Select ADSL, and you will see the statistics table as below.
Statistics Table:
Transmit total PDUs
Transmit
Statistics
Transmit total Error Counts
Receive total PDUs
Receive
Statistics
Receive total Error Counts
Select WLAN, and you will see the statistics table as below.
Statistics Table:
Tx Frames Count
Transmit
Tx Errors Count
Statistics
Tx Drops Count
Rx Frames Count
Receive
Rx Errors Count
Statistics
Rx Drops Count
Click the REFRESH button to refresh immediately.

4.2 Quick Start

Please refer to " 3.2
iB-WRA150N
The frames transmitted over the WLAN when wireless data is
being transmitted.
The errors occurred over the WLAN when wireless data is being
transmitted.
The drops occurred over the WLAN when wireless data is being
transmitted.
The frames received over the WLAN when wireless data is being
transmitted.
The errors occurred over the WLAN when wireless data is being
received.
The drops occurred over the WLAN when wireless data is being
received.
Login".
150M Wireless-N ADSL2+ Router User Guide
The total PDUs transmitted over the ADSL port.
The total errors occurred over the ADSL port when data
is being transmitted.
The total PDUs transmitted over the ADSL port.
The total errors occurred over the ADSL port when data
is being received.
