OPERATION AND
INSTALLATION MANUAL
For Models:
700DDPOOL
1200DDPOOL
1000RHC
1000RHCAC
TO BE COMPLETED BY CONTRACTOR AFTER INSTALLATION
Installation Date
NOTE: ALTHOUGH SOME MODELS
DIFFER IN OPERATION, THE BASIC
STEPS ARE SIMILAR.
CAUTION
Before installation, careful consideration must be
given to how the system will operate if connected to
any other piece of mechanical equipment, i.e. a forced
air furnace or air handler, operating at a higher static.
After installation, the compatibility of the two pieces of
equipment must be confirmed, by measuring the
airflow's of the Heat/Energy Recovery Ventilator
(HRV), by using the balancing procedure in
this manual.
It is always important to assess how the operation
of any HRV may interact with vented combustion
equipment (ie. Gas Furnaces, Oil Furnaces, Wood
Stoves, etc.).
NEVER install an HRV in a situation where its normal
operation, lack of operation or partial failure may result
in the backdrafting or improper functioning of vented
combustion equipment!!!
Installing Contractor
Telephone / Contact
Serial Number
Model
* LEAVE FOR HOMEOWNER
NOTE: Due to ongoing research and product development, specifications,
ratings and dimensions are subject to change without notice.
TI-81C
1203
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lifebreath 1000RHC
Summary of Contents for Lifebreath 1000RHC
- Page 1 OPERATION AND INSTALLATION MANUAL For Models: 700DDPOOL 1200DDPOOL 1000RHC 1000RHCAC TO BE COMPLETED BY CONTRACTOR AFTER INSTALLATION Installation Date NOTE: ALTHOUGH SOME MODELS DIFFER IN OPERATION, THE BASIC STEPS ARE SIMILAR. CAUTION Before installation, careful consideration must be given to how the system will operate if connected to any other piece of mechanical equipment, i.e.
-
Page 2: Table Of Contents
Table of Contents Introduction ...2 Technical Data - Model 700DDPOOL ...3 Technical Data - Model 1200DDPOOL ...4 Technical Data - Model 1000RHC ...5 Technical Data - Model 1000RHCAC...5 Sizing Your Pool HRV...6 Calculation ...7 System Installations ...7 Table 1 Evaporation Rate ...8 Table 2 Flowrate Factor ... -
Page 3: Specifications
SPECIFICATIONS CORES Modular (2 section) patented aluminum heat recovery cores arranged for efficient cross-flow ventilation.Meets the flame spread and smoke developed classifications of the National Building Code and NFPA 90A (1993 Edition) MOTORS Two PSC, 3 speed single shafted, 120 VAC, 2.75 Amps each (5.5 total on high speed). -
Page 4: Technical Data - Model 1200Ddpool
SPECIFICATIONS CORES Modular (3 section) patented aluminum heat recovery cores arranged for efficient cross-flow ventilation. Meets the flame spread and smoke developed classifications of the National Building Code and NFPA 90A (1993 Edition). MOTORS Two PSC, 3 speed double shafted, 120 VAC, 4 Amps each (8.1 total on high speed). -
Page 5: Technical Data - Model 1000Rhc
Each air stream has one double shafted motor driving 2 centrifugal blowers. HYDRONIC REHEAT COIL Standard built-in coil in both 1000RHC and 1000RHCAC. Rated 35,000 BTU @ 140°F, 3 US gal./min. Design temperature drop is 20°F, fluid pressure drop is 1.3 feet WG at rated flow, 3/4" fittings. -
Page 6: Sizing Your Pool Hrv
Sizing your Pool Heat Recovery Ventilator Determining ventilation requirements for Indoor Pool enclosures There are two primary reasons to ventilate an indoor pool enclosure. One is to provide effective and efficient control of harmful humidity levels. The other reason is to control the Indoor Air Quality (IAQ) in the pool room enclosure. -
Page 7: Calculation
Calculation Note: As a general rule, if the water temperature is maintained at 80˚F and the pool room air temperature is maintained at 82˚F, use a factor of 1 cfm/sq ft of pool surface or .5 cfm/sq ft of room area (whichever is greater) to determine amount of ventilation required. - Page 8 TABLE 1 40% 50% 60% 40% 50% 60% 40% 50% 60% 40% 50% 60% 40% 50% 60% 40% 50% 60% 0.069 0.063 0.056 0.079 0.073 0.066 0.090 0.084 0.077 0.102 0.095 0.089 0.115 0.108 0.102 0.068 0.060 0.053 0.078 0.070 0.063 0.088 0.081 0.074 0.100 0.093 0.086 0.113 0.106 0.099 0.065 0.058 0.050 0.075 0.068 0.060 0.086 0.079 0.071 0.098 0.090 0.083 0.111 0.103 0.096 0.125 0.063 0.055 0.047 0.073 0.065 0.057 0.084 0.076 0.068 0.096 0.088 0.079 0.109 0.101 0.092 0.123 0.061 0.052 0.043 0.071 0.062 0.053 0.082 0.073 0.064 0.094 0.085 0.076 0.107 0.098 0.089 0.121 0.112...
