  • Page 1 Bordbar CDF-11 Kompressor Bordbar Bedienungsanleitung EN 18 Compressor bordbar Instruction Manual...
  • Page 2 BordBar CDF-11 EMERGENCY OVERRIDE NORMAL USE POWER FRIDGE FREEZER ERROR...
  • Page 3 BordBar CDF-11...

  • Page 4: Table Of Contents

    Safety instructions BordBar CDF-11 Please read this operating manual carefully before starting the device. Keep it in a safe place for future reference. If the device is resold, this operating manual must be handed over to the purchaser along with it.
  • Page 5 Safety instructions BordBar CDF-11 The cooling device is not suitable for transporting caustic materials or materials containing solvents. Do not open the refrigerant circuit under any circumstances! Connect the device with the 12/24 V lead supplied to a 12/24 V socket.

  • Page 6: Intended Use

    Note To operate the device using a 220-240 V~ mains supply, we recommend using a WAECO rectifier (accessory). Caution! If you wish to cool medicines, please check if the cooling capacity of the device is suitable for the medicine in question.

  • Page 7: Technical Description

    Technical description BordBar CDF-11 Technical description The cooler can chill products, keep them cool as well as freeze them. A main- tenance-free, CFC-free refrigerant circuit with compressor provides the cool- ing. The cooler is suitable for mobile use. When used in vehicles the cooler can be secured with the seat belt.
  • Page 8 Technical description BordBar CDF-11 Operating and display elements Control panel (fig. 2, page 2) Item Description Explanation On/Off button Switches the cooler on or off when the button is pressed for between one and two seconds POWER Status indication LED lights up green Compressor is on;...

  • Page 9: Operation

    Operation BordBar CDF-11 Operation The device is equipped with an interior LED light which remains on whenever power is connected. The power consumption of this LED light is extremely low and insignificant compared to the overall power consumption of the device.
  • Page 10 Operation BordBar CDF-11 Securing the cooler in the vehicle ➤ Open the lid of the cooler. ➤ Place the seat belt into the fixing position (fig. 1 3, page 2) of the cooler. ➤ Close the lid. ➤ Fasten the seat belt and tighten it.

  • Page 11: Setting The Temperature

    Operation BordBar CDF-11 ➤ Press the “ON/OFF” button (fig. 2 1, page 2) for three seconds. ✓ The “POWER” LED (fig. 2 2, page 2) lights up green. When the cooler reaches the preset temperature, the LED lights up orange.
  • Page 12 Operation BordBar CDF-11 Note When switched off by the battery monitor due to low voltage the display (fig. 2 5, page 2) goes blank and the “POWER” LED (fig. 2 2, page 2) flashes orange. Caution – Danger of damage! When switched off by the battery monitor, the battery will no longer be fully charged.
  • Page 13 Operation BordBar CDF-11 5.10 Using the emergency switch The device is equipped with an emergency switch. Thus you can keep cool- ing if an error occurs within the interior electronics. Note During normal operation the emergency switch (fig. 1 12, page 2) has to be set to the “Normal”...

  • Page 14: Cleaning And Maintenance

    Cleaning and maintenance BordBar CDF-11 5.13 Replacing the plug fuse (12/24 V) ➤ Pull the adapter sleeve (fig. 3 4, page 3) off of the plug. ➤ Unscrew the screw (fig. 3 5, page 3) out of the upper half of the housing (fig.

  • Page 15: Troubleshooting

    Troubleshooting BordBar CDF-11 Troubleshooting Fault Possible cause Suggested remedy Device does not function, There is no voltage The ignition must be switched on in “POWER” LED does present in the 12/24 V most vehicles to apply current to the not glow.

  • Page 16: Technical Data

    Technical data BordBar CDF-11 Technical data BordBar CDF-11 Item no.: 9105100007 Gross capacity: 10.5 litres Connection voltage: 12/24 Vg Power consumption: max. 30 W Climate class: Cooling capacity: +10 °C to –18 °C Dimensions: 540 x 235 x 358 mm...
