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, extremes in temperatures, and store in a
heated location. Use the machine indoors. Do not use outdoors.
3. Do not let the pump run dry.
4. Use approved chemicals only. NO SOLVENTS.
5. Wear gloves or use rags when removing quick disconnects to prevent burns.
03/10 revised 11/10 FORM NO. 56041905

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LT-350 EXTRACTOR 120V and is the answer not in the manual?

Questions and answers

Related Manuals for U.S. Products LT-350 EXTRACTOR 120V

Summary of Contents for U.S. Products LT-350 EXTRACTOR 120V

  • Page 1 LT-350 EXTRACTOR 120V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THE INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage. 2.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be observed, including the following: NOTE: Read all instructions before using this machine.

  • Page 3: Cleaning Solutions

    INSPECTION: Carefully unpack and inspect your LT-350 for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts. CLEANING SOLUTIONS We recommend liquid cleaning chemicalsr.

  • Page 4: Switch Plate

    SWITCH PLATE CIRCUIT LOCATOR LIGHT INDICATES TWO CIRCUITS. HEATER WILL AUTOMATICALLY TURN ON. BYPASS SWITCH. TURNS THE HEATER ON WHEN GREEN PUMP LIGHT IS NOT ON ON/OFF SWITCH RED LIGHT INDICATES HEATER IS HEATING VACUUM SELECT CARPET ON/OFF SWITCH OR UPHOLSTERY Record the serial number and model of your new extractor here: Serial Number: __________________ Model: LT-350____...
  • Page 5 block the open area in the hose barb. This will allow the pump and the vacuum to work together to get the water moving. Priming may take 20-60 seconds, and the solution tank should be full. Once the pump is primed, turn the pump and the vacuum OFF. Remove the priming hose. Add liquid cleaning chemical, with a pH between 6 and 9, to the solution tank.
  • Page 7 LT-350 EXTRACTOR PART LIST 120V ITEM PART No. DESCRIPTION ITEM PART No. DESCRIPTION Chain, lid, 8” Heat sink plate FP446 Lid, solution tank ------ See miscellaneous HCP-1 Holding tank, white Louver, 3”, includes screws 1088 Glide, teflon 1377 Hose, hydraulic, 27-3/4" 2062 Solenoid valve FP357...

  • Page 8: Specifications

    LT-350 EXTRACTOR 120V SPECIFICATIONS: Rotomolded Body: Lifetime Warranty Vacuum: 7.2” 3-stage VAC Shutoff: Ball float Pump: Positive displacement, selectable pressure setting Waterlift: 140” Heat: Instant to 212º F Heater: 2000 Watts Wand: Light weight (only 6-1/2 lb), 2-tip Weight: 112 lbs. Dimensions: 38”...
