U.S. Products KING COBRA 500 100V Information & Operating Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
KING COBRA
500
®
100V
INFORMATION
&
OPERATING
INSTRUCTIONS
DO NOT OPERATE THE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THE INSTRUCTIONS
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, extremes in temperatures, and store in a
heated location. Use the machine indoors. Do not use outdoors.
3. Do not let the pump run dry.
4. Use approved chemicals only. NO SOLVENTS.
5. Wear gloves or use rags when removing quick disconnects to prevent burns.
07.31.2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KING COBRA 500 100V and is the answer not in the manual?

Questions and answers

Related Manuals for U.S. Products KING COBRA 500 100V

Summary of Contents for U.S. Products KING COBRA 500 100V

  • Page 1 KING COBRA ® 100V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE THE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THE INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage. 2.
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine.
  • Page 3 U.S. Products “X-1500” is recommended. The vacuum motor, pump motor, and the pump do not require any scheduled maintenance; however, the motors may require replacement brushes after 1000 - 1500 hours.
  • Page 4 NOTE: This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. Record the serial number and model of your new extractor here: (and be sure to register your warranty: go to www. usproducts.com) Serial Number: __________________ Model: KING COBRA-500-JP Purchase Date:_____________ Write the name and phone number of your distributor:...
  • Page 5 REFER TO THE DIAGRAMS ON THE PREVIOUS PAGE continued from the previous page Connect the priming/siphon hose to the machine, turn the pump ON by turning the pump pressure knob (2) up to increase pump speed, and turn the vacuum switch (3) on. Hold the rubber ‘cork’ against the vacuum inlet hose barb on the recovery tank.
  • Page 7 KING COBRA-500-JP 100V PART LIST ITEM PART No. DESCRIPTION ITEM PART No DESCRIPTION 908A Latch, draw, rubber Chain, lid, 8” 901B Lid, solution tank Louver, 3”, includes 3 screws Holding Tank, white BKCR-BLK Base, black 1088 Glide, teflon Castor, 4” 176A Hose clamp Screw, 6-32 X 1/2”...
  • Page 8 KING COBRA ® 100V SPECIFICATIONS: Rotomolded Body: Lifetime Warranty Vacuum: 7.2” 3-stage VAC Shutoff: Electronic Pump: Positive displacement, fully adjustable 0-500 psi Waterlift: 140” Heat: Fully adjustable 145º to 212 º Heater: 1500 Watts Wand: Double bend, two spray tip, for 500 psi Weight: 122 lbs.