- Page 9 TABLE 2 40% 50% 60% 40% 50% 60% 40% 50% 60% 40% 50% 60% 40% 50% 60% 40% 50% 60% 39.70 31.50 26.10 35.70 28.30 23.40 32.10 25.50 21.10 29.00 23.00 19.00 26.10 20.70 17.20 40.20 31.80 26.20 36.10 28.50 23.60 32.40 25.70 21.20 29.20 23.10 19.10 26.30 20.90 17.20 40.80 32.10 26.50 36.50 28.80 23.80 32.80 25.90 21.40 29.50 23.30 19.20 26.60 21.00 17.40 41.60 32.60 26.80 37.20 29.20 24.00 33.30 26.20 21.60 29.90 23.60 19.40 26.90 21.20 17.50 42.60 33.20 27.20 38.00 29.70 24.40 34.00 26.60 21.90 30.40 23.90 19.60 27.30 21.50 17.70...
-
Page 10: Installation Diagram Sketch #1
Installation Diagrams Main Stale Air Intake Typical Duct Layout Sketch #1 EXPOSED WALL Blanket exposed windows with fresh dry air Min. 10’-0" EXPOSED WALL Always attempt to minimize short circuiting of air streams, (supply fresh air on one side of room and exhaust stale air from opposite side of room). -
Page 11: Installation Diagram Sketch #2
Stale Air Intake Typical Duct Layout Sketch #2 EXPOSED WALL Blanket exposed windows with fresh dry air EXPOSED WALL Min. 10’-0" Always attempt to minimize short circuiting of air streams, (supply fresh air on one side of room and exhaust stale air from opposite side of room). -
Page 12: Location For Mounting
Location for Mounting The HRV must be located in a heated space where the surrounding air temperature does not fall below 60˚F (16˚C). The unit must be mounted level (horizontal) to obtain proper drainage or water from the heat exchange element and drip pans. -
Page 13: Outside Weatherhoods
Outside Weatherhoods The weatherhoods must have built-in “bird” screen with 1/4 in (6.35 mm) minimum mesh to prevent birds and rodents from entering into the ductwork. Do not use smaller mesh as it will be very susceptible to plugging up. Gravity dampers at the vents must not be used as they will restrict air flow and often “seize up”. -
Page 14: Fresh Air Supply System
Fresh Air Supply System The fresh air supply ductwork from the HRV may be directly connected to the return air duct of the forced air system. Check the air flow balance of the HRV with the air handler blower both “ON” and “OFF” to determine that it does not imbalance the HRV more than 10%. -
Page 15: Various Installation Types
Various Installation Types Figure 7A Saddle Installation Hang unit with suspended rods and "U" channel members. Figure 7C Suspended Unit Suspended using Polyester reinforced PVC support straps. NOTE: Vibration Isolators (Supplied by others) Threaded rod and U channel (Supplied by others) Figure 7B Curb Mounted Curb is wood or metal... -
Page 16: Electrical Connections
Electrical Connections It is recommended that a licensed electrician make all electrical connections. It is very important that the unit be properly grounded. It is recommended that a separate 15 amp/120 volt circuit be used. WARNING: In order to prevent electric shock when cleaning or servicing the HRV, it is extremely important to confirm the polarity of the power line that is switched by the safety (disconnect) switch whose control arm is... -
Page 17: Operation Of The Hrv
Operation of the HRV These Recirculating Models of HRV's will provide fresh clean air without sacrificing the savings of your energy conserving home. When outdoor air is required for pool room dehumidification, the aluminum cores of the HRV provide effective and efficient heat recovery exchange. Whether operating as an HRV or in recirculation mode, the energy efficient PSC blower motors provide reliable and cost effective operation. -
Page 18: Ducting Requirements & Mode Of Operation
Ducting Requirements & Mode of Operation Ventilation Mode In ventilation mode, both motors are running and air is being exchanged with the outside through the supply and exhaust ducts. Recirculation Mode In recirculation mode the supply motor continues to run and a damper moves to block off air entering from outside, drawing air instead from the conditioned space. -
Page 19: Speed Selection And Controls
Ventilation/Recirculation Damper only, not low/high speed control. DISCLAIMER The Model 1000RHC and RHCAC is intended to be installed by certified HVAC trades people. Damage resulting in partial or complete failure of the Reheat/Air Conditioning portion is the respon- sibility of the installing contractor. -
Page 20: Pitot Tube Air Flow Balancing
Pitot Tube Air Flow Balancing It is necessary to have balanced air flows in an HRV. The volume of air brought in from the outside must equal the volume of air exhaust- ed by the unit. If the air flows are not properly balanced, then; •... -
Page 21: Service/Maintenance
Service/Maintenance Servicing your HRV on a regular schedule will result in optimum operating efficiencies and prolonged life of the equipment. Due to numerous applications in which this equipment can be installed, it is difficult to predict servicing intervals. In certain situations where there is heavy smoke, servicing the equipment every one - two months may be needed;... -
Page 22: Filters
FILTERS Open front service door to access the filters located in both supply and exhaust air streams. Note to remove and install filters, it may be easier to first remove the core(s). See CORE. The filters are designed to stop large particles from entering in the core. -
Page 23: Troubleshooting Your Hrv System
Troubleshooting Your HRV System SYMPTOM Poor Air Flows Supply air feels cold Dehumidistat is not Operating Humidity Levels are too High Condensation is appearing on the windows Humidity Levels are too Low HRV and / or Ducts Frosting up Condensation or Ice Build Up in Insulated Duct to the Outside Water in the bottom of the HRV CAUSE... -
Page 25: Warranty
This Warranty is personal to NUTECH period of two years, save and except that a 15 YEAR WARRANTY is given to the LIFEBREATH core should it develop a condensation leak or become perforated due to corrosion caused by nor- mal use.
